| Frame | Glass fiber reinforced (20-30%) PP/PA |
| Seat | Cold cured foam (Mesh: Mesh) |
| Back | Cold cured foam (Mesh: Mesh) |
| Headrest | Memory foam |
| Wheelbase | Aluminum |
| Casters | Hubless 65 mm with soft PU wheels |
| Gas Piston | 120 mm Class 4 |
| Mechanism | Synchro-tilt |
| Armrests | Plastic cover with aluminum mechanism and steel bracket |
| Arm Caps | Soft PU foam with TPU cover |
| Lumbar Support | Height and depth adjustable |
| Fabric Cover | Mesh: Nylon reinforced mesh, Fabric: Woven non-organic fabric, Alcantara®: Alcantara® |
| Seat Height (from floor) | 475 mm – 595 mm (Mesh: 490 mm – 610 mm) |
| Seat Depth | 425 mm – 480 mm (Mesh: 450 mm – 505 mm) |
| Armrest Height (from seat) | 160 mm – 270 mm (Mesh: 145 mm – 255 mm) |
| Armrest to Armrest | 420 mm – 560 mm (Mesh: 430 mm – 560 mm) |
| Armrest Rotation Adjustability | ±15° |
| Armrest Depth Adjustability | 60 mm |
| Lumbar Support Height Adjustability | 110 mm |
| Lumbar Support Depth Adjustability | 20 mm |
| Max Back Tilt | 125° (~130° under load) |
| Tilt Mechanism | Donati Dynamic |
| Back/Seat Tilt Ratio | 2:1 |
| Lockable Tilt Positions | 11 |
| Free Tilt | Yes |
| Headrest Height Adjustability | 120 mm |
| Headrest Width | 210 mm |
| Headrest Depth | 80 mm |
| Headrest Height | 185 mm |
| Lumbar Support Pad Height | 110 mm |
| Lumbar Support Pad Width | 260 mm |
| Seat Pad Width | 540 mm (Mesh: 550 mm) |
| Seat Pad Depth | 460 mm (Mesh: 465 mm) |
| Seat Width (between seams) | 435 mm |
| Arm Cap Length | 250 mm |
| Arm Cap Width | 110 mm |
| Back Height (from floor) | 1340 mm – 1465 mm |
| Back Height (from seat) | 875 mm (Mesh: 860 mm) |
| Back Width | 530 mm |
| Caster Size | 65 mm |
| Wheelbase Diameter | 700 mm |
| Certifications | Bifma X5.1, EN1335-1 , BS5852 OR CAL TB 117 + EN1021-1/-2 |
| Weight Capacity | 125 kg |
| Warranty | 5 years (mechanical parts), 3 years (upholstery and cover material, including fabric and mesh) |
| Recommended User Height | 1.65 m – 2.0 m |
| Recommended User Weight | 60 kg – 125 kg |
| Net Weight | 25.7 kg (Alcantara®: 25.8 kg) |
| Gross Weight | 35.7 kg (Alcantara®: 35.8 kg) |
| Package Dimensions (LxWxH) | 107 x 68 x 39 cm |
| Package Contents | Seat base with synchro-tilt mechanism, backrest with built-in lumbar support, wheelbase, headrest, Large Accessory Box, Quick Start Guide, Designers' Note with envelope |
| Large Accessory Box Contents | Gas lift, casters (5x), Small Accessory Box, armrests (2x), User Manual, Red Stop Note |
| Small Accessory Box Contents | Allen Key, 6x screws for armrest, 2x screws for backrest |
| EAN | Mesh Dark: 843276106683, Mesh Light: 7340172706694, Mesh Dark (UK): 7340172706700, Mesh Light (UK): 7340172706717, Fabric Dark: 7340172706724, Fabric Light: 7340172706731, Fabric Dark (UK): 7340172706748, Fabric Light (UK): 7340172706755, Alcantara®: 7340172706762, Alcantara® (UK): 7340172706779 |
| UPC | Mesh Dark: 843276106683, Mesh Light: 843276106690, Mesh Dark (UK): 843276106706, Mesh Light (UK): 843276106713, Fabric Dark: 843276106720, Fabric Light: 843276106737, Fabric Dark (UK): 843276106744, Fabric Light (UK): 843276106751, Alcantara®: 843276106768, Alcantara® (UK): 843276106775 |
| JAN | Mesh Dark: 4537694341820, Mesh Light: 4537694341837, Mesh Dark (UK): 4537694341844, Mesh Light (UK): 4537694341851, Fabric Dark: 4537694341868, Fabric Light: 4537694341875, Fabric Dark (UK): 4537694341882, Fabric Light (UK): 4537694341899, Alcantara®: 4537694341905, Alcantara® (UK): 4537694341912 |
| Product Code | Mesh Dark: FD-CH-RE1M-01, Mesh Light: FD-CH-RE1M-02, Mesh Dark (UK): FD-CH-RE1M-03, Mesh Light (UK): FD-CH-RE1M-04, Fabric Dark: FD-CH-RE1F-01, Fabric Light: FD-CH-RE1F-02, Fabric Dark (UK): FD-CH-RE1F-03, Fabric Light (UK): FD-CH-RE1F-04, Alcantara®: FD-CH-RE1A-01, Alcantara® (UK): FD-CH-RE1A-02 |
