Hikvision 4MP Solar-powered Security Camera Setup, 4mm Fixed Focal Lens, Up to 30m IR Light, Support 4G LTE Network, RJ45 ETH, Built-in Memory /Micro Sim Card Slot, IP67, White | DS-2XS2T41G1-ID/4G SOLAR CAMERA
Model :
SKU : DS-2XS2T41G1-ID/4G/C05S07
About this item
0
Inclusive of VAT
Delivery to
FREE scheduled delivery as soon as Loading...
Sold and shipped by: Adarc computers
About this item
Description
- Camera
- Image Sensor1/3" Progressive Scan CMOS
- Max. Resolution2560 ?? 1440
- Min. IlluminationB/W: 0.01 Lux @ (F1.6, AGC ON),B/W: 0 Lux with IR
- Shutter Time1/3 s to 1/100,000 s
- Day & NightIR cut filter
- Angle AdjustmentSolar panel: tilt: -45?? to 45??, rotate:-30?? to 30??
- Lens
- Lens TypeFixed focal lens, 4 and 6 mm optional
- Iris TypeFixed
- Aperture4mm: F1.28, 6mm: F1.6
- Depth Of Field
4 mm: 2.7 m to ???
6 mm: 5.9 m to ???
- Focal Length & FOV
4 mm, Horizontal FOV: 79??, Vertical FOV: 43??, Diagonal FOV: 93??
6 mm, Horizontal FOV: 49??, Vertical FOV: 26??, Diagonal FOV: 57??
- Lens MountM12
- DORI
- DORI
4 mm, D: 77 m, O: 30 m, R: 15 m, I: 7 m
6 mm, D: 128 m, O: 50 m, R: 25 m, I: 12 m
- Illuminator
- Supplement Light TypeIR
- Supplement Light RangePerformance mode: up to 30 m, proactive mode: up to 10 m
- IR Wavelength850 nm
- Smart Supplement LightYes
- Video
- Main Stream
50 Hz: 12.5 fps (2560 ?? 1440, 1920 ?? 1080, 1280 ?? 720)
60 Hz: 15 fps (2560 ?? 1440, 1920 ?? 1080, 1280 ?? 720)
- Sub-Stream
50 Hz: 12.5 fps (1280 ?? 720, 640 ?? 480, 640 ?? 360)
60 Hz: 15 fps (1280 ?? 720, 640 ?? 480, 640 ?? 360)
- Video Compression
Main stream: H.265/ H.264,
Sub-stream: H.265/H.264/MJPEG,
H.264+ and H.265+: main stream supports under performance mode
- Video Bit Rate32 Kbps to 8 Mbps
- H.264 TypeBaseline Profile,Main Profile,High Profile
- H.265 TypeMain Profile
- Bit Rate ControlCBR,VBR
- Region Of Interest (ROI)1 fixed region for main stream
- Scalable Video Coding (SVC)H.264 and H.265 encoding
- Audio
- Audio Sampling Rate8 kHz/16 kHz
- Environment Noise FilteringYes
- Audio CompressionG.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/AAC-LC
- Audio Bit Rate64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC-LC)
- Network
- SecurityPassword protection, complicated password, basic and digest authentication for HTTP, TLS 1.1/1.2/1.3, WSSE and digest authentication for Open Network Video Interface
- Simultaneous Live ViewUp to 6 channels
- APIOpen Network Video Interface (Profile S, Profile G, Profile T),ISAPI,SDK
- ProtocolsTCP/IP, ICMP, HTTP, DHCP, DNS, RTP, RTSP, RTCP, NTP, IGMP, QoS, UDP
- User/Host
Up to 32 users
3 user levels: administrator, operator, and user
- Network StorageAuto Network Replenishment (ANR)
- ClientiVMS-4200,Hik-Connect,Hik-Central
- Web Browser
Plug-in required live view: IE 10, IE 11,
Plug-in free live view: Chrome 57.0+, Firefox 52.0+,
Local service: Chrome 57.0+, Firefox 52.0+
- Mobile Communication
- SIM Card TypeMicro SIM
- Uplink And Downlink Data RateCat 4, uplink: 50 Mbps, downlink: 150 Mbps
- Frequency
EU:
LTE-TDD: B38/B40/B41
LTE-FDD: B1/B3/B5/B7/B8/B20/B28
WCDMA: B1/B5/B8
GSM: B3/B5/B8
LA:
LTE-TDD: B38/B40
LTE-FDD: B1/B2/B3/B4/B5/B7/B8/B12/B17/B28/B66
WCDMA:B1/B2/B3/B4/B5/B8
GSM: B2/B3/B5/B8
- StandardLTE-TDD,LTE-FDD,WCDMA,GSM
- Image
- SNR??? 52 dB
- Wide Dynamic Range (WDR)Digital WDR
- Day/Night SwitchDay,Night,Auto,Schedule
- Image EnhancementBLC,HLC,3D DNR
- Image SettingsSaturation,brightness,contrast,sharpness,gain,white balance,adjustable by client software or web browser
- Transducer
- Transducer TypePIR + Radar
- Detection Angle4 mm : Horizontal: 80??, vertical: 42??,6 mm???Horizontal: 50??, vertical: 22??
