H90 Dual-Lens 2K+ (CS-H90) represents a significant leap in indoor surveillance, moving beyond the limitations of single-lens cameras to provide "Ultra-Flexible Vision." Featuring two independent 4MP sensors, this camera allows you to monitor two separate fields of view at the same time—such as a nursery crib and the room's entrance—in stunning 2K+ resolution. This dual-stream capability ensures that you never have to choose between a wide overview and a detailed close-up, providing clinical clarity across your entire living space.
Key Features The standout feature of the H90 is its co-linked dual-lens system. While the bottom lens remains fixed to maintain a constant wide-angle overview, the top lens can pan and tilt 360 degrees to track movement or focus on specific details. The camera is equipped with on-device AI algorithms that specifically identify human shapes and pet activity, drastically reducing false notifications. It also features "Auto-Tracking" across both lenses, where the motorized lens automatically follows a moving subject identified by the wide-angle view.
Performance / Technology Connectivity is powered by a high-performance Wi-Fi system designed to handle the dual 4MP video feeds without latency. For nighttime security, the H90 utilizes Smart Color Night Vision, which uses integrated spotlights to render vivid colors in total darkness. The system supports H.265 video compression, which optimizes storage efficiency and reduces network load. The integrated two-way talk system provides crisp, real-time communication, allowing you to interact with family or pets effortlessly via the EZVIZ app.
Design & Ergonomics The H90 features a modern, architectural design with a clean white finish that integrates seamlessly into any upscale interior decor. Its flexible mounting base allows for effortless installation on tabletops, walls, or ceilings. To ensure total peace of mind, the camera includes a physical privacy shutter—with a single tap in the app, the lenses rotate out of view, providing complete visual privacy when you are at home.
Compatibility / Use Cases This high-capacity dual camera is the ideal solution for large open-plan living rooms, home offices, and as a comprehensive baby or pet monitor. It is fully compatible with the EZVIZ smart ecosystem and supports voice control via Amazon Alexa and Google Assistant. With support for massive 512GB local storage and secure CloudPlay encrypted backups, your high-resolution security data is always protected and easily retrievable.
Why This Product Stands Out The EZVIZ H90 stands out by providing a "Two-in-One" camera experience that effectively eliminates blind spots. While traditional cameras lose context when they pan away, the H90’s fixed lens keeps the big picture in sight while the PT lens investigates details. Its combination of 2K+2K resolution, AI-driven intelligence, and massive storage capacity makes it one of the most versatile and advanced indoor security solutions available in 2026.
| Model | CS-H90-R100-8H44WKFL |
| Image Sensor | 1/3" Progressive Scan CMOS |
| Shutter Speed | Self-adaptive shutter |
| Lens | Top Lens: 2.8mm @ F1.6, Field of view: Diagonal 110, Horizontal 96, Vertical 54 Bottom Lens: 6mm @ F1.6, Field of view: Diagonal 60, Horizontal 52, Vertical 28 |
| PT Angle | Pan: 324, Tilt: 90 |
| Minimum Illumination | 0.5 Lux @(F1.6, AGC ON), 0 Lux with IR (EZVIZ laboratories data) |
| Lens Mount | M12 |
| Day & Night | IR-cut filter with auto switch |
| DNR | 3D DNR |
| WDR | Digital WDR |
| Black & White Night Vision | 30 m (98 ft) |
| Max Resolution | 2K+ (2880 1620) |
| Frame Rate | Max: 15fps; Self-Adaptive during network transmission |
| Video Compression | H.265 / H.264 |
| H.265 Type | Main Profile |
| Video Bit Rate | Ultra-HD; Hi-Def; Standard. Adaptive bit rate. |
| Audio Bit Rate | Self-Adaptive |
| Wi-Fi Standard | IEEE802.11b, 802.11g, 802.11n |
| Frequency Range | 2.4 GHz ~ 2.4835 GHz |
| Channel Bandwidth | Supports 20MHz |
| Security | WPA-PSK/WPA2-PSK |
| Transmission Rate | 11b 11 Mbps, 11g 54 Mbps, 11n: 150 Mbps |
| Wi-Fi Pairing | AP pairing |
| Protocol | EZVIZ cloud proprietary protocol |
| Wired Network | RJ45 1 (10M / 100M Adaptive Ethernet Port) |
| Smart Alarm | - AI-powered human shape detection - AI-powered vehicle shape detection - Motion detection |
| Auto Tracking | Supports |
| Customized Alert Area | Supports |
| Two-way Talk | Supports |
| Preset Locations | Supports |
| General Function | Anti-Flicker, Dual-Stream, Heart Beat, Password Protection, Watermark |
| Local Storage | Supports microSD card (max. 512 GB) |
| Cloud Storage | Supports EZVIZ CloudPlay storage (subscription required) |
| Operating Conditions | -30C to 50C (-22F to 122F), Humidity 95% or less (non-condensing) |
| IP Grade | Weatherproof Design |
| Power Supply | IP65 + 2h rainstorm |
| Power Consumption | MAX. 18W |
| Dimensions | 224 135 136 mm (8.82 5.31 5.35 inch) |
| Packaging Dimensions | 255 176 194 mm (10.04 6.93 7.64 inch) |
| Weight | Net weight: 723 g (25.51 oz) With Package: 1203 g (42.43 oz) |
| In the Box | - H90 Dual 2K+ Camera - Power Adapter - Drill Template - Waterproof Kit - Screw Kit - Regulatory Information 2 - Quick Start Guide |
| Certifications | CE / UL / WEEE / RoHS / REACH |
