GIGABYTE X870E AORUS Xtreme AI TOP AMD AM5 LGA 1718 Motherboard, E-ATX, DDR5, 4X M.2, PCIe 5.0, USB4, WIFI7, 10GbE LAN, EZ-Latch, 5-Year Warranty | X870E A XTREME AI TOP
Model :
SKU : MB-GIG X870E A XTR AI TOP
About this item
About this item
Description
X870E A XTREME AI TOP
Training your own AI on your desk
DDR5 OC up to 8800MT/s
AMD Socket AM5 : Supports AMD Ryzen™ 9000 / 8000 / 7000 Series Processors
Digital twin 18+2+2 phases VRM solution
Dual Channel DDR5 : 4*DIMMs with AMD EXPO™Memory Module Support
DDR Wind Blade : Enhanced Active Cooling for Memory Modules
M.2 EZ-Match : Magnetic alignment for easy installation of large heatsinks
WIFI EZ-Plug : Quick and easy design for Wi-Fi antenna installation
EZ-Latch Plus : PCIe and M.2 slots with Quick Release & Screwless Design
EZ-Latch Click : M.2 heatsinks with screwless design
Sensor Panel Link : Onboard video port for hassle-free in-chassis panel setup
Friendly UI : Multi-Theme, AIO Fan Control, and Q-Flash Auto Scan in BIOS and SW.
New Power Monitor in HWinfo for real-time monitoring on CPU power phases
Ultra-Fast Storage : 4*M.2 slots, including PCIe 5.0 / 4.0
Efficient Thermal : VRM Thermal Armor Advanced with I/O ZONE AORUS LIGHTING & M.2 Thermal Guard XL
Blazing Fast Networks : Dual 10GbE LAN & Wi-Fi 7 & directional Ultra-high gain antenna with ARGB
Extended Connectivity : Dual USB4 Type-C with DP-Alt, HDMI
DTS : X® Ultra Audio : ALC1220 & Rear ESS SABRE Hi-Fi 9118 DAC
Titanium PCIe UD Slot X : PCIe 5.0 x16 slot with titanium for ultimate protection of graphics cards
The GIGABYTE X870E AORUS Xtreme AI TOP is more than just a motherboard; it is a specialized workstation foundation designed for the new era of Artificial Intelligence. Built on the AMD X870E chipset, it provides maximum lanes for PCIe 5.0, ensuring that both your GPU and high-speed NVMe storage run at their theoretical limits. The "AI TOP" designation signifies GIGABYTE's unique hardware and software tuning aimed at users running local AI models, offering the stability and throughput required for deep learning and complex data processing.
Power Delivery and Thermal Mastery
To sustain the power-hungry Ryzen™ 9000 and 7000 series CPUs, the X870E AORUS Xtreme features a 16+2+2 phase digital VRM with 80A Smart Power Stages. This is cooled by the Fins-Array III heatsink system, which utilizes a NanoCarbon coating to dissipate heat more efficiently. The thermal design extends to the storage, with M.2 Thermal Guard XTREME shielding ensuring that Gen5 SSDs never throttle during sustained file transfers or heavy rendering tasks.
Next-Gen Connectivity: WiFi 7, 10GbE, and USB4
Connectivity is where this motherboard truly shines. It features onboard WiFi 7 with a high-gain directional antenna for lag-free wireless data. For wired enthusiasts, the Marvell® AQtion 10GbE LAN provides server-grade speeds. On the I/O panel, Dual USB4 Type-C ports offer up to 40Gbps bandwidth each, supporting DisplayPort alt mode and daisy-chaining for professional creative setups.
EZ-Latch and User-Centric Design
GIGABYTE has streamlined the building process with M.2 EZ-Latch Click and PCIe EZ-Latch Plus. These tool-less designs allow you to install and remove massive graphics cards and M.2 heatsinks with a simple button press or click—no more fumbling with tiny screws. The E-ATX form factor provides ample space for a premium aesthetic, complemented by customizable RGB lighting and a durable Ultra Durable™ PCIe Armor.
Why the X870E AORUS Xtreme AI TOP Stands Out
AI TOP Tuning: Optimized BIOS and hardware traces for local AI model training and inferencing.
10GbE Networking: Massive wired bandwidth for NAS users and professional creators.
Dual USB4 Ports: Extreme 40Gbps speeds for high-end peripherals and external storage.
