Brand | GIGABYTE / AORUS |
Model | X870 AORUS INFINITY |
Form Factor | E-ATX (30.5 × 27.5 cm) |
CPU Socket | AMD Socket AM5 |
Supported Processors | AMD Ryzen™ 9000, 8000, and 7000 Series Processors |
Chipset | AMD X870 |
Memory Slots | 2× DDR5 DIMM Sockets (Dual-Channel Architecture) |
Max Memory Capacity | Up to 128 GB (Up to 64 GB per DIMM) |
Memory Speeds | Up to DDR5 11400+ MT/s (OC); Supports non-ECC Unbuffered DIMM, AMD EXPO™, Intel XMP |
Primary PCIe Slots | 1× PCIe 5.0 x16 (PCIEX16 from CPU; operates at x16 or x8 when shared)
1× PCIe 5.0 x16 (PCIEX8 from CPU; runs at x8 mode) |
M.2 Storage Slots | 3× M.2 Slots: 1× M.2 PCIe 5.0 x4/x2 (M2A_CPU, 25110/22110/2580/2280) 1× M.2 PCIe 5.0 x4/x2 (M2B_CPU, 22110/2280; shares bandwidth with USB4) 1× M.2 PCIe 4.0 x4/x2 (M2D_SB from Chipset, 22110/2280) |
SATA Ports | 4× SATA 6Gb/s |
RAID Support | NVMe: RAID 0, 1, 5 (Ryzen 9000 only), 10 SATA: RAID 0, 1, 10 |
Display Outputs | 1× USB4® Type-C (DP 1.4 with HDR, up to 3840×2160 @ 240 Hz) 1× Rear HDMI 2.1 (up to 4096×2160 @ 60 Hz) 1× Internal HDMI 1.4 (up to 1920×1080 @ 30 Hz for sensor panel) |
Wired Network (LAN) | Realtek® 5GbE LAN (5 Gbps / 2.5 Gbps / 1 Gbps / 100 Mbps) |
Wireless & Bluetooth | Qualcomm® Wi-Fi 7 QCNCM865 (802.11be, 2.4/5/6 GHz, 320 MHz) + Bluetooth 5.4 |
Audio CODEC | Realtek® ALC1220 CODEC + DTS:X® Ultra (2/4/5.1/7.1-Channel, DSD Audio Support) |
Audio Ports | 2× Audio Jacks, 1× Optical S/PDIF Out Connector |
Rear USB Ports | 1× USB4® Type-C (with DP), 3× USB 3.2 Gen 2 Type-A (red), 4× USB 3.2 Gen 1 |
Front/Internal USB Headers | 1× USB Type-C (USB 3.2 Gen 2x2 with 65W PD 3.0 / QC 4+ Fast Charging), 1× USB 3.2 Gen 1 (supports 2 ports), 2× USB 2.0/1.1 (supports 4 ports) |
Dedicated OC & Hardware Controls | Power, Reset, Clear CMOS, Cold Reset (RTY), ECLK+ / ECLK- Buttons, OC Ignition, Q-Flash Plus, Dual BIOS Switch, OC Trigger Switch, Voltage Measurement Points |
Cooling & Sensor Headers | 1× CPU fan, 1× CPU fan/pump, 4× system fan, 2× fan/pump headers, 2× temperature sensor headers |
RGB Lighting Headers | 3× Addressable RGB Gen2 Headers, 1× Standard RGB Header |
Legacy Ports | 1× PS/2 Keyboard Port, 1× PS/2 Mouse Port |
Power Connectors | 1× 24-pin ATX Main Power, 2× 8-pin ATX 12V Power, 1× PCIe Supplemental Power |
BIOS | 2× 512 Mbit Flash ROM, AMI UEFI BIOS (DualBIOS™ Architecture) |
Operating System Support | Windows 11 64-bit |
