ASUS TUF GAMING B760-PLUS WIFI DDR5 ATX Motherboard, 4x DIMM, Max.192GB, 3 x M.2 slots and 4x SATA 6Gb/s, Wi-Fi 6 & BT v5.2 | 90MB1ER0-M0EAY0
Model :
SKU : MB-ASUS TUF B760-PLUS WIF
About this item
About this item
Description
The TUF Gaming B760-PLUS WIFI takes all the essential elements of Intel's latest platform and combines them with game-ready features and proven durability. Utilizing the Intel B760 chipset, it is optimized for the hybrid architecture of Intel's 14th Gen processors, ensuring seamless performance across productivity and gaming. Its rugged industrial aesthetic is backed by TUF Protection, a suite of hardware safeguards that ensure your system survives the rigors of extreme gaming environments.
Reliable Power & Elite Thermal Design
To sustain the clock speeds of Intel's high-performance CPUs, this motherboard features 12+1 DrMOS power stages that combine high-side and low-side MOSFETs into a single package. Cooling is managed by enlarged VRM heatsinks and three dedicated M.2 heatsinks, preventing thermal throttling for both your processor and high-speed NVMe SSDs. A 6-layer PCB design further dissipates heat around critical components to maintain system integrity under heavy load.
Next-Gen Speed: DDR5 and PCIe 5.0
Stay at the forefront of hardware technology with DDR5 memory support. Featuring ASUS-exclusive AEMP II (ASUS Enhanced Memory Profile), this board allows for easy tuning to reach extreme memory frequencies. The primary PCIe 5.0 x16 SafeSlot offers double the bandwidth of the previous generation, making it fully ready for the next generation of flagship graphics cards.
Comprehensive Connectivity & AI Audio
Experience lag-free gaming with WiFi 6 and Realtek 2.5Gb Ethernet, providing high-bandwidth wireless and wired networking. To enhance your team coordination, the board features Two-Way AI Noise Cancelation, which leverages a massive deep-learning database to reduce background noise from your microphone and incoming audio. With Addressable Gen 2 RGB headers, you can synchronize your system's lighting across a vast ecosystem of Aura Sync-compatible gear.
Why the ASUS TUF Gaming B760-PLUS WIFI Stands Out
LGA 1700 Native: Native support for Intel 14th, 13th, and 12th Gen Core desktop processors.
TUF Durability: Military-grade chokes and capacitors for superior temperature tolerance.
PCIe 5.0 Support: Flagship-tier bandwidth for current and future graphics cards.
DDR5 Optimized: Unleash significantly higher data rates compared to DDR4 platforms.
Specification
| Model | TUF GAMING B760-PLUS WIFI |
| News & Updates | 2024/08/12: The new BIOS with Intel microcode (0x129) enhancing the stability of Intel Core 13th and 14th Gen desktop processors is now available. Please visit the support site for the latest BIOS updates. |
| CPU | Intel Socket LGA1700 for Intel Core 14th & 13th Gen Processors, Intel Core 12th Gen, Pentium Gold and Celeron Processors Supports Intel Turbo Boost Technology 2.0 and Intel Turbo Boost Max Technology 3.0. Refer to www.asus.com for CPU support list. Intel Turbo Boost Max Technology 3.0 support depends on the CPU types. |
| Chipset | Intel B760 Chipset |
| Memory | 4 x DIMM, Max. 192GB, DDR5 Speed: 7200(OC)/7000(OC)/6800(OC)/6600(OC)/6400(OC)/6200(OC)/6000(OC)/5800(OC)/5600/5400/5200/5000/4800 Non-ECC, Un-buffered Memory, Dual Channel Memory Architecture Supports Intel Extreme Memory Profile (XMP), OptiMem II Supported memory types and configurations vary. Refer to CPU/Memory Support under the Support tab on www.asus.com. |
| Graphics | 1 x DisplayPort (max. 4K@60Hz, DisplayPort 1.4) 1 x HDMI port (max. 4K@60Hz, HDMI 2.1) Graphics specifications may vary based on CPU type. |
| Expansion Slots | Intel Core Processors: - 1 x PCIe 5.0 x16 slot Intel B760 Chipset: - 1 x PCIe 3.0 x16 slot (x4 mode) - 2 x PCIe 3.0 x1 slots PCIEX16(G3) shares bandwidth with PCIEX1 slots. Refer to the compatibility list on the support page. |
| Storage | 3 x M.2 slots, 4 x SATA 6Gb/s ports Intel Core Processors: - M.2_1: PCIe 4.0 x4 mode Intel B760 Chipset: - M.2_2: PCIe 4.0 x4 mode - M.2_3: PCIe 4.0 x4 mode Supports Intel Rapid Storage Technology with SATA RAID 0/1/5/10. |
| Ethernet | 1 x Realtek 2.5Gb Ethernet with TUF LANGuard |
| Wireless & Bluetooth | Wi-Fi 6 (802.11 a/b/g/n/ac/ax, 2x2) supporting 2.4/5GHz Bluetooth v5.2 |
| USB Ports | Rear USB (6 Ports): - 1 x USB 3.2 Gen 2x2 (Type-C) - 1 x USB 3.2 Gen 2 (Type-A) - 3 x USB 3.2 Gen 1 (Type-A) - 1 x USB 2.0 (Type-A) Front USB (7 Ports): - 1 x USB 3.2 Gen 2 (Type-C) - 2 x USB 3.2 Gen 1 (via header) - 4 x USB 2.0 (via 2 headers) |
| Audio | Realtek 7.1 Surround Sound High Definition Audio CODEC Audio Features: - Audio Shielding - Premium audio capacitors - Rear optical S/PDIF out port - Dedicated audio PCB layers |
| Form Factor | ATX (12 inch x 9.6 inch / 30.5 cm x 24.4 cm) |
