ASUS ROG Rapture GT-AXE16000 Quad-Band WiFi 6E Gaming Router, Quad-Band 6E, Dual 10G Ports, 6GHz Band, Aura RGB, ASUS AiMesh | 90IG06W0-MU2A10
2195.00Home/Networking/Home Networking/Wireless Routers/ASUS RT-AXE7800 Triband WiFi6E Router, 6GHz, 2.5G ...
ASUS RT-AXE7800 Triband WiFi6E Router, 6GHz, 2.5G Port, 7800Mbps, Instant Guard, Parental Control, VPN, AiMesh, Smart Home | 90IG07B0-MU9B00
Model :
SKU : WR-ASUS RT-AXE7800
About this item
Description
ASUS RT-AXE7800 Triband WiFi6E Router, 6GHz, 2.5G Port, 7800Mbps, Instant Guard, Parental Control, VPN, AiMesh, Smart Home | 90IG07B0-MU9B00
| Model | RT-AXE7800 |
| Network Standard | IEEE 802.11a IEEE 802.11b IEEE 802.11g WiFi 4 (802.11n) WiFi 5 (802.11ac) WiFi 6 (802.11ax) WiFi 6E (802.11ax) IPv4 IPv6 |
| Product Segment | AXE7800 ultimate AX performance : 574+4804+2402 Mbps |
| WiFi Data Rate | 802.11a : up to 54 Mbps 802.11b : up to 11 Mbps 802.11g : up to 54 Mbps WiFi 4 (802.11n) : up to 300 Mbps WiFi 5 (802.11ac) : up to 500 Mbps WiFi 5 (802.11ac) (1024QAM) : up to 2167 Mbps WiFi 6 (802.11ax) (2.4GHz) : up to 574 Mbps WiFi 6 (802.11ax) (5GHz) : up to 4804 Mbps WiFi 6E (802.11ax) (6GHz) : up to 2402 Mbps |
| Antenna | External antenna x 6 (non-detachable) |
| Transmit / Receive | 2.4GHz 2x2 5GHz 4x4 6GHz 2x2 |
| Processor | 1.7GHz quad-core processor |
| Memory | 256 MB Flash and 512 MB DDR4 RAM |
| Boosts Speed | OFDMA (Orthogonal Frequency Division Multiple Access) Beamforming: standard-based and universal 1024-QAM high data rate 20/40/80/160 MHz bandwidth |
| Operating Frequency | Tri-band Wi-Fi: 2.4 GHz / 5 GHz / 6 GHz |
| Operating Mode | Router(AiMesh router), AiMesh node, Access point, Repeater, Media bridge |
| I/O Ports | RJ45 for 2.5 Gigabits BaseT for WAN/LAN x 1, RJ45 for Gigabits BaseT for WAN/LAN x 1, RJ45 for Gigabits BaseT for LAN x 3, USB 3.2 Gen 1 Port x 1 |
| Buttons | Power on/off switch Reset Button WPS Button |
| LED Indicator | Power x 1 2.4GHz x 1 5GHz x 1 6HGz x 1 2.5G WAN/LAN1 x 1 1G WAN/LAN1 x 1 1G LAN x 3 |
| Power Supply | AC Input : 110V~240V(50~60Hz) DC Output: 12 V with max. 3.0 A current |
| Package Content | RT-AXE7800 WiFi Router RJ-45 Cable Power Adapter Quick Start Guide Warranty Card |
| Product Weight (g) | 1033g |
| Product Dimensions | 243*223*155 mm |
| AiMesh | Primary AiMesh Router AiMesh Node |
| Parental Control | "Allow you to block access to unwanted websites and apps." Safe Browsing Customized Internet Schedule Maximum Parental Control Profile : 64 Maximum Parental Control Content Cilter Rule : 64 |
| Guest Network | "The Guest Network provides Internet connection for guests but restricts access to your local network." Maximum Guest Network Rule : 2.4 GHz x 3, 5 GHz-1 x 3, 6 GHz x 3 Guest Network Connection Time Limit Guest Network Encryption : Open system, WPA/WPA2/WPA3-Personal, WPS |
| Security | AiProtection WPA3-Personal, WPA2-Personal, WPA-Personal, WPA-Enterprise , WPA2-Enterprise , WPS support Let's Encrypt DNS-over-TLS SSH Security Scan |
