Cooler Master X Silent Mighty 2000W ATX 3.1 Powersupply, 80 Plus Platinum, Active PFC, Dual GPU support | MPS-K001-AFBP-NBUK
Model :
SKU : PS-COOLERMSTR X MGTY 2000
About this item
0
Inclusive of VAT
Delivery to
FREE scheduled delivery as soon as Loading...
Sold and shipped by: Adarc computers
1
About this item
Description
The X Mighty Platinum is a powerhouse blending high-capacity performance, top-tier industrial-grade IC components, and sophisticated interleaved PFC topology. This PSU is engineered to meet the demanding needs of server and artificial intelligence industries, featuring dual 12V-2x6 connectors designed for rigorous, high-performance applications.
Specification
| Model | MPS-K001-AFBP |
| ATX Version | ATX 12V Ver. 3.1 |
| PFC | Active PFC |
| Input Voltage | 115 - 240V (115 - 240V for 1600W / 200 - 240V for 2000W) |
| Input Current | 16A (Max) |
| Input Frequency | 50-60Hz |
| Dimensions (L x W x H) | 180 x 150 x 86 mm |
| Fan Size | 120mm |
| Fan Bearing | FDB |
| Fan Speed | 2500 RPM |
| Efficiency | ≥ 94% @ Typical Load |
| 80 PLUS Rating | 80 PLUS Platinum of EU Internal |
| ErP 2014 Lot 3 | Yes |
| Operating Temperature | 0-50°C |
| Power Good Signal | 100 - 150 ms |
| Hold Up Time | ≥ 16ms |
| MTBF | >100,000 Hours |
| Protections | OPP / OVP / OTP / OCP / SCP / UVP / Surge & Inrush Protection |
| Regulatory | cUL, TUV, CE, FCC, BSMI, CCC, EAC, RCM, UKCA/BIS, KC (based on region's request.) |
| ATX 24 Pin Connectors | 1 |
| EPS 4+4 Pin Connectors | 1 |
| EPS 8 Pin Connector | 1 |
| SATA Connectors | 12 |
| Peripheral 4 Pin Connectors | 4 |
| PCI-e 6+2 Pin Connectors | 4 |
| 12V-2x6 Connectors | 2 |
| USB 10P Connector | 1 |
| PMBus 5 Pin Connector | 1 |
| Series | X Series |
| 80 Plus Efficiency | Platinum |
| Modular | Fully Modular |
| Category | Above 750W |
| Form Factor | ATX |
| Watts | 2000W |
