Hikvision DS-2CD2747G2T-LZS 4 MP ColorVu Motorized Varifocal Dome Network Camera, Up to 40 m, 2688 ?? 1520 Max Resol, Human And Vehicle Classification, IP67 And IK10
Model :
SKU : DS-2CD2747G2T-LZS 2.8-12M
About this item
Description
Hikvision DS-2CD2747G2T-LZS 4 MP ColorVu Motorized Varifocal Dome Network Camera, Up To 40 M, 2688 ?? 1520 Max Resol, Human And Vehicle Classification, IP67 And IK10 Specifications
| Image Sensor | 1/1.8" Progressive Scan CMOS |
| Max. Resolution | 2688 ?? 1520 |
| Min. Illumination | Color: 0.0005 Lux @ (F1.0, AGC ON), 0 Lux with light |
| Shutter Time | 1/3 s to 1/100,000 s |
| Angle Adjustment | Pan: 0?? to 355??, tilt: 0?? to 75??, rotate: 0?? to 355?? |
| Day & Night | 24/7 color imaging |
| Lens Type | Varifocal lens, motorized lens, 2.8 to 12 mm |
| Focal Length & FOV | 2.8 to 12 mm, horizontal FOV 105.4?? to 56.4??, vertical FOV 53.9?? to 31.6??, diagonal FOV 131.8?? to 65.1?? |
| Lens Mount | Integrated |
| Focus | Auto, Semi-auto, Manual |
| Iris Type | DC iris |
| Aperture | F1.0 |
| Depth Of Field | 1.9 m to ??? |
| DORI | D: 66.8 m to 110.4 m, O: 26.5 m to 43.8 m, R: 13.4 m to 22.1 m, I: 6.7 m to 11 m |
| Supplement Light Type | White Light |
| Supplement Light Range | Up to 40 m |
| Smart Supplement Light | Yes |
| Sub-Stream | 50 Hz: 25 fps (1280 ?? 720, 640 ?? 480, 640 ?? 360) 60 Hz: 30 fps (1280 ?? 720, 640 ?? 480, 640 ?? 360) |
| Third Stream | 50 Hz: 10 fps (1920 ?? 1080, 1280 ?? 720, 640 ?? 480, 640 ?? 360) 60 Hz: 10 fps (1920 ?? 1080, 1280 ?? 720, 640 ?? 480, 640 ?? 360) *Third stream is supported under certain settings. |
| Video Compression | Main stream: H.265/H.264/H.265+/H.264+ Sub-stream: H.265/H.264/MJPEG Third stream: H.265/H.264 *Third stream is supported under certain settings. |
| Video Bit Rate | 32 Kbps to 8 Mbps |
| H.264 Type | Baseline Profile, Main Profile, High Profile |
| H.265 Type | Main Profile |
| Bit Rate Control | VBR, CBR |
| Main Stream | 50 Hz: 25 fps (2688 ?? 1520, 1920 ?? 1080, 1280 ?? 720) 60 Hz: 30 fps (2688 ?? 1520, 1920 ?? 1080, 1280 ?? 720) |
| Scalable Video Coding (SVC) | H.264 and H.265 encoding |
| Region Of Interest (ROI) | 1 fixed region(s) for main stream and sub-stream |
| Audio Compression | G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC |
| Audio Bit Rate | 64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC-LC) |
| Audio Sampling Rate | 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz |
| Environment Noise Filtering | Yes |
| Protocols | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, ARP, WebSocket, WebSockets |
| Simultaneous Live View | Up to 6 channels |
| API | Open Network Video Interface (Profile S, Profile G, Profile T), ISAPI, SDK |
| User/Host | Up to 32 users 3 user levels: administrator, operator, and user |
| Security | Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Interface, RTP/RTSP over HTTPS, control timeout settings, security audit log, TLS 1.1/1.2/1.3, host authentication (MAC address) |
| Network Storage | NAS (NFS, SMB/CIFS), Auto Network Replenishment (ANR) Together with high-end Hikvision memory card, memory card encryption and health detection are supported. |
| Client | iVMS-4200, Hik-Connect, Hik-Central |
| Web Browser | Plug-in required live view: IE 10, IE 11 Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Edge 89+ Local service: Chrome 57.0+, Firefox 52.0+, Edge 89+ |
| Image Parameters Switch | Yes |
| Image Settings | Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance, adjustable by client software or web browser |
| Day/Night Switch | Day, Night, Auto, Schedule |
| Wide Dynamic Range (WDR) | 140 dB |
| White Balance | Auto/Manual/ATW (Auto-tracking White Balance)/One Touch/Indoor/Outdoor/Fluorescent Lamp/Sodium Lamp |
| Gain | Auto/Manual |
| Digital Noise Reduction | 3D DNR |
| Privacy Mask | 4 programmable polygon privacy masks |
| Alarm | 3 input(s), 1 output(s) |
| Linkage Method | Trigger recording: memory card, network storage, pre-record and post-record Trigger capture: upload to FTP/memory card/network storage Trigger notification: send email, notify surveillance center, trigger alarm output, trigger capture |
| Reset | Yes |
| Startup and Operating Conditions | -40 ??C to 65 ??C (-40 ??F to 149 ??F). Humidity 95% or less (non-condensing) |
