Hikvision DS-QAE1A80G1-VB 80W 2-Zone Network Amplifier, USB/Bluetooth/MIC/RCA
Model :
SKU : DS-QAE1A80G1-VB Amplifie
About this item
0
Inclusive of VAT
Delivery to
FREE scheduled delivery as soon as Loading...
Sold and shipped by: Adarc computers
1
About this item
Description
Specification
| Function | |
|---|---|
| Network | |
| Audio | |
| Interface | |
| General | |
| Audio Bit Rate | G.711ulaw (64 Kbps) / G.711alaw (64 Kbps) / MP3 (128 Kbps) Sampling bit width: 16 bits |
| Speech Synthesis | Language Type: English, Russian, Spanish, Japanese, Thai, Portuguese (Brazil), Korean, French |
| Protection Function | Short circuit protection, overcurrent protection, over temperature protection, anti-static electricity protection, surge protection, electrical shock protection |
| Network Protocol | IPv4, HTTP, HTTPS, SSL/TLS, DNS, NTP, TCP, UDP, IGMP, ICMP, DHCP, ARP, SSH |
| Interface Protocol (API) | ISAPI, ISUP, RTP |
| Rated Power | 80 W, 24 VDC |
| Frequency Response | 80 Hz to 20 kHz (±3 dB) |
| THD and SNR | THD: ≤1% SNR: ≥100 dB |
| Alarm | 1 alarm input, 1 alarm output |
| Ethernet Interface | 1 × RJ45 10 M/100 M adaptive Ethernet port |
| Local Storage | Built-in 4 GB EMMC (Audio file storage is 1 GB) |
| Audio In | MIC 1: -28 dBV, 2.57 KΩ, unbalanced, 6.35 mm jack (supports dynamic microphone) USB 2.0 × 1 RCA in 1-2: 0 dBV, 5 KΩ, unbalance, RCA pin jack Bluetooth |
| Audio Out | Constant Voltage Output × 2, 100 V COM RCA Out 1-2: 0 dBV, 100 Ω, unbalance, RCA pin jack RCA Cascading: support cascade up to 3 amplifiers |
| LED Indicator | Power indicator (solid white): device normally working USB flash drive indicator (solid white): USB mode Bluetooth indicator (solid blue): Bluetooth mode |
| Volume Knob | MIC Volume Knob × 1, Partition 1 Volume Knob × 1, Partition 2 Volume Knob × 1 |
| USB | USB 2.0/3.0 File format: FAT32, max capacity: 128 GB FAT32 file system: max partition size: 128 GB, max file size: 4 GB |
| Power Interface | Aperture size: Ø2.0 mm |
| Material | Plastic |
| Language | 41 languages: English, French, Spanish, German, Italian, Japanese, Thai, Russian, Portuguese (Brazil), Arabic, Bulgarian, Czech, Danish, Greek, Spanish (Mexico), Estonian, Persian, Finnish, Hebrew, Croatian, Hungarian, Indonesian, Kazakh, Korean, Kirgiz, Lao, Lithuanian, Latvian, Dutch, Norwegian, Polish, Portuguese, Romanian, Slovak, Slovenian, Serbian, Swedish, Turkish, Ukrainian, Uzbek, Vietnamese |
| Dimension | 190.8 mm × 230.8 mm × 51.2 mm (7.48" × 9.06" × 2.01") |
| Package Dimension | 362 mm × 280 mm × 100 mm (14.25" × 11.02" × 3.94") |
| Net Weight | ≈ 1496.2 g (3.3 lb.) |
| With Package Weight | ≈ 2456.2 g (5.4 lb.) |
| Color | White |
| Packing List | Device × 1, Power Adapter × 1, Power Cord × 1, Regulatory Compliance and Safety Information × 1 |
| Bluetooth | Bluetooth 5.0, 10 m |
| Operating Temperature | -10 °C to 55 °C (14 °F to 131 °F) |
| Operating Humidity | <90% (No condensation) |
| Power Consumption | Standby: 4.5 W Annual Average Consumption: Max. Working Consumption: 90 W (based on average playing time) |
