About this item
Description
| Essentials | |
| Product Collection | 13th Generation Intel?? Core??? i5 Processors |
| Code Name | Products formerly Raptor Lake |
| Vertical Segment | Desktop |
| Processor Number | i5-13500 |
| Lithography | Intel 7 |
| Use Conditions | PC/Client/Tablet |
| CPU Specifications | |
| Total Cores | 14 |
| # of Performance-cores | 6 |
| # of Efficient-cores | 8 |
| Total Threads | 20 |
| Max Turbo Frequency | 4.80 GHz |
| Performance-core Max Turbo Frequency | 4.80 GHz |
| Efficient-core Max Turbo Frequency | 3.50 GHz |
| Performance-core Base Frequency | 2.50 GHz |
| Efficient-core Base Frequency | 1.80 GHz |
| Cache | 24 MB Intel?? Smart Cache |
| Total L2 Cache | 11.5 MB |
| Processor Base Power | 65 W |
| Maximum Turbo Power | 154 W |
| Memory Specifications | |
| Max Memory Size (dependent on memory type) | 128 GB |
| Memory Types | Up to DDR5 4800 MT/s Up to DDR4 3200 MT/s |
| Max # of Memory Channels | 2 |
| Max Memory Bandwidth | 76.8 GB/s |
| ECC Memory Supported ??? | Yes |
| Processor Graphics | |
| Processor Graphics ??? | Intel?? UHD Graphics 770 |
| Graphics Max Dynamic Frequency | 1.55 GHz |
| Graphics Base Frequency | 300 MHz |
| Graphics Output | eDP 1.4b, DP 1.4a, HDMI 2.1 |
| Execution Units | 32 |
| Max Resolution (HDMI)??? | 4096 x 2160 @ 60Hz |
| Max Resolution (DP)??? | 7680 x 4320 @ 60Hz |
| Max Resolution (eDP - Integrated Flat Panel)??? | 5120 x 3200 @ 120Hz |
| DirectX* Support | 12 |
| OpenGL* Support | 4.5 |
| OpenCL* Support | 3.0 |
| Multi-Format Codec Engines | 2 |
| Intel?? Quick Sync Video | Yes |
| Intel?? Clear Video HD Technology | Yes |
| # of Displays Supported ??? | 4 |
| Device ID | 0x4680 |
| Expansion Options | |
| Direct Media Interface (DMI) Revision | 4.0 |
| Max # of DMI Lanes | 8 |
| Scalability | 1S Only |
| PCI Express Revision | 5.0 and 4.0 |
| PCI Express Configurations ??? | Up to 1x16+4, 2x8+4 |
| Max # of PCI Express Lanes | 20 |
| Package Specifications | |
| Max CPU Configuration | 1 |
| Thermal Solution Specification | PCG 2020C |
| TJUNCTION | 100??C |
| Package Size | 45.0 mm x 37.5 mm |
| Advanced Technologies | |
| Intel?? Gaussian & Neural Accelerator | 3.0 |
| Intel?? Thread Director | Yes |
| Intel?? Deep Learning Boost (Intel?? DL Boost) | Yes |
| Intel?? Speed Shift Technology | Yes |
| Intel?? Turbo Boost Max Technology 3.0 ??? | No |
| Intel?? Turbo Boost Technology ??? | 2.0 |
| Intel?? Hyper-Threading Technology ??? | Yes |
| Intel?? 64 ??? | Yes |
| Instruction Set | 64-bit |
| Instruction Set Extensions | Intel?? SSE4.1, Intel?? SSE4.2, Intel?? AVX2 |
| Idle States | Yes |
| Enhanced Intel SpeedStep?? Technology | Yes |
| Thermal Monitoring Technologies | Yes |
| Intel?? Volume Management Device (VMD) | Yes |
| Security & Reliability | |
| Intel?? Standard Manageability (ISM) ??? | Yes |
| Intel?? Control-Flow Enforcement Technology | Yes |
| Intel?? AES New Instructions | Yes |
| Secure Key | Yes |
| Intel?? OS Guard | Yes |
| Execute Disable Bit ??? | Yes |
| Intel?? Boot Guard | Yes |
| Mode-based Execute Control (MBEC) | Yes |
| Intel?? Virtualization Technology (VT-x) ??? | Yes |
| Intel?? Virtualization Technology for Directed I/O (VT-d) ??? | Yes |
| Intel?? VT-x with Extended Page Tables (EPT) ??? | Yes |
| Warranty | 3 Years |
| Note | *** Features, Price, Specifications are subject to change without notice. |
