Gigabyte B850M GAMING X WF6E AM5 Micro ATX Motherboard, 4x DIMMs with AMD EXPO, DDR5 OC up to 8200MT/s, 2 x M.2 Slots, 2.5GbE LAN & Wi-Fi 6E | B850M GAMING X WF6E
Model :
SKU : MB-GIG B850M GAMIN X WI6E
About this item
About this item
Description
The B850M GAMING X WIFI6E is engineered for builders who want the full power of the "Zen 5" architecture without the bulk of a full ATX tower. As part of GIGABYTE's updated B850 lineup, this motherboard is "AI Ready," offering the optimized power phases and high-speed data lanes necessary for local AI processing, streaming, and gaming. It maintains full backward compatibility with Ryzen 8000 and 7000 series CPUs, ensuring a versatile upgrade path for the AM5 socket.
Reliable Power & Thermal Armor
Despite its mATX size, this board doesn't compromise on power delivery. It features a Digital VRM design to provide precise and stable voltage to the CPU during intense gaming sessions. Cooling is handled by an enlarged MOSFET heatsink and an M.2 Thermal Guard, which work together to dissipate heat effectively from the voltage regulators and high-speed NVMe SSDs, preventing thermal throttling and maintaining peak system performance.
Next-Gen Connectivity: WiFi 6E and PCIe 5.0
Stay at the forefront of wireless technology with integrated WiFi 6E, utilizing the 6GHz band to provide faster speeds and lower latency in crowded network environments. For storage, the motherboard includes a dedicated PCIe 5.0 M.2 slot, supporting data transfer rates up to 128Gb/s for near-instant game loading. For wired networking, the 2.5GbE LAN provides a high-bandwidth connection that is 2.5 times faster than standard Gigabit Ethernet.
EZ-DIY Innovations: Simplified Building
GIGABYTE has packed this board with user-friendly features to make building easy. The PCIe EZ-Latch allows for the quick and safe removal of heavy graphics cards, while the M.2 EZ-Latch offers tool-less installation for your storage drives. Furthermore, the Q-Flash Plus feature allows you to update the BIOS using only a USB thumb drive—no CPU, RAM, or GPU required—ensuring your system is always ready for the newest AMD processor releases.
Why the GIGABYTE B850M GAMING X WIFI6E Stands Out
LGA AM5 Native: Native support for Ryzen 9000 and backward compatible with 8000/7000 series.
Micro-ATX Versatility: Fits into a wide range of compact and mid-tower cases.
WiFi 6E Standard: Access the 6GHz spectrum for a cleaner, faster wireless experience.
PCIe 5.0 Ready: Future-proofed storage speeds for the latest NVMe SSDs.
Specification
| CPU | AMD Socket AM5, support for: AMD Ryzen 9000 Series Processors AMD Ryzen 8000 Series Processors AMD Ryzen 7000 Series Processors (Go to GIGABYTE's website for the latest CPU support list.) |
| Chipset | AMD B850 |
| Memory | Support for DDR5 8200(O.C) / 8000(O.C) / 7950(O.C) / 7900(O.C) / 7800(O.C) / 7600(O.C.) / 7400(O.C.) / 7200(O.C.) / 7000(O.C.) / 6800(O.C.) / 6600(O.C.) / 6400(O.C) / 6200(O.C) / 6000(O.C) / 5800(O.C) / 5600(O.C) / 5200 / 4800 / 4400 MT/s memory modules. 4 x DDR5 DIMM sockets supporting up to 256 GB (64 GB single DIMM capacity) of system memory. Dual channel memory architecture. Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules. Support for AMD EXtended Profiles for Overclocking (AMD EXPO) and Extreme Memory Profile (XMP) memory modules. (The CPU and memory configuration may affect the supported memory types, data rate (speed), and number of DRAM modules, please refer to "Memory Support List" on GIGABYTE's website for more information.) |
| Onboard Graphics | Integrated Graphics Processor with AMD Radeon Graphics support: - 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz * Support for HDMI 2.1 version and HDCP 2.3, and HDR. - 2 x DisplayPorts, supporting a maximum resolution of 3840x2160@144 Hz * Support for DisplayPort 1.4 version. Support for up to triple-display at the same time. |
| Audio | Realtek Audio CODEC High Definition Audio 2/4/5.1/7.1-channel * You can change the functionality of an audio jack using the audio software. To configure 7.1-channel audio, access the audio software for audio settings. |
| LAN | Realtek 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps) |
| Wireless Communication | Realtek Wi-Fi 6E RTL8852CE - Wi-Fi a, b, g, n, ac, ax, supporting 2.4/5/6 GHz carrier frequency bands - Bluetooth 5.3 - Support for 11ax 160MHz wireless standard (Actual data rate may vary depending on environment and equipment.) |
| Expansion Slots | 1 x PCI Express x16 slot (PCIEX16), integrated in the CPU: - AMD Ryzen 9000/7000 Series Processors support PCIe 5.0 x16 mode. - AMD Ryzen 8000 Series-Phoenix 1 Processors support PCIe 4.0 x8 mode. - AMD Ryzen 8000 Series-Phoenix 2 Processors support PCIe 4.0 x4 mode. |
| Storage Interface | 2 x M.2 connectors, integrated in the CPU: - Support for PCIe 5.0 and 4.0 SSDs 4 x SATA 6Gb/s connectors RAID 0, RAID 1, RAID 5, and RAID 10 support for NVMe and SATA storage devices. |
| USB | CPU: - 1 x USB Type-C port (USB 3.2 Gen 2) - 1 x USB 3.2 Gen 2 Type-A port Chipset: - Multiple USB 3.2 Gen 1 and USB 2.0/1.1 ports available through back panel and internal headers. |
| Form Factor | Micro ATX Form Factor; 24.4cm x 24.4cm |
