| Dimensions |
Height: 164 mm Width: 910 mm Depth: 130.5 mm Lens Depth: 28.8 mm Weight: 7.08 kg |
| Technical Specifications |
Certifications & Compatibility: For the latest information on certifications and compatibility, visit www.logitech.com/support/vc-certifications Microsoft Teams Rooms on Android 1: For medium-sized rooms Microsoft Teams Rooms on Windows 2: For medium-sized rooms |
| General Specifications |
Built-in Components: 6 beamforming microphones, PTZ camera, 2 speakers, AI Viewfinder, cable management and retention system, table stand, Logitech CollabOS platform Enclosure: All-in-one enclosure with integrated table stand and patented speaker suspension system to eliminate vibration-induced camera shake and audio interference Device Management: Logitech Sync Displays Supported: 2 Display Resolution: Up to 1080p Network Protocol Support: IPv4, IPv6 Proxy Support: IP based Proxy, FQDN based Proxy, Proxy using PAC file |
| Camera |
Resolution: 4K, 1440p, 1080p, 900p, 720p, and SD at 30fps Pan: Motorized ??25?? Tilt: Motorized ??15?? Zoom: 15X HD zoom (5X optical and 3X digital) Diagonal Field of View: 90?? Horizontal Field of View: 82.1?? Vertical Field of View: 52.2?? Total Room Coverage (field of view + pan and tilt): 132.1?? Horizontal x 82.2?? Vertical |
| Speakers |
Drivers: 2x 70 mm Sensitivity: 92dB SPL @1W, 99dB SPL @8.0W, both +/-2dB at ?? meter Rated Power: 8W THD: 1kHz < 2% at 1W Speaker Sampling Rate: 48 kHz Impedance: 4 Ohms |
| Microphones |
Frequency Response: 90Hz ??? 16kHz Sensitivity: >-36dBFS +/-1 dB @ 1Pa Microphone data rate output: 48KHz Pickup Range: Up to 7 m Beamforming Elements: 6 omnidirectional digital MEMS microphones forming 5 adaptive acoustic broadside beams Audio processing: AEC (Acoustic Echo Cancellation), VAD (Voice Activity Detector) Noise suppression: AI based de-noising algorithm Add-on Mics: Supports up to 4 additional Rally Mic Pods and 2 Rally Mic Pod Hubs for larger conference rooms |
| RightSense??? Technologies |
RightLight: Renders natural skin tones for each participant RightSight: Primary camera frames the active speaker while the AI Viewfinder captures everyone in the room RightSound: Distinguishes speech from other sounds to auto-level voices while suppressing background noise and echo Grid View: Detects and frames all meeting participants in order to create equitable hybrid meeting experiences. To learn more, visit logitech.com/prosupport/gridview |
| Interfaces |
HDMI Out: 2 (up to 1080p) HDMI In: 1 USB: 3x Type A, 1x Type C Network: 10/100/1G Ethernet WiFi: 802.11a/b/g/n/ac External Mic Input: Yes (proprietary input supports optional Rally Mic Pod, Rally Mic Pod Hub, and Rally Mic Pod Extension Cable) Remote Control: Bluetooth?? Low Energy |
| Power & Cables |
Power supply: Auto-sensing Operating Voltage/Power: 100-240V, 19V, 4.74A Power Supply Dimensions: 127 mm x 51 mm x 30 mm DC Cable: 1.5 m AC Cable: 1 m HDMI 1.4 Cable: 2 m USB A to USB C 3.0 Cable: 2.2 m |
| Environmental |
Operating Temperature: 0 to 40??C Storage Temperature: -40 to 70 ??C Humidity: 10 to 95% BTU/hr: 57 idle, 64 in meeting |
| Security |
Full Disk Encryption: AES-128 Data Encryption: Symmetric Keys, PKI Device Identity: Protected by device attestation Device Access: Authenticated using API Key Protection: Arm TrustZone, RPMP |
| Accessories |
Mounts: Wall Mount for Video Bars, TV Mount for Video Bars Audio: Rally Mic Pod, Rally Mic Pod Hub, Rally Mic Pod Mount, Rally Mic Pod Extension Cable Connectivity: Logitech Strong USB (10m, 25m, 45m) Touch Controller: Logitech Tap and Tap IP 3Compatibility may vary, see www.logitech.com/support/tap-compatibility for the latest information |
