Synology DX1222 12-Bay Expansion Unit, 12 x 3.5" or 2.5" SATA Drive Bays, 1 x Mini-SAS HD Port, Supports Hard Drives and SSDs, Seamless Storage Expansion, For DS3622xs+ & DS2422+, Black | DX1222
Model :
SKU : SYNOLOGY DX1222 12-BAY
About this item
0
Inclusive of VAT
Delivery to
FREE scheduled delivery as soon as Loading...
Sold and shipped by: Adarc computers
1
About this item
Description
table { border-collapse: collapse; width: 100%; } tr { border-bottom: 1px solid rgb(222, 226, 230); } td { padding: 8px; margin: 0; }
| Hardware Specifications | |
| Applied Models | Supports creating volumes across different units 22 series: DS3622xs+, DS2422+ |
| Notes | To have better performance, we recommend creating storage volumes physically located within the same NAS or Expansion Unit, rather than creating volumes across your NAS and Expansion Unit. |
| Storage | |
| Drive Bays | 12 |
| Compatible Drive Type* | 3.5" SATA HDD 2.5" SATA HDD 2.5" SATA SSD |
| Hot Swappable Drive* | |
| RAID Management through Synology DSM | |
| Notes | Synology only guarantees full functionality, reliability, and performance for Synology drives listed on the compatibility list. The use of non-validated components may limit certain functionality and result in data loss and system instability. |
| External Ports | |
| Expansion Port | 1 |
| Appearance | |
| Size (Height x Width x Depth) | 270 mm x 300 mm x 340 mm |
| Weight | 9.02 kg |
| Power | |
| Power Recovery | Synchronized with the Synology DiskStation |
| Power Supply Unit / Adapter | 550 W |
| AC Input Power Voltage | 100V to 240V AC |
| Power Frequency | 50/60 Hz, Single Phase |
| Power Consumption | 57.71 W (Access) 16.25 W (HDD Hibernation) |
| British Thermal Unit | 194.96 BTU/hr (Access) 55.48 BTU/hr (HDD Hibernation) |
| Notes | Power consumption is measured when it is fully loaded with Western Digital 1TB WD10EFRX hard drive(s). |
| Temperature | |
| Operating Temperature | 0??C to 40??C (32??F to 104??F) |
| Storage Temperature | -20??C to 60??C (-5??F to 140??F) |
| Relative Humidity | 5% to 95% RH |
| Others | |
| System Fan | 120 mm x 120 mm x 2 pcs |
| Easy Replacement System Fan | |
| Noise Level* | 24.6 dB(A) |
| Notes | Noise Level Testing Environment: Fully loaded with Seagate ST2000VN000 hard drive(s) in the idle state. Two G.R.A.S. Type 40AE microphones, each set up 1 meter away from the Synology expansion unit at the front and rear. Background noise: 16.49-17.51 dB(A); Temperature: 24.25-25.75??C; Humidity: 58.2-61.8%. |
| Certification | |
| UL | |
| FCC | |
| CE | |
| BSMI | |
| UKCA | |
| EAC | |
| VCCI | |
| RCM | |
| KC | |
| Warranty | |
| 5 Years | The warranty period starts from the purchase date as stated on your purchase receipt. (Learn more) |
| Environment & Packaging | |
| Environment | RoHS Compliant |
| Packaging Content | |
| Main Unit X 1 | |
| Accessory Pack X 1 | |
| AC Power Cord X 1 | |
| Expansion Cable: MiniSAS-HD X 1 | |
| Quick Installation Guide X 1 | |
| Optional Accessories | |
| 3.5" SATA HDD: HAT5300/HAT3300 | |
| 2.5" SATA SSD: SAT5210 | |
Specification
table { border-collapse: collapse; width: 100%; } tr { border-bottom: 1px solid rgb(222, 226, 230); } td { padding: 8px; margin: 0; }
| Hardware Specifications | |
| Applied Models | Supports creating volumes across different units 22 series: DS3622xs+, DS2422+ |
| Notes | To have better performance, we recommend creating storage volumes physically located within the same NAS or Expansion Unit, rather than creating volumes across your NAS and Expansion Unit. |
| Storage | |
| Drive Bays | 12 |
| Compatible Drive Type* | 3.5" SATA HDD 2.5" SATA HDD 2.5" SATA SSD |
| Hot Swappable Drive* | |
| RAID Management through Synology DSM | |
| Notes | Synology only guarantees full functionality, reliability, and performance for Synology drives listed on the compatibility list. The use of non-validated components may limit certain functionality and result in data loss and system instability. |
| External Ports | |
| Expansion Port | 1 |
| Appearance | |
| Size (Height x Width x Depth) | 270 mm x 300 mm x 340 mm |
| Weight | 9.02 kg |
| Power | |
| Power Recovery | Synchronized with the Synology DiskStation |
| Power Supply Unit / Adapter | 550 W |
| AC Input Power Voltage | 100V to 240V AC |
| Power Frequency | 50/60 Hz, Single Phase |
| Power Consumption | 57.71 W (Access) 16.25 W (HDD Hibernation) |
| British Thermal Unit | 194.96 BTU/hr (Access) 55.48 BTU/hr (HDD Hibernation) |
| Notes | Power consumption is measured when it is fully loaded with Western Digital 1TB WD10EFRX hard drive(s). |
| Temperature | |
| Operating Temperature | 0??C to 40??C (32??F to 104??F) |
| Storage Temperature | -20??C to 60??C (-5??F to 140??F) |
| Relative Humidity | 5% to 95% RH |
| Others | |
| System Fan | 120 mm x 120 mm x 2 pcs |
| Easy Replacement System Fan | |
| Noise Level* | 24.6 dB(A) |
| Notes | Noise Level Testing Environment: Fully loaded with Seagate ST2000VN000 hard drive(s) in the idle state. Two G.R.A.S. Type 40AE microphones, each set up 1 meter away from the Synology expansion unit at the front and rear. Background noise: 16.49-17.51 dB(A); Temperature: 24.25-25.75??C; Humidity: 58.2-61.8%. |
| Certification | |
| UL | |
| FCC | |
| CE | |
| BSMI | |
| UKCA | |
| EAC | |
| VCCI | |
| RCM | |
| KC | |
| Warranty | |
| 5 Years | The warranty period starts from the purchase date as stated on your purchase receipt. (Learn more) |
| Environment & Packaging | |
| Environment | RoHS Compliant |
| Packaging Content | |
| Main Unit X 1 | |
| Accessory Pack X 1 | |
| AC Power Cord X 1 | |
| Expansion Cable: MiniSAS-HD X 1 | |
| Quick Installation Guide X 1 | |
| Optional Accessories | |
| 3.5" SATA HDD: HAT5300/HAT3300 | |
| 2.5" SATA SSD: SAT5210 | |
