Hikvision DS-3WF0BC-2NT 2.4 GHz 300 Mbps 200 m Elevator Wireless Bridge, Up to 200 mtr, Built-in 7dBi 2x2 MIMO Antenna, Real-Time Alarm Push
Model :
SKU : DS-3WF0BC-2NT BRIDGE
About this item
0
Inclusive of VAT
Delivery to
FREE scheduled delivery as soon as Loading...
Sold and shipped by: Adarc computers
1
About this item
Description
Specification
| Product Dimensions (W ?? H ?? D) | 90.8 mm ?? 187.87 mm ?? 57.87 mm (3.57'' ?? 7.39'' ?? 2.27'') |
| Package Dimensions (W ?? H ?? D) | 256 mm ?? 231 mm ?? 86 mm (10.07" ?? 9.09" ?? 3.38") |
| Net Weight | 0.26 kg (0.57 lb) per device |
| Gross Weight | 0.8 kg (1.76 lb) |
| Packing List | Wireless Bridge ?? 2, Power Adapter (12 VDC, 1 A) ?? 2, 10/100 Mbps PoE Injector ?? 2, Binding Tape ?? 4, Quick Start Guide ??1 |
| Packing Method | Packing in pairs |
| Working Temperature | -30 ??C to 70 ??C (-22 ??F to 158 ??F) |
| Working Humidity | 5% to 95% (no condensation) |
| Storage Temperature | -40 ??C to 80 ??C (-40 ??F to 176 ??F) |
| Storage Humidity | 5% to 95% (no condensation) |
| Installation Mode | Pole Mounting |
| Ingress Protection | IP55 |
| Power Consumption | 1.89 W for typical (1-ch 2MP IPC), Max. 3.7 W |
| Max. Transmission Rate of Air Interface | ??? 300 Mbps |
| Wireless Standard | IEEE 802.11b/g/n (2 ?? 2 MIMO 300 Mbps) |
| Working Frequency Band | 2400 MHz ~ 2483.5 MHz |
| Antenna Gain | 7 dBi |
| Antenna Angle | (H) Beamwidth [3 dB] 65?? (V) Beamwidth [3 dB] 65?? |
| Transmitting Power | 19??2 dBm (Note: Transmitting power may vary with local regulations.) |
| Receiving Sensitivity | -68 ?? 2 dBm @HT40 MCS7 |
| Throughput Rate | Point to point: Support up to 6-ch IPC (2MP) in Max. 0.2 KM distance and Max. 30 Mbps bandwidth |
| Network Interface | 2 ?? 10/100 Mbps RJ45 ports |
| LED Indicator | Power indicator, LAN indicator, Signal intensity indicator |
| Reset | Hardware resetting button |
| Power Supply | 12-24 VDC Passive PoE |
| Application Function | IFM, IPM |
| Channel Width | 10/20/40 MHz |
| Channel Selection | Auto/manual selection |
| Network Protocol | NTP (network time synchronization), SADP (auto search for IP address), HTTPS (web management), SSH (debugging) |
| Security Mode | WPA2-PSK |
| Security Mechanism | Wireless network name hidden |
| Management Method | Web, iVMS-4200, HCP |
| Upgrade | Web, iVMS-4200, HCP |
| System Log | Syslog, Control center information |
| EMC | CE-EMC (EN 55032: 2015+A11: 2020, EN IEC 61000-3-2: 2019, EN 61000-3-3: 2013+A1: 2019, EN 50130-4: 2011+A1: 2014, EN 55035: 2017+A11: 2020) |
| Safety | CB (AMD1:2009, AMD2:2013, IEC 62368-1: 2014 (Second Edition)), CE-LVD (EN 62368-1: 2014+A11: 2017) |
| Chemistry | CE-RoHS (2011/65/EU), WEEE (2012/19/EU), Reach (Regulation (EC) No.1907/2006) |
| Radio | EN 301 893, EN 300 440, EN 62311, EN 301 489-3, EN 301 489-17 |
