Model :
SKU : CF-LIAN UNI FAN TL120 W R
Noise-optimized and performance-oriented fan.
LCP (liquid crystal polymer) fan blades are used for tight tolerance.
FDB bearing with copper shielding to ensure stable rotation of the impeller.
Enlarged infinity mirror around the frame with a longer light guide for a unified daisy-chained look.
Features two light zones for increased lighting customizability.
UNIFAN interlocking system for ease of cable management.
Cable connection is supported on both sides of the fan.
Support up to 10 fans per controller port via a daisy-chain POGO cable.
LED lighting and fan speed controller shared with UNIFAN TL LCD.
Complete software control with L-Connect 3.
The controller is required to use the fans.
| Model Name | UNI FAN TL 120 Reverse Blade / UNI FAN TL 140 Reverse Blade |
| Model No. | 12RTL3B / 12RTL3W / 12RTL1B / 12RTL1W / 14RTL1B / 14RTL1W |
| Color | Black / White |
| Number of Fans | 3 / 3 / 1 / 1 / 1 / 1 |
| Controller | Yes / No / No |
| Connector Type | UNI FAN Controller Cable x 1 (P-7P), Extension Cable x 1 (P-P), Power Adapter Cable x 1 (P-SA) UNI FAN Controller Cable x 1 (P-7P), Extension Cable x 1 (P-P) UNI FAN Controller Cable x 1 (P-7P), Extension Cable x 1 (P-P) |
| Fan Dimension | 124 × 120 × 28 mm (120mm) / 144 × 140 × 28 mm (140mm) |
| Fan Speed | 0, 200 ~ 2300 RPM (120mm) / 0, 200 ~ 1800 RPM (140mm) |
| Max. Air Pressure | 2.66 mmH₂O (120mm) / 2.27 mmH₂O (140mm) |
| Max. Airflow | 83.4 CFM (120mm) / 101.6 CFM (140mm) |
| Acoustic Noise | 34 dB(A) Max (120mm) / 31 dB(A) Max (140mm) |
| Input Power | 4.5W (120mm) / 4.6W (140mm) |
| Material | PA66 / LCP |
| Rated Voltage | DC 12V (Fan) & 5V (LED) |
| Bearing Type | Fluid Dynamic Bearing (FDB) |
| Operate Voltage | DC 12V & 5V |
| Warranty | 3 years |
