Asus Tuf Gaming X670E-Plus Wifi ATX DDR5 Motherboard, Socket AM5, Max 128GB Memory, PCIe 5.0, AMD X670 Chipset, Tuf LAN Guard, Wi-Fi 6E, Bluetooth v5.2, Realtek 2.5Gb Ethernet | 90MB1BK0-M0EAY0

• 1 x DisplayPort
• 1 x HDMI?? port

AMD Ryzen??? 7000 Series Desktop Processors*

• 1 x PCIe 5.0 x16 slot

AMD X670 Chipset

• 1 x PCIe 4.0 x16 slot (supports x4 mode)
• 1 x PCIe 4.0 x4 slots

Total supports 4 x M.2 slots and 4 x SATA 6Gb/s ports*

AMD Ryzen??? 7000 Series Desktop Processors

• M.2_1 slot (Key M), type 2242/2260/2280 (supports PCIe 5.0 x4 mode)
• M.2_3 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode)

AMD X670 Chipset

• M.2_2 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 3.0 x4 & SATA modes)**
• M.2_4 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode)
• 4 x SATA 6Gb/s ports

Wi-Fi 6E

• 2x2 Wi-Fi 6E (802.11 a/b/g/n/ac/ax)

Bluetooth v5.2

Rear USB (Total 10 ports)

• 1 x USB 3.2 Gen 2x2 port (1 x USB Type-C??)
• 4 x USB 3.2 Gen 2 ports (3 x Type-A + 1 x USB Type-C??)
• 5 x USB 3.2 Gen 1 ports (5 x Type-A)

Front USB (Total 9 ports)

• 1 x USB 3.2 Gen 2 connector (supports USB Type-C??)
• 1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports
• 3 x USB 2.0 headers support additional 6 USB 2.0 ports

Realtek S1220A 7.1 Surround Sound High Definition Audio CODEC*

• Impedance sense for front and rear headphone outputs
• Internal audio Amplifier to enhance the highest quality sound for headphone and speakers
• Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking
• High quality 120 dB SNR stereo playback output and 113 dB SNR recording input (Line-in)

• 1 x USB 3.2 Gen 2x2 port (1 x USB Type-C??)
• 4 x USB 3.2 Gen 2 ports (3 x Type-A, 1 x USB Type-C??)
• 5 x USB 3.2 Gen 1 ports (5 x Type-A)
• 1 x DisplayPort
• 1 x HDMI?? port
• 1 x Wi-Fi Module
• 1 x Realtek 2.5Gb Ethernet port
• 5 x Audio jacks
• 1 x BIOS FlashBack??? button

• 1 x 4-pin CPU Fan header
• 1 x 4-pin CPU OPT Fan header
• 1 x 4-pin AIO Pump header
• 4 x 4-pin Chassis Fan headers
• 1 x W_PUMP+ header
• 1 x 24-pin Main Power connector
• 2 x 8-pin +12V Power connectors
• 4 x M.2 slots (Key M)
• 4 x SATA 6Gb/s ports

• 3 x Addressable Gen 2 headers
• 1 x AURA RGB header
• 1 x Clear CMOS header
• 1 x COM Port header
• 1 x Front Panel Audio header (AAFP)
• 1 x 20-3 pin System Panel header with Chassis intrude function
• 1 x Thermal Sensor header
• 1 x Thunderbolt??? header

• TUF PROTECTION
• ASUS Q-Design
• ASUS Thermal Solution
• ASUS EZ DIY
• AURA Sync

• ASUS Exclusive Software
• TUF GAMING CPU-Z
• DTS Audio Processing
• MyAsus
• Norton Anti-virus software (Free Trial version)
• WinRAR
• UEFI BIOS

• 2 x SATA 6Gb/s cables
• 1 x ASUS Wi-Fi moving antenna
• 2 x Rubber packages for M.2
• 2 x Screw packages for M.2 SSD
• 1 x TUF certification card
• 1 x User guide
