MSI PRO X870E-P WIFI Motherboard, AMD AM5, DDR5, PCIe 5.0, USB4, Wi-Fi 7, 5G LAN, ATX | 911-7E70-014
Model :
SKU : MB-MSI PRO X870E-P WIFI
About this item
About this item
Description
Designed for professionals and power users, the MSI PRO X870E-P WIFI leverages the full capabilities of the AMD Socket AM5 platform. It is optimized for Ryzen™ 9000 Series processors, ensuring that your system can handle the most demanding multitasking, 3D rendering, and AI-driven workloads. The board features an 8-layer server-grade PCB with thickened copper to maintain signal integrity and stability under heavy loads.
Next-Gen Connectivity: USB4 & Wi-Fi 7
The PRO X870E-P WIFI sets a new standard for I/O. It includes integrated USB4 technology, delivering blistering 40Gbps transfer speeds—perfect for massive file transfers and high-resolution external displays. Networking is equally advanced with Wi-Fi 7, offering a 320MHz channel width for speeds up to 5.8Gbps, and a 5G Super LAN port that provides a rock-solid, low-latency wired connection for professional environments.
Future-Proof PCIe 5.0 and Storage
Stay ahead of the curve with Lightning Gen 5 support. The primary x16 slot and the lead M.2 slot both utilize PCIe 5.0, doubling the bandwidth compared to Gen 4. This ensures total compatibility with the fastest NVMe SSDs and future-gen graphics cards. To keep your storage running at peak speeds without thermal throttling, MSI includes the EZ M.2 Shield Frozr II, a tool-less heatsink design that simplifies installation.
EZ DIY Features and Smart Cooling
MSI has prioritized the building experience with "EZ DIY" innovations. The EZ PCIe Clip II allows for effortless GPU removal, while the EZ Debug LEDs and EZ Memory Detection help you troubleshoot hardware issues in seconds. For cooling, Frozr AI Cooling automatically adjusts fan curves based on real-time CPU and GPU temperatures, ensuring your system stays quiet during light tasks and cool under pressure.
Why the MSI PRO X870E-P WIFI Stands Out
DDR5 Optimized: Supports extreme memory overclocking up to 8200+ MT/s (OC).
Robust Power Delivery: 14+2+1 Duet Rail Power System with 60A Smart Power Stages.
USB4 40Gbps: Native Type-C support for the fastest peripherals and 8K display output.
Wi-Fi 7 Ready: Future-proof wireless with Multi-Link Operation (MLO) support.
Specification
| Chipset | AMD X870E |
|---|---|
| CPU Support | AMD Socket AM5 Supports AMD Ryzen™ 9000 / 8000 / 7000 Series Desktop Processors |
| Memory | 4x DDR5 UDIMM, Max. 256GB Supports up to 8200+(OC) MT/s (Ryzen 9000) Supports AMD EXPO™, Dual-Channel, & CUDIMM (Bypass mode) |
| Graphics Out | 1x HDMI™ 2.1 (4K 60Hz) 1x USB4® Type-C (DP 1.4 over HBR3, 4K 60Hz) |
| Expansion Slots | 1x PCIe 5.0 x16 (From CPU)* *Bandwidth varies by CPU (Ryzen 8000 Series supports x8 or x4). |
| Storage | M.2 Slots: *NVMe RAID 0/1/5 (RAID 5 for Ryzen 9000 only); SATA RAID 0/1/10. |
| Networking | LAN: Realtek® 8126VB 5G LAN (5Gbps) Wi-Fi/BT: Wi-Fi 7 (Up to 5.8Gbps), Bluetooth® 5.4 |
| USB Ports | Rear USB: 1x USB4 40Gbps (Type-C), 1x 20Gbps (Type-C), 2x 10Gbps (Type-A), 4x 5Gbps (Type-A), 4x USB 2.0 Front Headers: 1x 10Gbps (Type-C), 4x 5Gbps (Type-A), 6x USB 2.0 |
| Audio | Realtek® ALC897, 7.1-Channel High Definition Audio |
| Internal I/O | 1x 24-pin Power, 2x 8-pin CPU Power, 1x 8-pin PCIe Power, 1x CPU Fan, 1x Pump/Sys Fan, 6x System Fans, 3x ARGB V2, 1x RGB, EZ Debug LEDs |
| Back Panel | Clear CMOS, Flash BIOS Button, HDMI, USB4 Type-C, Wi-Fi Antennas, 5G LAN, Audio Jacks |
| Form Factor | ATX (243.84mm x 304.8mm) |