- Detection RangeUp to 12 m
- Interface
- Ethernet Interface1 RJ45 10 M/100 M self-adaptive Ethernet port
- On-Board Storage
Built-in eMMC storage, up to 8 GB,
Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 256 GB,For eMMC storage, 5 GB is available for recording.
- Built-In MicrophoneYes
- Built-In SpeakerYes
- Reset KeyYes
- Event
- Basic EventMotion detection,video tampering alarm,network disconnected,IP address conflict,illegal login,HDD full,HDD error
- Linkage
Upload to NAS/memory card,notify surveillance center,trigger recording,trigger capture,audible warning
- General
- Power
Power Consumption and Current:
Typical power scenarios: 1.85 W (4G working)
Standby scenarios: 80 mW
Max. power consumption: 7 W
Power Supply:
12 VDC
*For debugging only
6.5 W (deviation: ?? 1 W) Solar panels
Power Interface:
Power supply interface: ??5.5 mm coaxial power plug
Extened solar panel: ??5.5 mm coaxial power plug
- MaterialPlastic
- Storage Conditions0 ??C to 50 ??C (32 ??F to 122 ??F). Humidity 95% or less (non-condensing)
- Language33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian
- General FunctionHeartbeat,mirror,flash log
- Startup And Operating Conditions0 ??C to 50 ??C (32 ??F to 122 ??F). Humidity 95% or less (non-condensing)
- Dimension213.7 mm ?? 292.4 mm ?? 188.7 mm (8.4" ?? 11.5" ?? 7.3")
- Package Dimension345 mm ?? 240 mm ?? 292 mm (13.6" ?? 9.4" ?? 11.5")
- Weight
Approx. 1.42 kg (3.1 lb.)
- With Package Weight
Approx. 2.07 kg (4.6 lb.)
- Battery
- Battery TypeTernary Lithium
- Capacity51.46 Wh
- Max. Charging Voltage12.6 V
- Operating Temperature
Charging: 0 ??C to 45 ??C (32 ??F to 113 ??F)
Discharging: -20 ??C to 50 ??C (-4 ??F to 122 ??F)
- Battery Voltage8.1 V to 12.6 V
- Battery LifeMore than 800 cycles
- Cycle Lifetime
Proactive mode: 1.5 days,
Standby mode: 11 days
- Battery WeightApprox. 185 g (0.4 lb.)
- Approval
- EMC
CE-EMC: EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3: 2013+A1:2019, EN 50130-4: 2011 +A1: 2014,
RCM: AS/NZS CISPR 32: 2015,
*CE and RCM certifications are only for the device sold in the European region.
- RF
CE-RED: EN 301489-1 V2.1.1 (BT or 2.4G), EN 301489-17 V3.1.1 (BT or 2.4G), EN 300328 V2.1.1 (BT or 2.4G), EN 62311: 2008 (BT or 2.4G)
*CE certification is only for the device sold in the European region.
- Safety
CB: IEC 62368-1: 2014+A11,
CE-LVD: EN 62368-1: 2014/A11: 2017,
LOA: IEC/EN 60950-1,
*CE and LOA certifications are only for the device sold in the European region.
- Environment
CE-RoHS: 2011/65/EU,
WEEE: 2012/19/EU,
Reach: Regulation (EC) No 1907/2006,
*CE certification is only for the device sold in the European region.
- ProtectionIP67: IEC 60529-2013