| Firewall | Maximum Firewall Keyword Filter : 64 Maximum Firewall Network Service Filter : 32 Maximum Firewall URL Filter : 64 Router Security Assessment Malicious Site Blocking Two-Way IPS Infected Device Prevention and Blocking |
| VPN | Instant Guard VPN Client L2TP VPN Client Open VPN VPN Client PPTP VPN Client WireGuard VPN Server IPSec VPN Server Open VPN VPN Server PPTP VPN Server WireGuard VPN Fusion |
| Traffic Control | Adaptive QoS Bandwidth Monitor Bandwidth Limiter Maximum Bandwidth Limiter Rule : 32 Traditional QoS Maximum Traditional QoS Rule : 32 Traffic Monitor Real-time Traffic Monitor Wired Traffic Monitor Wireless Traffic Monitor Traffic Analyzer Traffic Analysis Period : Daily, Weekly, Monthly Website History |
| WAN | Internet connection Type : PPPoE, PPTP, L2TP, Automatic IP, Static IP Dual WAN WAN Aggregation 3G / 4G LTE dongle Port forwarding Maximum Port Forwarding Rule : 64 Port triggering Maximum Port Triggering Rule : 32 DMZ DDNS NAT Passthrough : PPTP Pass-Through, L2TP Pass-Through, IPSec Pass-Through, RTSP Pass-Through, H.323 Pass-Through, SIP Passthrough, PPPoE relay |
| LAN | DHCP Server IGMP Snooping IPTV LAN Link Aggregation Manually Assign IP Address Maximum Manually Assign IP Address Rule : 64 Wake on LAN (WOL) |
| Wireless | MU-MIMO UTF-8 SSID WiFi MAC Address Filter Maximum MAC Filters : 64 Wireless Scheduler Airtime Fairness RADIUS Client Universal Beamforming Explicit Beamforming |
| USB application | File System : HFS+, NTFS, vFAT, ext2, ext3, ext4 Safely Remove Disk AiCloud Download Master AiDisk Media Server Time Machine Samba Server FTP Server Shared Folder Privileges |
| Administration | Configuration Backup and Restore Diagnosis tools Feedback System System Log New Device Connect Notification Login Captcha Connection Diagnosis Auto Firmware Update |
Specification
ASUS RT-AXE7800 Triband WiFi6E Router, 6GHz, 2.5G Port, 7800Mbps, Instant Guard, Parental Control, VPN, AiMesh, Smart Home | 90IG07B0-MU9B00
| Model | RT-AXE7800 |
| Network Standard | IEEE 802.11a IEEE 802.11b IEEE 802.11g WiFi 4 (802.11n) WiFi 5 (802.11ac) WiFi 6 (802.11ax) WiFi 6E (802.11ax) IPv4 IPv6 |
| Product Segment | AXE7800 ultimate AX performance : 574+4804+2402 Mbps |
| WiFi Data Rate | 802.11a : up to 54 Mbps 802.11b : up to 11 Mbps 802.11g : up to 54 Mbps WiFi 4 (802.11n) : up to 300 Mbps WiFi 5 (802.11ac) : up to 500 Mbps WiFi 5 (802.11ac) (1024QAM) : up to 2167 Mbps WiFi 6 (802.11ax) (2.4GHz) : up to 574 Mbps WiFi 6 (802.11ax) (5GHz) : up to 4804 Mbps WiFi 6E (802.11ax) (6GHz) : up to 2402 Mbps |
| Antenna | External antenna x 6 (non-detachable) |
| Transmit / Receive | 2.4GHz 2x2 5GHz 4x4 6GHz 2x2 |
| Processor | 1.7GHz quad-core processor |
| Memory | 256 MB Flash and 512 MB DDR4 RAM |
| Boosts Speed | OFDMA (Orthogonal Frequency Division Multiple Access) Beamforming: standard-based and universal 1024-QAM high data rate 20/40/80/160 MHz bandwidth |
| Operating Frequency | Tri-band Wi-Fi: 2.4 GHz / 5 GHz / 6 GHz |
| Operating Mode | Router(AiMesh router), AiMesh node, Access point, Repeater, Media bridge |
