AMD Ryzen 9 7950X 4.5 GHz AM5 170W Desktop Processor, 16 Cores & 32 Threads, 5.7 GHz Max Boost Clock, 64MB L3 Cache, AMD Radeon Graphics, 2CH -DDR5-6400 / 128GB Max, Zen 4 Arc | 100-100000514WOF
Model :
SKU : PRC-AMD 7950X RYZEN 9
About this item
Description
AMD Ryzen 9 7950X 4.5 GHz AM5 170W Desktop Processor, 16 Cores & 32 Threads, 5.7 GHz Max Boost Clock, 64MB L3 Cache, AMD Radeon Graphics, 2CH -DDR5-6400 / 128GB Max, Zen 4 Arc | 100-100000514WOF
| Category | Specification |
|---|---|
| Name | AMD Ryzen??? 9 7950X |
| Family | Ryzen |
| Series | Ryzen 7000 Series |
| Form Factor | Desktops, Boxed Processor |
| Market Segment | Enthusiast Desktop |
| AMD PRO Technologies | No |
| Consumer Use | Yes |
| Regional Availability | Global |
| Former Codename | Raphael AM5 |
| Architecture | Zen 4 |
| # of CPU Cores | 16 |
| Multithreading (SMT) | Yes |
| # of Threads | 32 |
| Max. Boost Clock | Up to 5.7 GHz |
| Base Clock | 4.5 GHz |
| L1 Cache | 1 MB |
| L2 Cache | 16 MB |
| L3 Cache | 64 MB |
| Default TDP | 170W |
| Processor Technology for CPU Cores | TSMC 5nm FinFET |
| Processor Technology for I/O Die | TSMC 6nm FinFET |
| CPU Compute Die (CCD) Size | 71mm?? |
| I/O Die (IOD) Size | 122mm?? |
| Package Die Count | 3 |
| Unlocked for Overclocking | Yes |
| AMD EXPO??? Memory Overclocking Technology | Yes |
| Precision Boost Overdrive | Yes |
| Curve Optimizer Voltage Offsets | Yes |
| AMD Ryzen??? Master Support | Yes |
| CPU Socket | AM5 |
| Supporting Chipsets | A620, X670E, X670, B650E, B650 |
| CPU Boost Technology | Precision Boost 2 |
| Instruction Set | x86-64 |
| Supported Extensions | AES, AMD-V, AVX, AVX2, AVX512, FMA3, MMX-plus, SHA, SSE, SSE2, SSE3, SSE4.1, SSE4.2, SSE4A, SSSE3, x86-64 |
| Thermal Solution (PIB) | Not Included |
| Recommended Cooler | Liquid cooler recommended for optimal performance |
| Max. Operating Temperature (Tjmax) | 95??C |
| Launch Date | 09/27/2022 |
| OS Support | Windows 11 - 64-Bit Edition, Windows 10 - 64-Bit Edition, RHEL x86 64-Bit, Ubuntu x86 64-Bit |
| Connectivity |
|
| Graphics Capabilities |
|
| Product IDs |
|
| Key Features |
|
Specification
AMD Ryzen 9 7950X 4.5 GHz AM5 170W Desktop Processor, 16 Cores & 32 Threads, 5.7 GHz Max Boost Clock, 64MB L3 Cache, AMD Radeon Graphics, 2CH -DDR5-6400 / 128GB Max, Zen 4 Arc | 100-100000514WOF
| Category | Specification |
|---|---|
| Name | AMD Ryzen??? 9 7950X |
| Family | Ryzen |
| Series | Ryzen 7000 Series |
| Form Factor | Desktops, Boxed Processor |
| Market Segment | Enthusiast Desktop |
| AMD PRO Technologies | No |
| Consumer Use | Yes |
| Regional Availability | Global |
| Former Codename | Raphael AM5 |
| Architecture | Zen 4 |
| # of CPU Cores | 16 |
| Multithreading (SMT) | Yes |
| # of Threads | 32 |
| Max. Boost Clock | Up to 5.7 GHz |
| Base Clock | 4.5 GHz |
| L1 Cache | 1 MB |
| L2 Cache | 16 MB |
| L3 Cache | 64 MB |
| Default TDP | 170W |
| Processor Technology for CPU Cores | TSMC 5nm FinFET |
| Processor Technology for I/O Die | TSMC 6nm FinFET |
| CPU Compute Die (CCD) Size | 71mm?? |
| I/O Die (IOD) Size | 122mm?? |
| Package Die Count | 3 |
| Unlocked for Overclocking | Yes |
| AMD EXPO??? Memory Overclocking Technology | Yes |
| Precision Boost Overdrive | Yes |
| Curve Optimizer Voltage Offsets | Yes |
| AMD Ryzen??? Master Support | Yes |
| CPU Socket | AM5 |
| Supporting Chipsets | A620, X670E, X670, B650E, B650 |
| CPU Boost Technology | Precision Boost 2 |
| Instruction Set | x86-64 |
| Supported Extensions | AES, AMD-V, AVX, AVX2, AVX512, FMA3, MMX-plus, SHA, SSE, SSE2, SSE3, SSE4.1, SSE4.2, SSE4A, SSSE3, x86-64 |
| Thermal Solution (PIB) | Not Included |
| Recommended Cooler | Liquid cooler recommended for optimal performance |
| Max. Operating Temperature (Tjmax) | 95??C |
| Launch Date | 09/27/2022 |
| OS Support | Windows 11 - 64-Bit Edition, Windows 10 - 64-Bit Edition, RHEL x86 64-Bit, Ubuntu x86 64-Bit |
| Connectivity |
|
| Graphics Capabilities |
|
| Product IDs |
|
| Key Features |
|
