MSI MAG PANO 130R PZ Mid-Tower Case, Support Back-Connect Motherboards, Panoramic 270° View, 3x Pre-installed Reverse ARGB Fans, Vertical GPU Ready | 306-7G32R21-HH9

Model :

SKU : ATX-MSI PANO 130R PZ BLK

About this item

The MSI MAG PANO 130R PZ WHITE is a stunning panoramic mid-tower chassis designed for enthusiasts who want a clean, "zero-cable" aesthetic. Featuring support for PROJECT ZERO back-connect motherboards, it hides clutter behind the tray while providing a 270-degree view of your internal components through seamless tempered glass. Pre-installed with three reverse-blade ARGB fans and a rotatable GPU bracket, this case blends high-performance airflow with unmatched visual elegance.

dirham-symbol0

Inclusive of VAT

Delivery to

FREE scheduled delivery as soon as Loading...

Sold and shipped by: Adarc computers

1

AED 0.00

stock : 1

About this item

Description

Reimagine your PC build with the MSI MAG PANO 130R PZ. This chassis represents the pinnacle of modern "fish-tank" case design, offering a breathtaking panoramic view of your hardware. Specifically engineered to support the latest Back-Connect (PROJECT ZERO) motherboards, it allows you to hide all power and data cables on the rear of the motherboard tray, resulting in the cleanest build possible in 2026.



Key Features

  • Panoramic 270° Display: The unique wrap-around tempered glass design provides an unobstructed view of your system's interior. Without a thick front corner pillar, your high-end GPU and ARGB lighting become the center of attention from every angle.
  • Back-Connect Motherboard Support: Fully compatible with ATX and Micro-ATX back-connect motherboards. By routing connections to the rear, the MAG PANO 130R PZ eliminates the "cable spaghetti" usually visible in glass cases, ensuring a professional, clutter-free look.

    Elite Airflow & 10-Fan Capacity: Don't let the glass fool you; this case is built for performance. It supports up to 10 fans and dual 360mm radiators (top and side simultaneously). The lower chamber is surrounded by vents to ensure your PSU and GPU receive a constant supply of fresh air.

  • Reverse-Blade ARGB Fans Pre-installed: The side intake features three pre-installed 120mm reverse-blade fans. This clever design allows the "pretty" side of the ARGB fan to face the interior while still pulling air into the case, maintaining both beauty and functionality.

Performance / Versatility The MAG PANO 130R PZ is ready for the most powerful hardware on the market. It supports GPUs up to 400mm in length and features a Rotatable GPU Bracket. This innovative design allows you to switch between traditional horizontal mounting or a vertical orientation with a simple 90-degree rotation (riser cable sold separately). The top panel houses an ultra-fast 20Gbps USB Type-C port, providing enterprise-level data transfer speeds at your fingertips.

Maintenance & Protection Keeping your white build pristine is easy with a magnetic top dust filter and a removable bottom filter. These ensure that internal components remain free from dust buildup while maintaining optimal airflow. The high-quality steel construction and matte white finish provide a premium feel that resists fingerprints and reflects ARGB lighting beautifully.

Specification

MAG PANO 130R PZ / WHITE Specifications

Product NameMAG PANO 130R PZ / WHITE
Case Form FactorMid-Tower
Motherboard Form Factor SupportRegular: ATX / Micro-ATX / Mini-ITX
Back-connect: ATX / Micro-ATX
I/O Ports2 × USB 5Gbps (Type-A)
1 × USB 20Gbps (Type-C)
1 × Audio-Out / Mic-in
1 × Reset Button
1 × Power Button
Drive Mount SupportUp to 3 × 2.5” SSD
Up to 2 × 3.5” HDD
(Maximum of 3 drives at once, depending on configuration)
Expansion Slots7
Maximum GPU Length400 mm / 15.75 inches
Maximum CPU Cooler Height165 mm / 6.50 inches
Power Supply SupportATX
Maximum PSU Length180 mm / 7.09 inches
Fan Size SupportTop: 3 × 120 mm / 2 × 140 mm
Front: N/A
Rear: 1 × 120 mm
Side: 3 × 120 mm
Bottom: 3 × 120 mm (Above power shroud)
Pre-installed Fan TypeRear: 1 × 120 mm ARGB Fan
Side: 3 × 120 mm ARGB Fan (Reverse Blade)
Radiator Size SupportTop: 120 / 140 / 240 / 280 / 360 mm
Front: N/A
Rear: 120 mm
Side: 120 / 240 / 360 mm
Bottom: N/A
Dimensions (D × W × H)460 × 232 × 490 mm
(18.11 × 9.25 × 19.29 inches)
Net WeightBlack: 8.37 kg / 18.45 lbs
White: 8.37 kg / 18.45 lbs
Gross WeightBlack: 10 kg / 22.04 lbs
White: 10 kg / 22.04 lbs
