Supports AMD Ryzen™ 9000 / 8000 / 7000 Series Processors
Digital twin 16+2+2 phases VRM solution
PCIe 5.0 x16 slot with 10X strength for graphics card
4*M.2 slots, including PCIe 5.0 x4
Dual 5GbE LAN & Wi-Fi 7 with directional Ultra-high gain antenna
The GIGABYTE X870E AERO X3D Dark Wood Edition (X870E AERO X DK WOOD / 9MX87EOXK-00-) is designed for PC builders who demand top-tier performance without sacrificing visual elegance. Moving away from traditional industrial styling, this flagship AMD X870E motherboard incorporates real dark wood paneling to bring a warm, modern aesthetic to creator studios, living room setups, and premium desktop builds.
Performance / Technology Built on a multi-layer copper PCB with thermal armor and direct-touch heatpipes, the X870E AERO X3D keeps VRMs and NVMe SSDs cool during sustained workloads. High-bandwidth USB4 / USB 3.2 Gen 2x2 Type-C connectivity enables ultra-fast external drive transfers and display outputs.
Design & Ergonomics The ATX form factor features reinforced PCIe UD Slot X technology to prevent heavy graphics card sag, along with intuitive BIOS software (UC BIOS) with customizable fan curves and quick AI tuning profiles.
Compatibility / Use Cases Optimized for content creators, 3D animators, video editors, and gamers who build in wood-accented or Scandinavian-designed PC cases (such as Fractal North).
Why This Product Stands Out The GIGABYTE X870E AERO X3D Dark Wood Edition pairs real dark wood aesthetics, X3D CPU tuning, PCIe 5.0 throughput, DDR5 speed, Wi-Fi 7, and dual 5GbE LAN into a creator-focused AM5 motherboard.
Feature
Specification
Model & Form Factor
GIGABYTE X870E AERO X3D DARK WOOD (X870E AERO X DK WOOD) | ATX (30.5cm x 24.4cm)
CPU Socket & Support
AMD Socket AM5 | Supports AMD Ryzen™ 9000, 8000, and 7000 Series Processors
Chipset
AMD X870E
Memory (RAM)
4x DDR5 DIMM Sockets | Up to 256 GB (64 GB per DIMM) | Dual Channel | Speeds up to 9000 MT/s (O.C.) | Supports AMD EXPO™ & Intel XMP
Graphics Output
2x USB4® Type-C® (DP alt mode up to 3840x2160 @ 240Hz) | 1x Rear HDMI 2.1 (up to 4096x2160 @ 60Hz) | 1x Front/Internal HDMI 1.4 (up to 1920x1080 @ 30Hz)
Dual Realtek® 5GbE LAN (5/2.5/1 Gbps) | MediaTek Wi-Fi 7 MT7927 (802.11be, 320MHz) | Bluetooth 5.4
Audio
Realtek® ALC1220 CODEC | 2/4/5.1/7.1-channel High Definition Audio | DSD Support | Optical S/PDIF Out
Rear I/O Ports
2x USB4® Type-C® | 1x USB 3.2 Gen 2x2 Type-C® | 5x USB 3.2 Gen 2 Type-A (Red) | 3x USB 3.2 Gen 1 Type-A | 1x HDMI | 2x RJ-45 | 2x Audio Jacks | 1x Optical S/PDIF | 2x Wi-Fi Antenna Connectors | Power, Reset, Q-Flash Plus, and Clear CMOS buttons
Internal I/O Headers
1x USB 3.2 Gen 2x2 Type-C® header | 2x USB 3.2 Gen 1 headers | 2x USB 2.0/1.1 headers | 8x Fan/Pump headers | 3x ARGB Gen2 headers | 1x RGB header | 1x Internal HDMI port | Noise & Temp sensor headers
Power Connectors
1x 24-pin ATX | 2x 8-pin ATX 12V (CPU)
Description
The GIGABYTE X870E AERO X3D Dark Wood Edition (X870E AERO X DK WOOD / 9MX87EOXK-00-) is designed for PC builders who demand top-tier performance without sacrificing visual elegance. Moving away from traditional industrial styling, this flagship AMD X870E motherboard incorporates real dark wood paneling to bring a warm, modern aesthetic to creator studios, living room setups, and premium desktop builds.
Performance / Technology Built on a multi-layer copper PCB with thermal armor and direct-touch heatpipes, the X870E AERO X3D keeps VRMs and NVMe SSDs cool during sustained workloads. High-bandwidth USB4 / USB 3.2 Gen 2x2 Type-C connectivity enables ultra-fast external drive transfers and display outputs.
Design & Ergonomics The ATX form factor features reinforced PCIe UD Slot X technology to prevent heavy graphics card sag, along with intuitive BIOS software (UC BIOS) with customizable fan curves and quick AI tuning profiles.
Compatibility / Use Cases Optimized for content creators, 3D animators, video editors, and gamers who build in wood-accented or Scandinavian-designed PC cases (such as Fractal North).
Why This Product Stands Out The GIGABYTE X870E AERO X3D Dark Wood Edition pairs real dark wood aesthetics, X3D CPU tuning, PCIe 5.0 throughput, DDR5 speed, Wi-Fi 7, and dual 5GbE LAN into a creator-focused AM5 motherboard.
Specification
Feature
Specification
Model & Form Factor
GIGABYTE X870E AERO X3D DARK WOOD (X870E AERO X DK WOOD) | ATX (30.5cm x 24.4cm)
CPU Socket & Support
AMD Socket AM5 | Supports AMD Ryzen™ 9000, 8000, and 7000 Series Processors
Chipset
AMD X870E
Memory (RAM)
4x DDR5 DIMM Sockets | Up to 256 GB (64 GB per DIMM) | Dual Channel | Speeds up to 9000 MT/s (O.C.) | Supports AMD EXPO™ & Intel XMP
Graphics Output
2x USB4® Type-C® (DP alt mode up to 3840x2160 @ 240Hz) | 1x Rear HDMI 2.1 (up to 4096x2160 @ 60Hz) | 1x Front/Internal HDMI 1.4 (up to 1920x1080 @ 30Hz)
