Huawei S220-8P4S Switches, 8x10/100/1000BASE-T Ports, 125W PoE+, 4xGE SFP Ports, Built-In AC Power, 1U Form Factor, Gigabit Managed Switch, Gray | 98012552
Model :
SKU : NS-HUAWEI S220-8P4S
About this item
0
Inclusive of VAT
Delivery to
FREE scheduled delivery as soon as Loading...
Sold and shipped by: Adarc computers
1
About this item
Description
Integrated Fixed Device Specifications
| Dimensions without packaging (H x W x D) | Basic dimensions (excluding the parts protruding from the body): 43.6 mm x 320.0 mm x 210.0 mm (1.72 in. x 12.6 in. x 8.27 in.) Maximum dimensions (the depth is the distance from ports on the front panel to the parts protruding from the rear panel): 43.6 mm x 320.0 mm x 217.0 mm (1.72 in. x 12.6 in. x 8.54 in.) |
| Dimensions with packaging (H x W x D) | 90.0 mm x 465.0 mm x 380.0 mm (3.54 in. x 18.31 in. x 14.96 in.) |
| Chassis height | 1 U |
| Installation type | Rack mounting, Desk mounting, Wall mounting |
| Chassis material | Metal |
| Weight without packaging | 2.23 kg (4.92 lb) |
| Weight with packaging | 3.05 kg (6.72 lb) |
| Typical power consumption | 19.99 W |
| Maximum power consumption | ??? Without PoE: 25.09 W ??? Full PoE load: 166.65 W (PoE: 125 W) |
| Static power consumption | 17.19 W |
| Number of fans modules | 1 |
| Maximum number of FE ports | 8 |
| Uplink ports | 4 x GE SFP ports |
| Downlink ports | 8 x 10/100/1000BASE-T ports (380 W, PoE+) |
| Long-term operating temperature | -5??C to +50??C (23??F to 122??F) at an altitude of 0-1800 m (0-5905.44 ft.) The operating temperature ranges from ???5??C (23??F) to +45??C (113??F) when optical modules with transmission distances ??? 60 km are used. |
| Storage temperature | ???40??C to +70??C (???40??F to +158??F) |
| Long-term operating relative humidity | 5% RH to 95% RH (non-condensing) |
| Power supply mode | AC built-in |
| Rated input voltage | - AC input: 100 V AC to 240 V AC, 50/60 Hz - High-voltage DC input: 240 V DC |
| Input voltage range | - AC input: 90 V AC to 290 V AC; 45 Hz to 65 Hz - High-voltage DC input: 190 V DC to 290 V DC |
| Maximum input current | 3 A |
| Console port | RJ45 |
| Dying gasp | Supported |
| Service port surge protection | Common mode: ??7 kV |
| Power supply surge protection | Differential mode: ??6 kV; Common mode: ??6 kV |
| Types of fans | Built-in |
| Heat dissipation mode | Air cooling for heat dissipation, intelligent fan speed adjustment |
| Airflow direction | Air intake from left and air exhaust from right |
| PoE | Supported |
| Certification | EMC certification, Safety certification, Manufacturing certification |
Specification
Integrated Fixed Device Specifications
| Dimensions without packaging (H x W x D) | Basic dimensions (excluding the parts protruding from the body): 43.6 mm x 320.0 mm x 210.0 mm (1.72 in. x 12.6 in. x 8.27 in.) Maximum dimensions (the depth is the distance from ports on the front panel to the parts protruding from the rear panel): 43.6 mm x 320.0 mm x 217.0 mm (1.72 in. x 12.6 in. x 8.54 in.) |
| Dimensions with packaging (H x W x D) | 90.0 mm x 465.0 mm x 380.0 mm (3.54 in. x 18.31 in. x 14.96 in.) |
| Chassis height | 1 U |
| Installation type | Rack mounting, Desk mounting, Wall mounting |
| Chassis material | Metal |
| Weight without packaging | 2.23 kg (4.92 lb) |
| Weight with packaging | 3.05 kg (6.72 lb) |
| Typical power consumption | 19.99 W |
| Maximum power consumption | ??? Without PoE: 25.09 W ??? Full PoE load: 166.65 W (PoE: 125 W) |
| Static power consumption | 17.19 W |
| Number of fans modules | 1 |
| Maximum number of FE ports | 8 |
| Uplink ports | 4 x GE SFP ports |
| Downlink ports | 8 x 10/100/1000BASE-T ports (380 W, PoE+) |
| Long-term operating temperature | -5??C to +50??C (23??F to 122??F) at an altitude of 0-1800 m (0-5905.44 ft.) The operating temperature ranges from ???5??C (23??F) to +45??C (113??F) when optical modules with transmission distances ??? 60 km are used. |
| Storage temperature | ???40??C to +70??C (???40??F to +158??F) |
| Long-term operating relative humidity | 5% RH to 95% RH (non-condensing) |
| Power supply mode | AC built-in |
| Rated input voltage | - AC input: 100 V AC to 240 V AC, 50/60 Hz - High-voltage DC input: 240 V DC |
| Input voltage range | - AC input: 90 V AC to 290 V AC; 45 Hz to 65 Hz - High-voltage DC input: 190 V DC to 290 V DC |
| Maximum input current | 3 A |
| Console port | RJ45 |
| Dying gasp | Supported |
| Service port surge protection | Common mode: ??7 kV |
| Power supply surge protection | Differential mode: ??6 kV; Common mode: ??6 kV |
| Types of fans | Built-in |
| Heat dissipation mode | Air cooling for heat dissipation, intelligent fan speed adjustment |
| Airflow direction | Air intake from left and air exhaust from right |
| PoE | Supported |
| Certification | EMC certification, Safety certification, Manufacturing certification |
