Gigabyte B850M D3HP AM5 ATX Motherboard, 4x DIMMs with AMD EXPO, Upto DDR5 8200(OC), 2x M.2 slots, 1x PCIe 5.0 x4, GbE LAN, EZ-Latch | B850M D3HP
Model :
SKU : MB-GIGABYTE B850M D33HP
0
Inclusive of VAT
Delivery to
FREE scheduled delivery as soon as Loading...
Sold and shipped by: Adarc computers
1
About this item
Description
Gigabyte B850M D3HP AM5 ATX Motherboard, 4x DIMMs with AMD EXPO, Upto DDR5 8200(OC), 2x M.2 slots, 1x PCIe 5.0 x4, GbE LAN, EZ-Latch | B850M D3HP Specifications
| CPU | AMD Socket AM5, support for AMD Ryzen??? 9000/8000/7000 Series Processors |
| Chipset | AMD B850 |
| Memory |
Support for DDR5 8200(OC) / 8000(OC) / 7800(OC) / 7600(OC) / 7200(OC) / 7000(OC)/6800(OC) / 6666(OC) / 6600(OC) / 6400(OC) / 6200(OC) / 6000(OC) / 5600(OC) / 5200 / 4800 / 4400 MT/s 4 x DDR5 DIMM sockets supporting up to 256 GB (64 GB single DIMM capacity) Dual channel memory architecture Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules Support for AMD EXtended Profiles for Overclocking (AMD EXPO???) and XMP |
| Onboard Graphics |
Integrated Graphics Processor with AMD Radeon??? Graphics support: - 1 x HDMI port, max resolution 4096x2160@60Hz - 2 x DisplayPorts, max resolution 3840x2160@144Hz * Supports up to triple-display simultaneously |
| Audio |
Realtek?? Audio CODEC High Definition Audio 2/4/5.1/7.1-channel support |
| LAN | Realtek?? GbE LAN chip (1 Gbps/100 Mbps/10 Mbps) |
| Expansion Slots |
1 x PCI Express x16 slot (PCIEX16), supporting: - AMD Ryzen??? 9000/7000: PCIe 5.0 x16 - AMD Ryzen??? 8000-Phoenix 1: PCIe 4.0 x8 - AMD Ryzen??? 8000-Phoenix 2: PCIe 4.0 x4 1 x PCI Express x16 slot, supporting PCIe 3.0 and running at x4 (PCIEX4) |
| Storage Interface |
2 x M.2 connectors, supporting PCIe 5.0 and PCIe 4.0 SSDs 4 x SATA 6Gb/s connectors RAID 0, RAID 1, RAID 5, and RAID 10 support |
| USB |
CPU: - 1 x USB Type-C?? (USB 3.2 Gen 1) - 1 x USB 3.2 Gen 1 - 1 x USB 2.0/1.1 Chipset: - 1 x USB Type-C?? (USB 3.2 Gen 1) - 4 x USB 3.2 Gen 1 - 5 x USB 2.0/1.1 |
| Internal I/O Connectors |
1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 1 x CPU fan header 1 x CPU fan/water cooling pump header 2 x addressable RGB Gen2 LED strip headers 1 x RGB LED strip header 4 x SATA 6Gb/s connectors And more... |
| Back Panel Connectors |
1 x HDMI port 2 x DisplayPorts 1 x PS/2 keyboard/mouse port 1 x USB Type-C?? port 3 x USB 3.2 Gen 1 ports 2 x USB 2.0/1.1 ports 1 x RJ-45 port 3 x audio jacks |
| BIOS | 1 x 256 Mbit flash, AMI UEFI BIOS |
| Unique Features |
Support for GIGABYTE Control Center (GCC) Support for Q-Flash and Q-Flash Plus Support for Smart Backup |
| Operating System | Support for Windows 11 64-bit, Windows 10 64-bit |
| Form Factor | Micro ATX; 24.4cm x 24.4cm |
Specification
Gigabyte B850M D3HP AM5 ATX Motherboard, 4x DIMMs with AMD EXPO, Upto DDR5 8200(OC), 2x M.2 slots, 1x PCIe 5.0 x4, GbE LAN, EZ-Latch | B850M D3HP Specifications
| CPU | AMD Socket AM5, support for AMD Ryzen??? 9000/8000/7000 Series Processors |
| Chipset | AMD B850 |
| Memory |
Support for DDR5 8200(OC) / 8000(OC) / 7800(OC) / 7600(OC) / 7200(OC) / 7000(OC)/6800(OC) / 6666(OC) / 6600(OC) / 6400(OC) / 6200(OC) / 6000(OC) / 5600(OC) / 5200 / 4800 / 4400 MT/s 4 x DDR5 DIMM sockets supporting up to 256 GB (64 GB single DIMM capacity) Dual channel memory architecture Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules Support for AMD EXtended Profiles for Overclocking (AMD EXPO???) and XMP |
| Onboard Graphics |
Integrated Graphics Processor with AMD Radeon??? Graphics support: - 1 x HDMI port, max resolution 4096x2160@60Hz - 2 x DisplayPorts, max resolution 3840x2160@144Hz * Supports up to triple-display simultaneously |
| Audio |
Realtek?? Audio CODEC High Definition Audio 2/4/5.1/7.1-channel support |
| LAN | Realtek?? GbE LAN chip (1 Gbps/100 Mbps/10 Mbps) |
| Expansion Slots |
1 x PCI Express x16 slot (PCIEX16), supporting: - AMD Ryzen??? 9000/7000: PCIe 5.0 x16 - AMD Ryzen??? 8000-Phoenix 1: PCIe 4.0 x8 - AMD Ryzen??? 8000-Phoenix 2: PCIe 4.0 x4 1 x PCI Express x16 slot, supporting PCIe 3.0 and running at x4 (PCIEX4) |
| Storage Interface |
2 x M.2 connectors, supporting PCIe 5.0 and PCIe 4.0 SSDs 4 x SATA 6Gb/s connectors RAID 0, RAID 1, RAID 5, and RAID 10 support |
| USB |
CPU: - 1 x USB Type-C?? (USB 3.2 Gen 1) - 1 x USB 3.2 Gen 1 - 1 x USB 2.0/1.1 Chipset: - 1 x USB Type-C?? (USB 3.2 Gen 1) - 4 x USB 3.2 Gen 1 - 5 x USB 2.0/1.1 |
| Internal I/O Connectors |
1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 1 x CPU fan header 1 x CPU fan/water cooling pump header 2 x addressable RGB Gen2 LED strip headers 1 x RGB LED strip header 4 x SATA 6Gb/s connectors And more... |
| Back Panel Connectors |
1 x HDMI port 2 x DisplayPorts 1 x PS/2 keyboard/mouse port 1 x USB Type-C?? port 3 x USB 3.2 Gen 1 ports 2 x USB 2.0/1.1 ports 1 x RJ-45 port 3 x audio jacks |
| BIOS | 1 x 256 Mbit flash, AMI UEFI BIOS |
| Unique Features |
Support for GIGABYTE Control Center (GCC) Support for Q-Flash and Q-Flash Plus Support for Smart Backup |
| Operating System | Support for Windows 11 64-bit, Windows 10 64-bit |
| Form Factor | Micro ATX; 24.4cm x 24.4cm |
