MSI MAG B850 TOMAHAWK MAX WIFI ATX AM5 Motherboard, 4x DDR5 UDIMM, Max Memory 256GB upto 8400+ MT/s (OC), PCIe 5.0 x16, M.2 Gen5, Wi-Fi 7 | 911-7E62-002
Model :
SKU : MB-MSI MAG B850 TOMA MA W
About this item
About this item
Description
Supports AMD Ryzen™ 9000 / 8000 / 7000 Series Desktop Processors
Supports DDR5 Memory, Dual Channel DDR5 8200+ MT/s (OC)
Ultra Performance: 14+2+1 Duet Rail Power System, dual 8-pin CPU power connectors, Core Boost, Memory Boost, 6-layer PCB made by 2oz thickened copper and server-grade level 6aterial
Frozr Guard: Extended Heatsink, MOSFET thermal pads rated for 7W/mK, additional choke thermal pads and EZ M.2 Shield Frozr II are built for high performance system and non-stop experience
EZ DIY: EZ M.2 Shield Frozr II, EZ PCIe Release, EZ M.2 Clip II and EZ Antenna
Lightning Fast Game experience: PCIe 5.0 slot, Lightning Gen 5 x4 M.2, Front USB Type-C
5G LAN with Wi-Fi 7 Solution: the latest solution for professional and multimedia use, delivering secure, stable, and high-speed networking and data transmission
Audio Boost 5: Reward your ears with studio-grade sound quality for the most immersive gaming experience
Specification
MSI MAG B850 TOMAHAWK MAX WIFI ATX AM5 Motherboard, 4x DDR5 UDIMM, Max Memory 256GB upto 8400+ MT/s (OC), PCIe 5.0 x16, M.2 Gen5, Wi-Fi 7 | 911-7E62-002 Specifications
| Chipset | AMD B850 |
| CPU Support | Supports AMD Ryzen??? 9000/ 8000/ 7000 Series Desktop Processors |
| Socket | AM5 |
| Memory | 4x DDR5 UDIMM, Maximum Memory Capacity 256GB |
| Memory Support | DDR5 8400 - 5600 (OC) MT/s / 5600 - 4800 (JEDEC) MT/s |
| Ryzen??? 9000 Series Overclocking |
|
| Memory Features | Supports AMD POR Speed and JEDEC Speed, Memory Overclocking, AMD EXPO???, Dual-Channel Mode, Non-ECC, Un-buffered Memory, CUDIMM (Clock Driver bypass mode only) |
| Onboard Graphics | 1x HDMI??? 2.1 with FRL, supporting 8K 60Hz (Available only on processors with integrated graphics) |
| PCIe Slots |
|
| Audio | Realtek?? ALC4080 Codec, 7.1-Channel USB High-Performance Audio, S/PDIF Output |
| Storage | 4x M.2 (PCIe 5.0/4.0) & 4x SATA 6G |
| RAID Support | RAID 0, RAID 1, RAID 10 (M.2 NVMe storage devices, supported by AMD Ryzen 9000/7000 series CPUs) |
| USB Ports |
|
| LAN | 1x Realtek?? 8126 5G LAN |
| Wireless & Bluetooth | Wi-Fi 7, Bluetooth 5.4, MLO, 4KQAM |
| Internal I/O |
|
| LED Features | 4x EZ Debug LED, 1x EZ Digit Debug LED, 1x EZ Memory Detection LED |
