ASUS ROG MAXIMUS Z690 HERO EVA EDITION DDR5 ATX Motherboard, LGA 1700, 4 x DIMM, Max. 128GB, 5 x M.2 slots & 6 x SATA, Intel Wi-Fi 6E, Bluetooth v5.2, AURA Sync | 90MB1BX0-M0EAY0
Model :
SKU : MB-ASUS ROG Z690 HERO EVA
About this item
About this item
Description
The ROG Maximus Z790 Hero EVA Edition is the centerpiece of the "NERV" inspired PC build. This motherboard isn't just a color swap; it is a meticulously themed hardware experience. From the Polymo Lighting on the I/O cover that switches between EVA-01’s "Normal" and "Berserk" modes to the custom-etched NERV branding on the heatsinks, every detail celebrates the legendary anime series while providing the world-class performance expected of the ROG Maximus series.
Elite Performance and Overclocking
Beneath its striking exterior, the EVA Edition is a beast of a motherboard. It features a 20+1 teamed power stage design rated for 90A, providing effortless power to flagship Intel CPUs. To ensure stability during extreme gaming or content creation, it utilizes massive VRM heatsinks, high-conductivity thermal pads, and three integrated M.2 heatsinks. With AI Overclocking and AI Cooling II, the board intelligently balances thermals and clock speeds to maximize your system’s potential.
Next-Gen Connectivity: DDR5 & PCIe 5.0
The Z690 Hero EVA is ready for the future of data. It supports ultra-fast DDR5 memory, significantly increasing bandwidth over previous generations. It also features PCIe 5.0 support on the primary x16 slots and one M.2 slot (via the included ROG Hyper M.2 Card), preparing your rig for the next generation of GPUs and NVMe SSDs. Connectivity is rounded out by onboard WiFi 6E and Intel 2.5Gb Ethernet for lag-free networking.
Customization and Exclusive Software
This limited edition extends the EVA experience into the software. The BIOS features a custom Evangelion-themed interface, and the Armoury Crate software allows you to synchronize the Aura Sync RGB lighting across all your ROG x Evangelion peripherals. With Dual Thunderbolt™ 4 ports on the rear I/O, you can daisy-chain displays and high-speed drives with ease, making this board as functional for professional work as it is for gaming.
--
Why the ROG Maximus Z690 Hero EVA Stands Out
Limited Edition Design: Official Evangelion EVA-01 purple/green colorway and custom graphics.
Polymo Lighting: Exclusive I/O shroud lighting with dual-mode EVA animations.
Extreme Power: 20+1 power stages for rock-solid performance with i9 processors.
Thunderbolt 4: Dual 40Gbps ports for ultimate peripheral connectivity.
Specification
ASUS ROG MAXIMUS Z690 HERO EVA EDITION DDR5 ATX Motherboard, LGA 1700, 4 x DIMM, Max. 128GB, 5 x M.2 slots & 6 x SATA, Intel Wi-Fi 6E, Bluetooth v5.2, AURA Sync Specifications
| CPU | Intel?? Socket LGA1700 for 13th Gen Intel Core & 12th Gen Intel Core, Pentium Gold and Celeron Processors Supports Intel Turbo Boost Technology 2.0 and Intel Turbo Boost Max Technology 3.0 Refer to www.asus.com for CPU support list. Intel?? Turbo Boost Max Technology 3.0 support depends on the CPU types. |
| Chipset | Z690 |
| Memory | 4 x DIMM, Max. 128GB, DDR5 6400+(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(OC)/ 5400(OC)/ 5200(OC)/ 5000(OC)/ 4800 MT/s Non-ECC, Un-buffered Memory* Dual Channel Memory Architecture Supports Intel?? Extreme Memory Profile (XMP) *Actual memory data rate depends on the CPU types and DRAM modules, for more information refer to www.asus.com for the Memory QVL (Qualified Vendors Lists) |
| Graphics | 1 x HDMI port 2 x Intel Thunderbolt 4 ports (USB Type-C) support DisplayPort 1.4 and Thunderbolt video outputs Graphics specifications may vary between CPU types. Please refer to www.intel.com for any updates. Support 4K@60Hz as specified in HDMI 2.1. |
| Expansion Slots | Intel CoreTM Processors (14th & 13th & 12th Gen) 2 x PCIe 5.0 x16 slots (support x16 or x8/x8 modes) Intel Z690 Chipset 1 x PCIe 4.0 x16 slot (supports x4, x4/x4 modes) Please check the PCIe bifurcation table in Chapter 1. When the ROG Hyper M.2 card is installed on PCIEX16(G5)_1, PCIEX16(G5)_2 will run x8 only and if ROG Hyper M.2 card is installed on PCIEX16(G5)_2, PCIEX16(G5)_1 will run x8 only. Supports Intel?? Optane Memory H Series on PCH-attached PCIe slot. |
