Model :
SKU : IMOU IPC-S76DP-13M0N
Performance / Technology
The intelligence of the Cruiser Pano Z lies in its automated tracking. When a person or vehicle enters the panoramic frame, the camera's algorithm can direct the 5MP PTZ lens to lock onto the subject, utilizing its 12x Mixed Zoom to follow the target as they move across the property. This ensures that you have highly detailed evidence of any intrusion, rather than just a blurry shape in the distance.
Design & Deployment Strategy
When deploying this camera, placement is critical. To take full advantage of the panoramic 4+4MP lenses, the camera should be mounted relatively high up (such as on the corner of a building or a sturdy pole) with an unobstructed view of the target area. Setup Note: Ensure that the installation location has a strong, stable Wi-Fi signal or a dedicated Ethernet connection to handle the high-bandwidth transmission required for streaming simultaneous multi-lens high-definition video feeds.
Why This Product Stands Out
The IMOU Cruiser Pano Z stands out by bringing enterprise-level multi-sensor technology down to the consumer and small business market. It completely solves the "blind spot" problem inherent to moving cameras, providing total situational awareness and incredibly detailed zoomed-in tracking in a single, easy-to-install unit.
Feature | Specification |
|---|---|
Fixed Lens - Image Sensor | 1/3” Progressive CMOS |
Fixed Lens - Max Resolution | 4MP+4MP (2560*1440) |
Fixed Lens - Night Vision | Warm Light: 30m (98ft) IR: 30m (98ft) |
Fixed Lens - Focal Length | 3.6mm F1.6 |
Fixed Lens - Spliced Field of View | 158°(H), 47°(V), 165°(D) |
Pan & Tilt Lens - Image Sensor | 1/3” Progressive CMOS |
Pan & Tilt Lens - Max Resolution | 5MP (2880*1620) |
Pan & Tilt Lens - Night Vision | Warm Light: 56m Max (184ft) IR: 56m Max (184ft) |
Pan & Tilt Lens - Focal Length | 2.8mm+12mm F1.6 |
Pan & Tilt Lens - Max Field of View | 94°(H), 52°(V), 111°(D) |
Wireless Connectivity | 2.4GHz & 5GHz Dualband Wi-Fi 6 2.4GHz: IEEE802.11b/g/n/ax 5GHz: IEEE802.11a/n/ac/ax |
Wired Interface | 1 x 100Mbps Ethernet Port |
Software & Protocols | Imou App (iOS, Android), ONVIF |
Video Compression | H.265 / H.264 |
Video Frame Rate | Up to 15 fps |
Zoom Capabilities | 12× Mixed Zoom |
Audio & Alerts | Built-in Mic & Speaker, Warning Lights |
Storage Expansion | Micro SD Card (Up to 1024GB) |
Reset Button | Supported |
Smart Detection | Motion, Human, Vehicle |
Power Supply | DC 12V 1.5A Power Supply / PoE (802.3at) |
Power Consumption | < 18W |
Material | Plastic |
Working Environment | -30℃ to +50℃, Less Than 95% RH |
Dimensions (L×W×H) | 126.18 × 161.39 × 202.4 mm (4.97 × 6.35 × 7.97 inch) |
Weight | 698g |
Certification | CE |
