MSI B860M GAMING PLUS WIFI LGA 1851 mATX Motherboard, 4x DDR5 UDIMM, Max 256GB 8800+ MT/s (OC), PCIe 5.0 slot, Lightning Gen 5 x4 M.2, Front USB Type-C, 5G LAN Wi-Fi 7, BT 5.4, Realtek ALC897 Codec | 911-7E42.003
Model :
SKU : MB-MSI B860M GAMI PLU WIF
About this item
About this item
Description
The B860M GAMING PLUS WIFI marks a significant evolution for the MSI Gaming series. Engineered for the Intel B860 chipset, this motherboard is optimized for the "Arrow Lake" architecture, ensuring seamless compatibility with the latest Intel Core Ultra (Series 2) processors. As an AI Ready platform, it provides specialized signal routing and power delivery to support NPU-heavy workloads, ensuring your system is prepared for the next era of intelligent software.
Dominant Networking: WiFi 7 and 5G LAN
Connectivity is where this board truly shines. It features the latest WiFi 7 standard, which introduces 320MHz channels and Multi-Link Operation (MLO) for dramatically higher speeds and lower latency compared to previous wireless generations. For wired enthusiasts, the onboard 5G LAN provides five times the bandwidth of standard Gigabit Ethernet, making it ideal for lightning-fast file transfers, 4K streaming, and competitive online play without bottlenecks.
Elite Power Delivery & Thermal Cooling
To extract the maximum frequency from Intel's high-efficiency architecture, the board utilizes a robust Duet Rail Power System with high-quality components. Cooling is prioritized through extended heatsinks and the M.2 Shield Frozr, which protects your NVMe storage from thermal throttling. The 6-layer PCB with thickened copper ensures superior signal integrity, allowing for extreme DDR5 memory overclocking and overall system stability under heavy load.
EZ-DIY Features & Future-Proof Storage
MSI has integrated several "EZ-DIY" innovations to make building and upgrading easier than ever. The EZ M.2 Clip allows for tool-less SSD installation, while the EZ PCIe Latch simplifies the removal of heavy graphics cards. With PCIe 5.0 support, the primary x16 slot offers the massive bandwidth required for next-generation flagship GPUs. Additionally, the MSI Center software allows for centralized control over your fans, performance profiles, and Mystic Light RGB synchronization.
Why the MSI B860M GAMING PLUS WIFI Stands Out
LGA 1851 Native: Built specifically for the latest Intel Core Ultra (Series 2) processors.
Flagship Connectivity: Integrated WiFi 7 and 5G LAN for the ultimate networking pipeline.
PCIe 5.0 Readiness: Future-proof slot for the fastest graphics cards.
Compact Power: Full-sized gaming performance in a versatile Micro-ATX form factor.
Specification
| Chipset | INTEL B860 |
|---|---|
| CPU | Supports Intel Core Ultra Processors (Series 2), LGA 1851 |
| Memory | 4x DDR5 UDIMM, Maximum 256GB Support: 8800 - 6400 (OC) MT/s / 6400 - 4800 (JEDEC) MT/s Max OC Frequency: 1DPC 1R: up to 8800+ MT/s 1DPC 2R: up to 7200+ MT/s 2DPC 1R: up to 6400+ MT/s 2DPC 2R: up to 5600+ MT/s Supports Intel POR Speed, JEDEC, XMP 3.0, Dual-Channel, Non-ECC, Un-buffered, CUDIMM Single-sided latch DIMM slots |
| Onboard Graphics | 1x HDMI (2.1, up to 4K 60Hz) 1x DisplayPort (1.4, up to 4K 60Hz) 1x USB-C DisplayPort (Thunderbolt 4, up to 4K@120Hz / 8K@60Hz) Depends on CPU with iGPU |
| Expansion Slots | 4x PCI-E x16: PCI_E1: PCIe 5.0 x16 (CPU) PCI_E2: PCIe 4.0 x1 (Chipset) PCI_E3: PCIe 4.0 x1 (Chipset) PCI_E4: PCIe 4.0 x4 (Chipset) |
| Audio | Realtek ALC897 Codec, 7.1-Channel HD Audio |
| Storage | 3x M.2: M.2_1 (CPU): PCIe 5.0 x4 (2280/2260/2242) M.2_2 (Chipset): PCIe 4.0 x4 (2280/2260) M.2_3 (Chipset): PCIe 4.0 x2 (2280) 4x SATA 6Gb/s Refer to manual for SSD heatsink restrictions |
| RAID | Supports RAID 0/1/5/10 for SATA |
| Thunderbolt | 1x Thunderbolt 4 (Rear) Up to 40Gbps (Thunderbolt), 20Gbps (USB4), 10Gbps (USB 3.2) Up to 5V/3A (15W) charging Supports daisy-chain & up to 8K display |
| USB Ports | Rear: 2x USB 2.0, 2x USB 5Gbps Type-A, 1x USB 5Gbps Type-C, 1x USB 10Gbps Type-A Front: 4x USB 2.0, 4x USB 5Gbps Type-A, 1x USB 10Gbps Type-C |
| LAN | Intel Killer E5000 5Gbps LAN |
| Wireless & Bluetooth | Intel Killer BE1750x Wi-Fi 7 MU-MIMO TX/RX, 2.4GHz / 5GHz / 6GHz (up to 5.8Gbps) Bluetooth 5.4, MLO, 4KQAM |
| Internal I/O | 1x Thunderbolt5 card header 1x ATX_PWR, 2x CPU_PWR, 1x PCIE_PWR 1x CPU Fan, 1x Pump_Sys Fan, 3x Sys Fan 1x EZ Conn (JAF_1), 2x JFP, 1x JCI, 1x JAUD, 1x JCOM 1x JDASH, 2x JARGB_V2, 1x JRGB 1x TPM 2.0 Header 4x USB 2.0, 4x USB 5Gbps Type-A, 1x USB 10Gbps Type-C |
| LED Features | 4x EZ Debug LED |
| Back Panel Ports | DisplayPort, HDMI, Thunderbolt 4 (Type-C), USB 2.0, USB 5Gbps (Type-A/Type-C), USB 10Gbps (Type-A), Clear CMOS, 5G LAN, Wi-Fi/Bluetooth, Audio connectors |
| Operating System | Windows 11 64-bit |
| Form Factor | mATX, 243.84mm x 243.84mm |