| Storage | Supports 5 x M.2 slots and 6 x SATA 6Gb/s ports Total supports 5 x M.2 slots and 6 x SATA 6Gb/s ports Intel CoreTM Processors (14th & 13th & 12th Gen) M.2_1 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 4.0 x4 mode.) - Intel 14th & 13th & 12th Gen processors support PCIe 4.0 x4 mode. Hyper M.2_1 slot (Key M) via ROG Hyper M.2 card, type 2242/2260/2280/22110*** - Intel 14th & 13th & 12th Gen processors support PCIe 5.0 x4 mode Intel Z690 Chipset M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 3.0 x4 mode) M.2_3 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 & SATA modes) Hyper M.2_1 slot (Key M) via ROG Hyper M.2 card, type 2242/2260/2280/22110 (supports PCIe 4.0 x4 mode) Hyper M.2_2 slot (Key M) via ROG Hyper M.2 card, type 2242/2260/2280/22110 (supports PCIe 4.0 x4 mode) 6 x SATA 6Gb/s ports Intel Rapid Storage Technology supports NVMe RAID 0/1/5, SATA RAID 0/1/5/10. Intel Rapid Storage Technology supports Intel Optane Memory H Series on PCH attached M.2 slots. When ROG Hyper M.2 card is installed on PCIEX16(G5)_1, Hyper M.2_1 slot can support PCIe 4.0 x4 mode. When ROG Hyper M.2 card is installed on PCIEX16(G5)_2, Hyper M.2_1 slot can support PCIe 5.0 x4 mode. When ROG Hyper M.2 card is installed on PCIEX16(G4), Hyper M.2_1 and Hyper M.2_2 slots can support PCIe 4.0 x4 mode. When ROG Hyper M.2 card is installed on PCIEX16(G5)_1 or PCIEX16(G5)_2, Hyper M.2_2 slot will be disabled. When ROG Hyper M.2 card is installed on PCIEX16(G4), Hyper M.2_1 and Hyper M.2_2 slots can support PCIe 4.0 x4 mode. RAID configuration and boot drives are not supported on the SATA6G_E1-2 ports |
| Ethernet | 1 x Intel 2.5Gb Ethernet ASUS LANGuard |
| Wireless & Bluetooth | Intel Wi-Fi 6E 2x2 Wi-Fi 6E (802.11 a/b/g/n/ac/ax) Supports 2.4/5/6GHz frequency band* Bluetooth v5.2 hardware ready** * WiFi 6E 6GHz regulatory may vary between countries, and function will be ready in Windows 11 or later. |
| USB | Rear USB: Total 11 ports 2 x Thunderbolt 4 ports (2 x USB Type-C) 7 x USB 3.2 Gen 2 ports (6 x Type-A + 1 x USB Type-C) 2 x USB 2.0 ports (2 x Type-A) Front USB: Total 9 ports 1 x USB 3.2 Gen 2x2 connector (supports USB Type-C) 2 x USB 3.2 Gen 1 headers support additional 4 USB 3.2 Gen 1 ports 2 x USB 2.0 headers support additional 4 USB 2.0 ports |
| Audio | ROG SupremeFX 7.1 Surround Sound High Definition Audio CODEC ALC4082 - Impedance sense for front and rear headphone outputs - Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking - High quality 120 dB SNR stereo playback output and 113 dB SNR recording input - Supports up to 32-Bit/384 kHz playback Audio Features: - SupremeFX Shielding Technology - ESS SABRE9018Q2C DAC/AMP - Gold-plated audio jacks - Rear optical S/PDIF out port - Premium audio capacitors - Audio cover |
| Back Panel I/O Ports | 2 x Thunderbolt 4 USB Type-C ports 7 x USB 3.2 Gen 2 ports (6 x Type-A + 1 x USB Type-C) 2 x USB 2.0 ports (2 x Type-A) 1 x HDMI port 1 x Wi-Fi Module 1 x Intel 2.5Gb Ethernet port 5 x Gold-plated audio jacks 1 x Optical S/PDIF out port 1 x BIOS FlashBack button 1 x Clear CMOS button |
| Internal I/O Connectors | Fan and cooling related 1 x 4-pin CPU Fan header 1 x 4-pin CPU OPT Fan header 2 x 4-pin Chassis Fan headers 2 x 4-pin Chassis OPT Fan headers 1 x 4-pin H_AMP Fan header 1 x W_PUMP+ header 1 x W_IN header 1 x W_OUT header 1 x W_FLOW header Power related 1 x 24-pin Main Power connector 1 x 8-pin +12V Power connector 1 x 8-pin +12V Power connector Storage related 1 x M.2 slot (Key M) for PCIe 4.0 x4 mode* 2 x M.2 slots (Key M) for PCIe 3.0 x4 mode 4 x SATA 6Gb/s ports USB 1 x USB 3.2 Gen 2x2 connector (supports USB Type-C) 2 x USB 3.2 Gen 1 headers support additional 4 USB 3.2 Gen 1 ports 2 x USB 2.0 headers support additional 4 USB 2.0 ports Miscellaneous 3 x Addressable Gen 2 headers 2 x AURA RGB headers 1 x ReTry button 1 x Safe Boot button 1 x Start button 1 x FlexKey button 1 x Slow Mode switch 1 x LN2 Mode jumper 1 x TPM header 1 x 20-3 pin System Panel header with Chassis intrude function 1 x Front Panel Audio header (AAFP) 1 x Thunderbolt header |
| Accessories | Cables 1 x ROG CLAVIS DAC 1 x RGB extension cable 1 x 2-in-1 rubber padding 1 x ASUS Wi-Fi moving antennas 1 x Fan bracket Miscellaneous 1 x ROG Hyper M.2 card 1 x ROG key chain 1 x ROG Graphics card holder 1 x ROG Cable ties pack 1 x ROG Strix stickers 1 x ROG Strix thank you card 1 x ROG SSD screw package Installation Media 1 x Support DVD Documentation 1 x User guide |
| BIOS | 1 x 256 Mb Flash ROM, UEFI AMI BIOS |
| Manageability | WOL by PME, PXE |
| Operating System | Windows11, Windows 10 64-bit |
| Form Factor | ATX Form Factor 30.5 cm x 24.4 cm |