Specification
| CPU | AMD Socket AM5, support for: AMD Ryzen??? 9000 Series Processors/ AMD Ryzen??? 8000 Series Processors/ AMD Ryzen??? 7000 Series Processors * Please refer to "CPU Support List" for more information. |
| Chipset | AMD X870E |
| Memory | Support for DDR5 8800(O.C.) / 8600(O.C) / 8400(O.C) /8266(O.C) / 8200(O.C) / 8000(O.C) / 7950(O.C) / 7900(O.C) / 7800(O.C) / 7600(O.C.) / 7400(O.C.) / 7200(O.C.) / 7000(O.C.) / 6800(O.C.) / 6600(O.C.) / 6400(O.C) / 6200(O.C) / 6000(O.C) / 5800(O.C) / 5600(O.C) / 5200 / 4800 / 4400 MT/s memory modules. 4 x DDR5 DIMM sockets supporting up to 256 GB (64 GB single DIMM capacity) of system memory Dual channel memory architecture Support for ECC and non-ECC Un-buffered DIMM memory modules Support for AMD EXtended Profiles for Overclocking (AMD EXPO???) and Extreme Memory Profile (XMP) memory modules (The CPU and memory configuration may affect the supported memory types, data rate (speed), and number of DRAM modules, please refer to "Memory Support List" for more information.) |
| Onboard Graphics | Integrated Graphics Processor with AMD Radeon??? Graphics support+ASMedia USB4?? Controller: - 2 x USB4?? USB Type-C?? ports, supporting USB4 and DisplayPort video outputs and a maximum resolution of 3840x2160@240 Hz * Support for DisplayPort 1.4 version and HDR. |
| Audio | Realtek?? ALC1220 CODEC * The front panel line out jack supports DSD audio. ESS ES9118 DAC chip Support for DTS:X?? Ultra High Definition Audio 2/4/5.1-channel * You can change the functionality of an audio jack using the audio software. To configure 5.1-channel audio, access the audio software for audio settings. Support for S/PDIF Out |
| LAN | 2 x Marvell?? AQtion AQC113C 10GbE LAN chips (10 Gbps/5 Gbps/2.5 Gbps/1 Gbps/100 Mbps) |
| Wireless Communication | Qualcomm?? Wi-Fi 7 QCNCM865 - 802.11a, b, g, n, ac, ax, be, supporting 2.4/5/6 GHz carrier frequency bands - BLUETOOTH 5.3 - Support for 11be 320MHz wireless standard (Actual data rate may vary depending on environment and equipment.) * Wi-Fi 7 features require Windows 11 SV3 to function properly. (There is no support driver for Windows 10.) ** Wi-Fi 7 channels on 6 GHz band availability depends on individual country's regulations. |
| Expansion Slots | 1 x PCI Express x16 slot (PCIEX16), integrated in the CPU: AMD Ryzen??? 9000/7000 Series Processors support PCIe 5.0 x16 mode AMD Ryzen??? 8000 Series-Phoenix 1 Processors support PCIe 4.0 x8 mode AMD Ryzen??? 8000 Series-Phoenix 2 Processors support PCIe 4.0 x4 mode * The PCIEX8 slot shares bandwidth with the PCIEX16 slot. When the PCIEX8 slot is populated, the PCIEX16 slot operates at up to x8 mode. * The PCIEX16 and PCIEX8 slots can only support a graphics card or an NVMe SSD. If only one graphics card is to be installed, be sure to install it in the PCIEX16 slot. |
| Storage Interface | 1 x M.2 connector (M2A_CPU), integrated in the CPU, supporting Socket 3, M key, type 25110/22110/2580/2280 SSDs: AMD Ryzen??? 9000/7000 Series Processors support PCIe 5.0 x4/x2 SSDs AMD Ryzen??? 8000 Series-Phoenix 1 Processors support PCIe 4.0 x4/x2 SSDs AMD Ryzen??? 8000 Series-Phoenix 2 Processors support PCIe 4.0 x4/x2 SSDs 2 x M.2 connectors (M2D_SB, M2B_SB), integrated in the Chipset, supporting Socket 3, M key, type 22110/2280 PCIe 4.0 x4/x2 SSDs 1 x M.2 connector (M2E_SB), integrated in the Chipset, supporting Socket 3, M key, type 22110/2280 PCIe 4.0 x2 SSDs 4 x SATA 6Gb/s connectors RAID 0, RAID 1, RAID 5, and RAID 10 support for NVMe SSD storage devices * RAID 5 is only available on AMD Ryzen??? 9000 Series Processors.. RAID 0, RAID 1, and RAID 10 support for SATA storage devices |
| USB | CPU+ASMedia USB4?? controller: - 2 x USB4?? USB Type-C?? ports on the back panel CPU: - 1 x USB 3.2 Gen 2 Type-A port (red) on the back panel Chipset: - 1 x USB Type-C?? port with USB 3.2 Gen 2x2 support, available through the internal USB header - 5 x USB 3.2 Gen 2 Type-A ports (red) on the back panel - 4 x USB 3.2 Gen 1 ports available through the internal USB headers - 6 x USB 2.0/1.1 ports (2 ports on the back panel, 4 ports available through the internal USB headers) |
| Internal I/O Connectors | 1 x 24-pin ATX main power connector 2 x 8-pin ATX 12V power connectors 1 x CPU fan header 1 x CPU fan/water cooling pump header 4 x system fan headers 4 x system fan/water cooling pump headers 3 x addressable RGB Gen2 LED strip headers 1 x RGB LED strip header 4 x SATA 6Gb/s connectors 4 x M.2 Socket 3 connectors 2 x temperature sensor headers 1 x front panel header 1 x front panel audio header 1 x USB Type-C?? header, with USB 3.2 Gen 2x2 support 2 x USB 3.2 Gen 1 headers 2 x USB 2.0/1.1 headers 1 x noise detection header 1 x HDMI port (Note) 1 x Trusted Platform Module header 1 x power button 1 x reset button 1 x reset jumper 1 x Clear CMOS jumper |
| Back Panel Connectors | 1 x Q-Flash Plus button 1 x Clear CMOS button 1 x HDMI port (Note) 2 x USB4?? USB Type-C?? ports (DisplayPorts (Note)) 6 x USB 3.2 Gen 2 Type-A ports (red) 2 x USB 2.0/1.1 ports 2 x RJ-45 ports 2 x antenna connectors (2T2R) 1 x optical S/PDIF Out connector 2 x audio jacks |
| I/O Controller | iTE?? I/O Controller Chip |
| H/W Monitoring | Voltage detection Temperature detection Fan speed detection Water cooling flow rate detection Fan fail warning Fan speed control * Whether the fan speed control function is supported will depend on the fan you install. Noise detection |
