Face two directions, but follow the same activity
Even if the two lenses are set on opposite viewing angles to secure two different areas, they can complete a single smart tracking task through teamwork. When a human is detected by the upper lens, the PT lens will automatically rotate to such angle to lock on the person and record the whole activity.
Key Features
The standout feature of the H9c Dual is its co-linked dual-lens system. The upper lens is a motorized pan-tilt unit that provides a total overview, while the lower fixed lens focuses on a specific high-priority area. When the upper lens detects a human or vehicle through its advanced AI algorithms, it can automatically track and zoom in up to 8x to identify the subject. This intelligent coordination ensures that critical events are captured with the necessary detail for identification.
Performance / Technology
Connectivity is powered by a high-gain dual-antenna system, ensuring a stable 2K stream even through thick exterior walls. For nighttime security, the H9c Dual features four built-in spotlights to deliver vivid Color Night Vision, alongside traditional IR modes for discreet monitoring. The camera utilizes H.265 video compression, which optimizes bandwidth and storage efficiency by up to 50%, allowing you to get the most out of your high-resolution footage and local storage capacity.
Design & Ergonomics
The H9c Dual features a rugged, weatherproof housing designed to withstand extreme temperatures, dust, and heavy rain. Its spherical "Two-in-One" design is both modern and functional, offering a clean installation on walls or under eaves. The integrated Two-Way Talk system features high-fidelity audio, allowing you to speak to visitors or warn off trespassers in real-time. Additionally, the camera includes an active defense system with a loud siren and flashing lights to deter intruders instantly.
Compatibility / Use Cases
This high-performance outdoor camera is the ideal solution for protecting large driveways, commercial parking lots, and expansive residential perimeters. It integrates perfectly with the EZVIZ app ecosystem and supports voice control via Amazon Alexa and Google Assistant. With support for massive local MicroSD storage (up to 512GB) and encrypted CloudPlay backups, your security history is always protected and easily retrievable for review.
Why This Product Stands Out
The EZVIZ H9c Dual stands out by offering a "Master-Slave" lens configuration that effectively replaces two separate cameras. While standard pan-tilt cameras might miss activity in one direction while facing another, the H9c’s dual-vision ensures constant vigilance. Its combination of 2K resolution, 8x mixed zoom, and AI vehicle detection makes it one of the most versatile and robust outdoor security tools available in 2026.
| Model | CS-H9c-R100-8H33WKFL |
| Image Sensor | 1/2.7" Progressive Scan CMOS |
| Shutter Speed | Self-adaptive shutter |
| Lens | Upper Camera: 2.8mm@ F1.6, viewing angle: Diagonal 130, Horizontal 108, Vertical 56 Bottom Camera: [email protected], viewing angle: Diagonal 62, Horizontal 55, Vertical 28 |
| PT Angle | Pan: 350, Tilt: 80 |
| Minimum Illumination | 0.5 Lux @(F1.6, AGC ON), 0 Lux with IR (*data is obtained from EZVIZ laboratories) |
| Lens Mount | M12 |
| Day & Night | IR-cut filter with auto-switching |
| DNR | 3D DNR |
| WDR | Digital WDR |
| Black & White Night | 30m / 98ft |
| Max Resolution | 2304 1296 |
| Frame Rate | Max: 15fps; Self-Adaptive during network transmission |
| Video Compression | H.265 / H.264 |
| H.265 Type | Main Profile |
| Video Bit Rate | Quad HD, Full HD, Hi Def, Standard. Adaptive bit rate. |
| Audio Bit Rate | Self-Adaptive |
| Wi-Fi Standard | IEEE802.11b, 802.11g, 802.11n |
| Frequency Range | 2.4 GHz ~ 2.4835 GHz |
| Channel Bandwidth | Supports 20MHz |
| Transmission Rate | 11b 11 Mbps, 11g 54 Mbps, 11n: 150 Mbps |
| Wi-Fi Pairing | AP pairing |
| Protocol | EZVIZ cloud proprietary protocol |
| Interface Protocol | EZVIZ cloud proprietary protocol |
| Wired Network | RJ45 1 (10M / 100M Adaptive Ethernet Port) |
| Security | WPA-PSK/WPA2-PSK |
| Smart Alarm | AI-Powered Human Shape Detection / AI-Powered Vehicle Shape Detection / Motion Detection |
| Auto Tracking | Supports |
| Customized Alert Area | Supports |
| Two-way Talk | Supports |
| Preset Locations | Supports |
| General Function | Anti-Flicker, Dual-Stream, Heart Beat, Password Protection, Watermark |
| Local Storage | Supports microSD Card (Up to 512 GB) |
| Cloud Storage | Supports EZVIZ CloudPlay storage |
| Operating Conditions | -30C to 50C ( -22 F to 122 F ) Humidity 95% or less (non-condensing) |
| IP Grade | Weatherproof Design |
| Power Supply | DC 12V/1.5A |
| Power Consumption | MAX. 12W |
| Dimensions | 145 116 142mm (5.71 4.57 5.59 inch) |
| Packaging Dimensions | 150 150 194mm (5.90 5.90 7.64 inch) |
| Weight | Net Weight: 668 g With Package: 960 g |
| In the Box | - H9c Camera - Drill Template - Screw Kit - Waterproof Kit - Power Adapter - Regulatory Information - Quick Start Guide |
| Certifications | CE / WEEE / RoHS / REACH |
