Model :
SKU : MB-MSI B860 GAMING PLU WI
Support Intel® Core™ Ultra Processors (Series 2) for LGA 1851 socket
Supports DDR5 Memory, Dual Channel DDR5 8800
Ultra Connect: Thunderbolt™ 4 port
Performance / Technology
Mid-range motherboards often fail under heavy thermal loads, but the B860 GAMING PLUS WIFI utilizes an extended heatsink design and heavy-duty thermal pads. The 12+1+1+1 Duet Rail Power System ensures that even under sustained 100% CPU utilization, the VRMs (Voltage Regulator Modules) remain ice cold, preventing your processor from thermal throttling when rendering video or streaming.
Design & Deployment Strategy
The standard ATX form factor provides maximum room for expansion, ensuring excellent clearance between your CPU cooler, RAM, and massive modern graphics cards. Builder Tip: MSI's EZ M.2 Clip system allows you to install NVMe SSDs entirely tool-free, eliminating the frustration of dropping microscopic screws onto your motherboard during installation.
Why This Product Stands Out
The MSI B860 GAMING PLUS WIFI stands out by offering enthusiast-tier networking capabilities—specifically 5G LAN and Wi-Fi 7—on a highly accessible B-series chipset. It provides everyday gamers and system integrators with the absolute best quality-of-life features without the inflated cost of a flagship Z890 overclocking board.
Feature | Specification |
|---|---|
Model & Form Factor | MSI B860 GAMING PLUS WIFI | ATX (243.84 x 304.8 mm) |
Chipset & CPU Socket | Intel® B860 | LGA 1851 (Supports Intel® Core™ Ultra Processors - Series 2) |
Memory (RAM) | 4x DDR5 UDIMM (Max 256GB) | Up to 8800+ MT/s (OC) Supports Intel® XMP 3.0 & CUDIMM |
Expansion Slots | 1x PCIe 5.0 x16 (From CPU) 1x PCIe 4.0 x4 | 2x PCIe 4.0 x1 (From Chipset) |
Storage Configuration | 1x M.2 PCIe 5.0 x4 (CPU) 2x M.2 PCIe 4.0 (x4 & x2) | 4x SATA 6G (Supports RAID 0, 1, 5, 10) |
Networking & Wireless | Intel® Killer E5000 5Gbps LAN Wi-Fi 7 (Intel® Killer™ BE1750x) & Bluetooth® 5.4 |
Advanced Data & Video | 1x Thunderbolt™ 4 Type-C (Rear, 40Gbps, PD 15W, Supports DP 2.1 up to 8K) 1x HDMI 2.1 (4K@60Hz) | 1x DisplayPort 1.4 (4K@60Hz) |
USB Ports (Rear Panel) | 1x Thunderbolt 4 (Type-C) | 2x USB-A (10Gbps) | 2x USB-A (5Gbps) | 4x USB 2.0 |
Audio Interface | Realtek® ALC897 Codec (7.1-Channel HD Audio) |
Internal Headers / Misc | EZ Debug LED | Clear CMOS Button (Rear Panel) | PCIe 8-pin Power Connector | Thunderbolt 5 Card Connector (JTBT5) |