| Power Supply | 12 VDC, two-core terminal block 24 VAC, max. 0.7 A, 50/60 Hz, two-core terminal block PoE (IEEE 802.3af, Class 3) |
| Power Consumption and Current | 12 VDC, 0.6 A, max. 7 W 24 VAC, 0.4 A to 0.2 A, max. 9 W PoE (802.3af, 36 V to 57 V), 0.2 A to 0.1 A, max. 9.5 W |
| Material | Front cover: metal Body: metal Rear cover: plastic |
| Dimensions | ?? 164.6 mm ?? 155.9 mm (?? 6.48" ?? 6.14") |
| Weight | Approx. 1.9 kg (4.2 lb.) |
| Approval | EMC: CE-EMC, FCC-EMC, IC-EMC, RCM-EMC, KC-EMC Safety: UL, CB, CE-LVD, BIS Environment: CE-RoHS, WEEE, Reach, IK10, IP67 |
| On-Board Storage | Built-in memory card slot, support microSD/SDHC/SDXC, up to 256 GB Memory card is optional. |
Hikvision DS-2CD2747G2T-LZS: See Clearly, Day and Night
Illuminate Your World with the Hikvision DS-2CD2747G2T-LZS 4 MP ColorVu Motorized Varifocal Dome Network Camera. This cutting-edge surveillance solution delivers exceptional image quality, advanced features, and robust construction for unparalleled security.
Key Features:
Day and Night Clarity: Experience vivid, true-color imaging even in the most challenging lighting conditions thanks to Hikvision's groundbreaking ColorVu technology.
Intelligent Detection: Go beyond basic surveillance with advanced features like human and vehicle classification, ensuring you only focus on what matters.
Panoramic Views: Enjoy complete coverage with the motorized varifocal lens, offering flexible viewing angles to suit any environment.
Weatherproof and Vandal-Resistant: Built to withstand harsh conditions with IP67 and IK10 ratings, ensuring reliable performance in any environment.
High-Resolution Imaging: Capture every detail with a 4 MP resolution that delivers sharp, clear images.
Additional Features:
Wide Dynamic Range (WDR): Maintain image clarity in high-contrast lighting conditions.
Long-Range Infrared: See clearly even in complete darkness with the built-in infrared illuminator.
H.265+ Compression: Efficiently store video footage without compromising image quality.
Flexible Installation: Easy to install and adjust with the motorized varifocal lens.
The Hikvision DS-2CD2747G2T-LZS is more than just a camera; it's a security investment. Protect your property with advanced technology and reliable performance.
Specification
Hikvision DS-2CD2747G2T-LZS 4 MP ColorVu Motorized Varifocal Dome Network Camera, Up To 40 M, 2688 ?? 1520 Max Resol, Human And Vehicle Classification, IP67 And IK10 Specifications
| Image Sensor | 1/1.8" Progressive Scan CMOS |
| Max. Resolution | 2688 ?? 1520 |
| Min. Illumination | Color: 0.0005 Lux @ (F1.0, AGC ON), 0 Lux with light |
| Shutter Time | 1/3 s to 1/100,000 s |
| Angle Adjustment | Pan: 0?? to 355??, tilt: 0?? to 75??, rotate: 0?? to 355?? |
| Day & Night | 24/7 color imaging |
| Lens Type | Varifocal lens, motorized lens, 2.8 to 12 mm |
| Focal Length & FOV | 2.8 to 12 mm, horizontal FOV 105.4?? to 56.4??, vertical FOV 53.9?? to 31.6??, diagonal FOV 131.8?? to 65.1?? |
| Lens Mount | Integrated |
| Focus | Auto, Semi-auto, Manual |
| Iris Type | DC iris |
| Aperture | F1.0 |
| Depth Of Field | 1.9 m to ??? |
| DORI | D: 66.8 m to 110.4 m, O: 26.5 m to 43.8 m, R: 13.4 m to 22.1 m, I: 6.7 m to 11 m |
| Supplement Light Type | White Light |
| Supplement Light Range | Up to 40 m |
| Smart Supplement Light | Yes |
| Sub-Stream | 50 Hz: 25 fps (1280 ?? 720, 640 ?? 480, 640 ?? 360) 60 Hz: 30 fps (1280 ?? 720, 640 ?? 480, 640 ?? 360) |
| Third Stream | 50 Hz: 10 fps (1920 ?? 1080, 1280 ?? 720, 640 ?? 480, 640 ?? 360) 60 Hz: 10 fps (1920 ?? 1080, 1280 ?? 720, 640 ?? 480, 640 ?? 360) *Third stream is supported under certain settings. |
| Video Compression | Main stream: H.265/H.264/H.265+/H.264+ Sub-stream: H.265/H.264/MJPEG Third stream: H.265/H.264 *Third stream is supported under certain settings. |
| Video Bit Rate | 32 Kbps to 8 Mbps |
| H.264 Type | Baseline Profile, Main Profile, High Profile |
| H.265 Type | Main Profile |
| Bit Rate Control | VBR, CBR |
| Main Stream | 50 Hz: 25 fps (2688 ?? 1520, 1920 ?? 1080, 1280 ?? 720) 60 Hz: 30 fps (2688 ?? 1520, 1920 ?? 1080, 1280 ?? 720) |
| Scalable Video Coding (SVC) | H.264 and H.265 encoding |
| Region Of Interest (ROI) | 1 fixed region(s) for main stream and sub-stream |
| Audio Compression | G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC |
