IP-COM W63AP AC1200 Wave 2 Gigabit 2.4 GHz, 5 GHz, Access Point | W63AP
Model :
SKU : WAP-IP-COM W63AP
About this item
- Gigabit port
- Up to 1167 Mbps dual-band data rate
- MU-MIMO for high throughput
- Supports to be centrally managed by all IP-COM access controllers (AC) and enterprise routers that includes AC functionality
Description
Product Information
| Model | W63AP |
| Appearance | Ceiling |
| Dimensions | 178 mm * 178 mm * 38 mm |
Hardware Features
| Frequency Band | 2.4 GHz, 5 GHz |
| Wireless Standards | IEEE 802.11a/b/g/n/ac |
| 2.4 GHz Data Rate | 1 - 300 Mbps |
| 5 GHz Data Rate | 6 - 867 Mbps |
| Ethernet Port | 1*10/100/1000 Base-TX port |
| Button | 1*Reset |
| LED Indicator | 1*Power |
| Max. Power Consumption | Full-load 11.5W |
| Power Supply Standard | IEEE 802.3af |
Software Specifications
| Operating Modes | AP, Client + AP |
| Hide SSID | Supported |
| Max. No. of SSID | 2.4 GHz: 8 5 GHz: 4 |
| Max. Connected Clients | 2.4 GHz: 128 5 GHz: 128 |
| WEP | Supported |
| WPA-PSK | AES/TKIP |
| WPA2-PSK | AES/TKIP |
| WPA | Supported |
| WPA2 | Supported |
| Access Control | MAC Address-Based |
| Adjustable Power Transmit | Supported |
| 802.11 k/v/r | Supported |
| Frequency Analysis | Supported |
| AP Isolation | Supported |
| Connected Clients Control | Supported |
| RSSI Threshold | Supported |
| WMM | Supported |
| VLAN Tagging for SSID | Supported |
| Antenna Gain | 4 dBi |
Environmental and Power Specifications
| Operating Temperature | -10??C to 45??C |
| Operating Humidity | 10%-90% RH, Non-condensing |
| Storage Temperature | -30??C to 70??C |
| Storage Humidity | 10%-90% RH, Non-condensing |
Packaging
- Wireless Ceiling AP: 1
- Bracket: 1
- Plastic Nut: 4
- Plastic Anchor: 4
- Screw: 4
- Quick Installation Guide: 1
- GPL: 1
Certificates
- CE
- FCC
- RoHS
Specification
Product Information
| Model | W63AP |
| Appearance | Ceiling |
| Dimensions | 178 mm * 178 mm * 38 mm |
Hardware Features
| Frequency Band | 2.4 GHz, 5 GHz |
| Wireless Standards | IEEE 802.11a/b/g/n/ac |
| 2.4 GHz Data Rate | 1 - 300 Mbps |
| 5 GHz Data Rate | 6 - 867 Mbps |
| Ethernet Port | 1*10/100/1000 Base-TX port |
| Button | 1*Reset |
| LED Indicator | 1*Power |
| Max. Power Consumption | Full-load 11.5W |
| Power Supply Standard | IEEE 802.3af |
Software Specifications
| Operating Modes | AP, Client + AP |
| Hide SSID | Supported |
| Max. No. of SSID | 2.4 GHz: 8 5 GHz: 4 |
| Max. Connected Clients | 2.4 GHz: 128 5 GHz: 128 |
| WEP | Supported |
| WPA-PSK | AES/TKIP |
| WPA2-PSK | AES/TKIP |
| WPA | Supported |
| WPA2 | Supported |
| Access Control | MAC Address-Based |
| Adjustable Power Transmit | Supported |
| 802.11 k/v/r | Supported |
| Frequency Analysis | Supported |
| AP Isolation | Supported |
| Connected Clients Control | Supported |
| RSSI Threshold | Supported |
| WMM | Supported |
| VLAN Tagging for SSID | Supported |
| Antenna Gain | 4 dBi |
Environmental and Power Specifications
| Operating Temperature | -10??C to 45??C |
| Operating Humidity | 10%-90% RH, Non-condensing |
| Storage Temperature | -30??C to 70??C |
| Storage Humidity | 10%-90% RH, Non-condensing |
Packaging
- Wireless Ceiling AP: 1
- Bracket: 1
- Plastic Nut: 4
- Plastic Anchor: 4
- Screw: 4
- Quick Installation Guide: 1
- GPL: 1
Certificates
- CE
- FCC
- RoHS
