The D-Link DAP-2695 AirPro AC1750 Dual-Band Access Point is engineered to provide high-speed, reliable wireless networking for business environments. Whether deployed in offices, schools, or hospitality venues, this access point handles high-volume traffic with ease, utilizing 802.11ac technology to deliver a superior user experience. Its robust design and advanced management features make it an essential component for any modern enterprise network.
Key Features
Equipped with six high-gain external antennas, the DAP-2695 provides extensive coverage and minimizes dead zones. It supports concurrent dual-band operation, allowing legacy devices to connect via the 2.4 GHz band while newer, high-bandwidth applications utilize the less congested 5 GHz band. For enhanced network efficiency, it features Band Steering and Airtime Fairness, ensuring that every connected client receives optimal throughput without slowing down the entire network.
Performance / Technology
The DAP-2695 delivers combined wireless speeds of up to 1750 Mbps (450 Mbps on 2.4 GHz and 1300 Mbps on 5 GHz). It features two Gigabit LAN ports, one of which supports 802.3at PoE+ for power and data delivery over a single cable, simplifying deployments in areas without easy access to power outlets. The unit is encased in a plenum-rated metal housing, making it compliant with fire safety regulations for installation in ceiling spaces.
Design & Ergonomics
Designed for versatility, the DAP-2695 can be wall or ceiling mounted using the included hardware. Its rugged metal chassis is built for durability, while the detachable antenna design allows for customization based on specific environmental needs. The clean, professional aesthetic ensures it blends seamlessly into office or campus corridors, maintaining a low-profile presence while providing high-performance connectivity.
Compatibility / Use Cases
This access point is ideal for high-density settings such as conference rooms, libraries, and open-plan offices where multiple users connect simultaneously. It supports multiple operation modes, including Access Point, Wireless Distribution System (WDS), and Wireless Client, providing flexibility for network expansion. With support for up to 16 SSIDs, administrators can easily segment user traffic for guests, employees, and management to maintain strict security protocols.
Why This Product Stands Out
The D-Link DAP-2695 stands out by offering a plenum-rated, business-class hardware solution at a competitive price point. Unlike consumer-grade hardware, it offers advanced security features like WPA2-Enterprise, MAC address filtering, and Rogue AP detection. Its ability to be managed as a standalone device or as part of a larger managed network via D-Link's Central WiFiManager or Nuclias solutions makes it a future-proof investment for growing businesses.
| Category | Details |
|---|---|
| Device Interfaces | 802.11a/b/g/n/ac wireless1 RJ45 console port 2 Gigabit LAN Port (one port supporting 802.3at PoE) |
| LEDs | Power LAN 2.4 GHz wireless 5 GHz wireless |
| Standards | IEEE 802.11a/b/g/n/ac1 IEEE 802.3u/ab/af |
| Wireless Frequency Range | 2.4 GHz band: 2.4 GHz to 2.4835 GHz 5 GHz band: 5.15 to 5.35 GHz, 5.47 to 5.85 GHz3 |
| Antennas | Three 4 dBi for 2.4 GHz Three 6 dBi for 5 GHz |
| Security | WPA-Personal WPA-Enterprise WPA2-Personal WPA2-Enterprise WEP 64/128-bit encryption SSID broadcast disable MAC address access control Network Access Protection (NAP) Internal RADIUS server |
| Network Management | Telnet Secure Telnet (SSH) HTTP Secure HTTP (HTTPS) Traffic control SNMP D-View module - private MIB Nuclias Connect Software Nuclias Connect Hub5 |
| Physical Dimensions | 190 x 36.5 x 198.8 mm (7.48 x 1.44 x 7.82 inches) |
| Weight | 1140 grams (2.52 lbs) with antennas |
| Operating Voltage | 48 V DC +/- 10% (power adapter not included) PoE+ (802.3at) |
| Maximum Transmit Output Power | FCC at 2.4 GHz: 26 dBm/ETSI: 15 dBm (Dual Chain) FCC at 5 GHz: 26.5 dBm/ETSI: 23.5 dBm (Dual Chain) |
| Temperature | Operating: 0 to 40 ??C (32 to 104 ??F) Storage: -20 to 65 ??C (-4 to 149 ??F) |
| Humidity | Operating: 10% to 90% non-condensing Storage: 5% to 95% non-condensing |
| Certifications | FCC IC CE UL Wi-Fi?? Cert |
