Hikvision DS-96128NI-H24R 128-Channel 4U 8K Super NVR, 1Gbps Bandwidth, 48-Ch 1080p Decoding, RAID 0/1/5/6/10 & N+1, ANPR & People Counting Support
10750.11Home/Network Products/Network Video Recorders/Hikvision DS-96128NI-M16/R 128-Channel 3U 4K NVR, ...
Hikvision DS-96128NI-M16/R 128-Channel 3U 4K NVR, 400Mbps Bandwidth, 8K/Dual 4K HDMI Output, RAID 0/1/5/6/10 with N+M Hot Spare, Redundant Power, IP Speaker Support
Model :
SKU : DS-96128NI-M16/R
About this item
About this item
Description
The Hikvision DS-96128NI-M16/R 128-Channel 3U 4K NVR is a high-capacity enterprise-grade network video recorder built for large-scale surveillance deployments. Designed for data centers, commercial complexes, airports, and industrial facilities, it offers reliable performance, advanced redundancy, and powerful video output capabilities.
Supporting up to 128 IP camera channels, the NVR provides 400Mbps incoming bandwidth, ensuring stable and efficient data recording. It features 8K and dual 4K HDMI output, delivering ultra-high-definition display for control rooms and monitoring centers.
For enhanced data protection, the DS-96128NI-M16/R supports RAID 0/1/5/6/10 configurations along with N+M hot spare technology, ensuring continuous operation even in the event of drive failure. The system also includes redundant power supply support, adding an extra layer of reliability for mission-critical environments.
With IP speaker support, the NVR enables integration of audio alerts and public address functionality within the surveillance ecosystem. The 3U rack-mount design makes it suitable for professional server racks and enterprise infrastructure.
The Hikvision DS-96128NI-M16/R is an ideal solution for organizations requiring scalable, secure, and high-performance surveillance recording.
Key Features
128-channel IP Network Video Recorder (NVR)
3U rack-mount enterprise design
400Mbps incoming bandwidth
8K and dual 4K HDMI video output
RAID 0/1/5/6/10 support for data protection
N+M hot spare redundancy
Redundant power supply support
IP speaker support for audio integration
Designed for large-scale and enterprise surveillance
Model: DS-96128NI-M16/R
Specification
128-Channel 3U Network Video Recorder – Technical Specifications
Video & Audio
| IP Video Input | 128 Channels |
| Incoming Bandwidth | 400 Mbps |
| Outgoing Bandwidth | 400 Mbps |
Video Output
| HDMI 1 | 7680×4320@30Hz, 3840×2160@60Hz/30Hz, 2560×1440@60Hz, 1920×1080@60Hz, 1600×1200@60Hz, 1280×1024@60Hz, 1280×720@60Hz, 1024×768@60Hz |
| HDMI 2 | 3840×2160@60Hz/30Hz, 2560×1440@60Hz, 1920×1080@60Hz, 1600×1200@60Hz, 1280×1024@60Hz, 1280×720@60Hz, 1024×768@60Hz |
| * When HDMI 1 is set to 8K resolution, HDMI 2 maximum output is limited to 1080p. | |
| VGA 1 | 1920×1080@60Hz, 1280×1024@60Hz, 1280×720@60Hz, 1024×768@60Hz |
| VGA 2 | 1920×1080@60Hz, 1280×1024@60Hz, 1280×720@60Hz, 1024×768@60Hz |
| Video Output Mode | HDMI 1 + VGA 1: Simultaneous main output HDMI 2 + VGA 2: Simultaneous auxiliary output |
| CVBS Output | 1-ch BNC (1.0 Vp-p, 75 Ω), PAL: 704×576 / NTSC: 704×480 |
| Audio Input | 1-ch, RCA (2.0 Vp-p, 1 KΩ) |
| Audio Output | 2-ch, RCA (Linear, 1 KΩ) |
| Two-Way Audio | 1-ch, RCA (Uses Audio Input) |
Decoding
| Decoding Format | H.265+, H.265, H.264+, H.264 |
| Recording Resolution | 32MP/24MP/12MP/8MP/7MP/6MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF |
| Synchronous Playback | 16-ch |
| Decoding Capability | 2-ch@32MP (30fps) 2-ch@24MP (30fps) 4-ch@16MP (30fps) 8-ch@8MP (30fps) 16-ch@4MP (30fps) 32-ch@2MP (30fps) |
| Audio Compression | G.711ulaw, G.711alaw, G.722, G.726, AAC, MP2L2, PCM |
Network
| Network Interface | 2 × RJ-45 (10/100/1000 Mbps self-adaptive) |
| Network Protocol | TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP™, HTTP, HTTPS, ONVIF (v2.2), OTAP |
| Camera Access Protocol | ONVIF (v2.5), RTSP |
RAID
| RAID Types | RAID 0, RAID 1, RAID 5, RAID 6, RAID 10 |
Storage & Interfaces
| SATA | 16 × SATA (Hot-Plug Supported) |
| eSATA | 1 × eSATA |
| Max HDD Capacity | Up to 16 TB per Disk |
| Serial Interface | 1 × RS-485 (Full-duplex), 1 × RS-232 |
| Alarm In/Out | 16 / 9 |
| USB | Front: 2 × USB 2.0 Rear: 2 × USB 3.0 |
| Ctrl 12V | 12 VDC, 1 A (Triggered by Alarm Output 9) |
| DC 12V Output | 12 VDC, 1 A |
General
| Power Supply | 100–240 VAC, 50–60 Hz (Redundant Power Supply) |
| Power Consumption | ≤ 50 W (Without HDD) |
| Working Temperature | -10 °C to 55 °C (14 °F to 131 °F) |
| Working Humidity | 10% to 90% |
| Chassis | 3U Rackmount |
| Dimensions (W × D × H) | 445 × 496 × 150 mm (17.5" × 19.5" × 5.9") |
| Weight | ≤ 12.5 kg (Without HDD) |
Certification
| Certifications | CE, FCC |
| FCC | Part 15 Subpart B, ANSI C63.4-2014 |
| CE | EN 55032:2015, EN 61000-3-2, EN 61000-3-3, EN 50130-4 |
