Huawei AC650-128AP Wireless Access Controller, mainframe (10*GE ports, 2*10GE SFP+ ports, with the AC/DC adapter)
Model :
SKU : AC650-128AP-b2b
0
Inclusive of VAT
Delivery to
FREE scheduled delivery as soon as Loading...
Sold and shipped by: Adarc computers
About this item
Description
Huawei AC650-128AP Wireless Access Controller
The Huawei AC650-128AP is a sophisticated wireless access controller (AC) designed by Huawei specifically for the SME Network markets. This device collaborates seamlessly with Huawei access points (APs) to create robust wireless networks suitable for a variety of environments, including small campus networks, office networks for small enterprises, and extensive hotspot coverage areas.
With the capability to manage up to 128 access points, the Huawei AC650-128AP Dubai can support a maximum of 2048 simultaneous STAs (Station Access Points), ensuring reliable and efficient network connectivity for numerous devices. This makes it an ideal solution for small to medium-sized businesses looking to establish or enhance their wireless networking infrastructure.
Technical Specifications
| Description | AC650-128AP mainframe (10*GE ports, 2*10GE SFP+ ports, with the AC/DC adapter) |
| Part Number | 02355NCG |
| Model | AC650-128AP |
| First Supported Version | V200R022C10 |
| Installation Type | Rack, Desk, Wall |
| Dimensions without Packaging (H x W x D) | Basic: 43.6 mm x 250 mm x 210 mm (1.72 in. x 9.84 in. x 8.27 in.) Maximum: 43.6 mm x 250 mm x 215 mm (1.72 in. x 9.84 in. x 8.46 in.) |
| Weight without Packaging | 1.9 kg (4.19 lb) |
| Storage | NAND FLASH 1GB |
| Console Port | RJ45 |
| Maximum Power Consumption | 23.58 W |
| Maximum Heat Dissipation | 80.45 BTU/hour |
| Power Supply Mode | DC Adapter |
| Service Port Surge Protection | 6 kV in Common Mode |
| Types of Fans | None |
| Maximum Physical Ports | 2 x 10GE (SFP+) + 10 x GE (RJ45) |
| Long-Term Operating Temperature | 0??C to 45??C (32??F to 113??F) (Temperature decreases by 1??C or 1.8??F every 300 m above 1800 m.) |
| Storage Temperature | ???40??C to +70??C (???40??F to +158??F) |
| Operating Relative Humidity | 5% RH to 95% RH, Non-condensing |
| Operating Altitude | ???60 m to +5000 m (???196.85 ft to +16404.20 ft) |
| Atmospheric Pressure | 53 kPa ??? 106 kPa ETSI 300 019-2-3 |
| Ground | Ground |
| USB | 1 x USB 2.0 (Host Type A) Port |
| MTBF | 50 Years |
| MTTR | 2 Hours |
Specification
Huawei AC650-128AP Wireless Access Controller
The Huawei AC650-128AP is a sophisticated wireless access controller (AC) designed by Huawei specifically for the SME Network markets. This device collaborates seamlessly with Huawei access points (APs) to create robust wireless networks suitable for a variety of environments, including small campus networks, office networks for small enterprises, and extensive hotspot coverage areas.
With the capability to manage up to 128 access points, the Huawei AC650-128AP Dubai can support a maximum of 2048 simultaneous STAs (Station Access Points), ensuring reliable and efficient network connectivity for numerous devices. This makes it an ideal solution for small to medium-sized businesses looking to establish or enhance their wireless networking infrastructure.
Technical Specifications
| Description | AC650-128AP mainframe (10*GE ports, 2*10GE SFP+ ports, with the AC/DC adapter) |
| Part Number | 02355NCG |
| Model | AC650-128AP |
| First Supported Version | V200R022C10 |
| Installation Type | Rack, Desk, Wall |
| Dimensions without Packaging (H x W x D) | Basic: 43.6 mm x 250 mm x 210 mm (1.72 in. x 9.84 in. x 8.27 in.) Maximum: 43.6 mm x 250 mm x 215 mm (1.72 in. x 9.84 in. x 8.46 in.) |
| Weight without Packaging | 1.9 kg (4.19 lb) |
| Storage | NAND FLASH 1GB |
| Console Port | RJ45 |
| Maximum Power Consumption | 23.58 W |
| Maximum Heat Dissipation | 80.45 BTU/hour |
| Power Supply Mode | DC Adapter |
| Service Port Surge Protection | 6 kV in Common Mode |
| Types of Fans | None |
| Maximum Physical Ports | 2 x 10GE (SFP+) + 10 x GE (RJ45) |
| Long-Term Operating Temperature | 0??C to 45??C (32??F to 113??F) (Temperature decreases by 1??C or 1.8??F every 300 m above 1800 m.) |
| Storage Temperature | ???40??C to +70??C (???40??F to +158??F) |
| Operating Relative Humidity | 5% RH to 95% RH, Non-condensing |
| Operating Altitude | ???60 m to +5000 m (???196.85 ft to +16404.20 ft) |
| Atmospheric Pressure | 53 kPa ??? 106 kPa ETSI 300 019-2-3 |
| Ground | Ground |
| USB | 1 x USB 2.0 (Host Type A) Port |
| MTBF | 50 Years |
| MTTR | 2 Hours |