| I/O Ports | RJ45 for 2.5 Gigabits BaseT for WAN/LAN x 1, RJ45 for Gigabits BaseT for WAN/LAN x 1, RJ45 for Gigabits BaseT for LAN x 3, USB 3.2 Gen 1 Port x 1 |
| Buttons | Power on/off switch Reset Button WPS Button |
| LED Indicator | Power x 1 2.4GHz x 1 5GHz x 1 6HGz x 1 2.5G WAN/LAN1 x 1 1G WAN/LAN1 x 1 1G LAN x 3 |
| Power Supply | AC Input : 110V~240V(50~60Hz) DC Output: 12 V with max. 3.0 A current |
| Package Content | RT-AXE7800 WiFi Router RJ-45 Cable Power Adapter Quick Start Guide Warranty Card |
| Product Weight (g) | 1033g |
| Product Dimensions | 243*223*155 mm |
| AiMesh | Primary AiMesh Router AiMesh Node |
| Parental Control | "Allow you to block access to unwanted websites and apps." Safe Browsing Customized Internet Schedule Maximum Parental Control Profile : 64 Maximum Parental Control Content Cilter Rule : 64 |
| Guest Network | "The Guest Network provides Internet connection for guests but restricts access to your local network." Maximum Guest Network Rule : 2.4 GHz x 3, 5 GHz-1 x 3, 6 GHz x 3 Guest Network Connection Time Limit Guest Network Encryption : Open system, WPA/WPA2/WPA3-Personal, WPS |
| Security | AiProtection WPA3-Personal, WPA2-Personal, WPA-Personal, WPA-Enterprise , WPA2-Enterprise , WPS support Let's Encrypt DNS-over-TLS SSH Security Scan |
| Firewall | Maximum Firewall Keyword Filter : 64 Maximum Firewall Network Service Filter : 32 Maximum Firewall URL Filter : 64 Router Security Assessment Malicious Site Blocking Two-Way IPS Infected Device Prevention and Blocking |
| VPN | Instant Guard VPN Client L2TP VPN Client Open VPN VPN Client PPTP VPN Client WireGuard VPN Server IPSec VPN Server Open VPN VPN Server PPTP VPN Server WireGuard VPN Fusion |
| Traffic Control | Adaptive QoS Bandwidth Monitor Bandwidth Limiter Maximum Bandwidth Limiter Rule : 32 Traditional QoS Maximum Traditional QoS Rule : 32 Traffic Monitor Real-time Traffic Monitor Wired Traffic Monitor Wireless Traffic Monitor Traffic Analyzer Traffic Analysis Period : Daily, Weekly, Monthly Website History |
| WAN | Internet connection Type : PPPoE, PPTP, L2TP, Automatic IP, Static IP Dual WAN WAN Aggregation 3G / 4G LTE dongle Port forwarding Maximum Port Forwarding Rule : 64 Port triggering Maximum Port Triggering Rule : 32 DMZ DDNS NAT Passthrough : PPTP Pass-Through, L2TP Pass-Through, IPSec Pass-Through, RTSP Pass-Through, H.323 Pass-Through, SIP Passthrough, PPPoE relay |
| LAN | DHCP Server IGMP Snooping IPTV LAN Link Aggregation Manually Assign IP Address Maximum Manually Assign IP Address Rule : 64 Wake on LAN (WOL) |
| Wireless | MU-MIMO UTF-8 SSID WiFi MAC Address Filter Maximum MAC Filters : 64 Wireless Scheduler Airtime Fairness RADIUS Client Universal Beamforming Explicit Beamforming |
| USB application | File System : HFS+, NTFS, vFAT, ext2, ext3, ext4 Safely Remove Disk AiCloud Download Master AiDisk Media Server Time Machine Samba Server FTP Server Shared Folder Privileges |
| Administration | Configuration Backup and Restore Diagnosis tools Feedback System System Log New Device Connect Notification Login Captcha Connection Diagnosis Auto Firmware Update |