| Audio Bit Rate | 64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC-LC) |
| Audio Sampling Rate | 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz |
| Environment Noise Filtering | Yes |
| Protocols | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, ARP, WebSocket, WebSockets |
| Simultaneous Live View | Up to 6 channels |
| API | Open Network Video Interface (Profile S, Profile G, Profile T), ISAPI, SDK |
| User/Host | Up to 32 users 3 user levels: administrator, operator, and user |
| Security | Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Interface, RTP/RTSP over HTTPS, control timeout settings, security audit log, TLS 1.1/1.2/1.3, host authentication (MAC address) |
| Network Storage | NAS (NFS, SMB/CIFS), Auto Network Replenishment (ANR) Together with high-end Hikvision memory card, memory card encryption and health detection are supported. |
| Client | iVMS-4200, Hik-Connect, Hik-Central |
| Web Browser | Plug-in required live view: IE 10, IE 11 Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Edge 89+ Local service: Chrome 57.0+, Firefox 52.0+, Edge 89+ |
| Image Parameters Switch | Yes |
| Image Settings | Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance, adjustable by client software or web browser |
| Day/Night Switch | Day, Night, Auto, Schedule |
| Wide Dynamic Range (WDR) | 140 dB |
| White Balance | Auto/Manual/ATW (Auto-tracking White Balance)/One Touch/Indoor/Outdoor/Fluorescent Lamp/Sodium Lamp |
| Gain | Auto/Manual |
| Digital Noise Reduction | 3D DNR |
| Privacy Mask | 4 programmable polygon privacy masks |
| Alarm | 3 input(s), 1 output(s) |
| Linkage Method | Trigger recording: memory card, network storage, pre-record and post-record Trigger capture: upload to FTP/memory card/network storage Trigger notification: send email, notify surveillance center, trigger alarm output, trigger capture |
| Reset | Yes |
| Startup and Operating Conditions | -40 ??C to 65 ??C (-40 ??F to 149 ??F). Humidity 95% or less (non-condensing) |
| Power Supply | 12 VDC, two-core terminal block 24 VAC, max. 0.7 A, 50/60 Hz, two-core terminal block PoE (IEEE 802.3af, Class 3) |
| Power Consumption and Current | 12 VDC, 0.6 A, max. 7 W 24 VAC, 0.4 A to 0.2 A, max. 9 W PoE (802.3af, 36 V to 57 V), 0.2 A to 0.1 A, max. 9.5 W |
| Material | Front cover: metal Body: metal Rear cover: plastic |
| Dimensions | ?? 164.6 mm ?? 155.9 mm (?? 6.48" ?? 6.14") |
| Weight | Approx. 1.9 kg (4.2 lb.) |
| Approval | EMC: CE-EMC, FCC-EMC, IC-EMC, RCM-EMC, KC-EMC Safety: UL, CB, CE-LVD, BIS Environment: CE-RoHS, WEEE, Reach, IK10, IP67 |
| On-Board Storage | Built-in memory card slot, support microSD/SDHC/SDXC, up to 256 GB Memory card is optional. |
Hikvision DS-2CD2747G2T-LZS: See Clearly, Day and Night
Illuminate Your World with the Hikvision DS-2CD2747G2T-LZS 4 MP ColorVu Motorized Varifocal Dome Network Camera. This cutting-edge surveillance solution delivers exceptional image quality, advanced features, and robust construction for unparalleled security.
Key Features:
Day and Night Clarity: Experience vivid, true-color imaging even in the most challenging lighting conditions thanks to Hikvision's groundbreaking ColorVu technology.
Intelligent Detection: Go beyond basic surveillance with advanced features like human and vehicle classification, ensuring you only focus on what matters.
Panoramic Views: Enjoy complete coverage with the motorized varifocal lens, offering flexible viewing angles to suit any environment.
Weatherproof and Vandal-Resistant: Built to withstand harsh conditions with IP67 and IK10 ratings, ensuring reliable performance in any environment.
High-Resolution Imaging: Capture every detail with a 4 MP resolution that delivers sharp, clear images.
Additional Features:
Wide Dynamic Range (WDR): Maintain image clarity in high-contrast lighting conditions.
Long-Range Infrared: See clearly even in complete darkness with the built-in infrared illuminator.
H.265+ Compression: Efficiently store video footage without compromising image quality.
Flexible Installation: Easy to install and adjust with the motorized varifocal lens.
The Hikvision DS-2CD2747G2T-LZS is more than just a camera; it's a security investment. Protect your property with advanced technology and reliable performance.