| Dimensions |
Height: 164 mm Width: 910 mm Depth: 130.5 mm Lens Depth: 28.8 mm Weight: 7.08 kg |
| Technical Specifications |
Certifications & Compatibility: For the latest information on certifications and compatibility, visit www.logitech.com/support/vc-certifications Microsoft Teams Rooms on Android 1: For medium-sized rooms Microsoft Teams Rooms on Windows 2: For medium-sized rooms |
| General Specifications |
Built-in Components: 6 beamforming microphones, PTZ camera, 2 speakers, AI Viewfinder, cable management and retention system, table stand, Logitech CollabOS platform Enclosure: All-in-one enclosure with integrated table stand and patented speaker suspension system to eliminate vibration-induced camera shake and audio interference Device Management: Logitech Sync Displays Supported: 2 Display Resolution: Up to 1080p Network Protocol Support: IPv4, IPv6 Proxy Support: IP based Proxy, FQDN based Proxy, Proxy using PAC file |
| Camera |
Resolution: 4K, 1440p, 1080p, 900p, 720p, and SD at 30fps Pan: Motorized ??25?? Tilt: Motorized ??15?? Zoom: 15X HD zoom (5X optical and 3X digital) Diagonal Field of View: 90?? Horizontal Field of View: 82.1?? Vertical Field of View: 52.2?? Total Room Coverage (field of view + pan and tilt): 132.1?? Horizontal x 82.2?? Vertical |
| Speakers |
Drivers: 2x 70 mm Sensitivity: 92dB SPL @1W, 99dB SPL @8.0W, both +/-2dB at ?? meter Rated Power: 8W THD: 1kHz < 2% at 1W Speaker Sampling Rate: 48 kHz Impedance: 4 Ohms |
| Microphones |
Frequency Response: 90Hz ??? 16kHz Sensitivity: >-36dBFS +/-1 dB @ 1Pa Microphone data rate output: 48KHz Pickup Range: Up to 7 m Beamforming Elements: 6 omnidirectional digital MEMS microphones forming 5 adaptive acoustic broadside beams Audio processing: AEC (Acoustic Echo Cancellation), VAD (Voice Activity Detector) Noise suppression: AI based de-noising algorithm Add-on Mics: Supports up to 4 additional Rally Mic Pods and 2 Rally Mic Pod Hubs for larger conference rooms |
| RightSense??? Technologies |
RightLight: Renders natural skin tones for each participant RightSight: Primary camera frames the active speaker while the AI Viewfinder captures everyone in the room RightSound: Distinguishes speech from other sounds to auto-level voices while suppressing background noise and echo Grid View: Detects and frames all meeting participants in order to create equitable hybrid meeting experiences. To learn more, visit logitech.com/prosupport/gridview |
| Interfaces |
HDMI Out: 2 (up to 1080p) HDMI In: 1 USB: 3x Type A, 1x Type C Network: 10/100/1G Ethernet WiFi: 802.11a/b/g/n/ac External Mic Input: Yes (proprietary input supports optional Rally Mic Pod, Rally Mic Pod Hub, and Rally Mic Pod Extension Cable) Remote Control: Bluetooth?? Low Energy |
| Power & Cables |
Power supply: Auto-sensing Operating Voltage/Power: 100-240V, 19V, 4.74A Power Supply Dimensions: 127 mm x 51 mm x 30 mm DC Cable: 1.5 m AC Cable: 1 m HDMI 1.4 Cable: 2 m USB A to USB C 3.0 Cable: 2.2 m |
| Environmental |
Operating Temperature: 0 to 40??C Storage Temperature: -40 to 70 ??C Humidity: 10 to 95% BTU/hr: 57 idle, 64 in meeting |
| Security |
Full Disk Encryption: AES-128 Data Encryption: Symmetric Keys, PKI Device Identity: Protected by device attestation Device Access: Authenticated using API Key Protection: Arm TrustZone, RPMP |
| Accessories |
Mounts: Wall Mount for Video Bars, TV Mount for Video Bars Audio: Rally Mic Pod, Rally Mic Pod Hub, Rally Mic Pod Mount, Rally Mic Pod Extension Cable Connectivity: Logitech Strong USB (10m, 25m, 45m) Touch Controller: Logitech Tap and Tap IP 3Compatibility may vary, see www.logitech.com/support/tap-compatibility for the latest information |
