MSI X870E GAMING PLUS WIFI AM5 ATX Motherboard, 4x DDR5 UDIMM, Max Memory 256GB, 3x M.2 4x SATA 6G, Wi-Fi 7 5G LAN, BT 5.4, High-speed USB4, PCIe 5.0 | 911-7E70-001
Model :
SKU : MB-MSI X870E GAM PLUS WIF
About this item
0
Inclusive of VAT
Delivery to
FREE scheduled delivery as soon as Loading...
Sold and shipped by: Adarc computers
1
About this item
Description
Specification
AMD X870E Motherboard Specifications
| Chipset | AMD X870E |
| CPU | Supports AMD Ryzen™ 9000/ 8000/ 7000 Series Desktop Processors Socket AM5 |
| Memory | 4x DDR5 UDIMM, Maximum Memory Capacity 256GB Memory Support DDR5 8200 - 5600 (OC) MT/s / 5600 - 4800 (JEDEC) MT/s Ryzen™ 9000 Series Processors max. overclocking frequency: • 1DPC 1R Max speed up to 8200+ MT/s • 1DPC 2R Max speed up to 6400+ MT/s • 2DPC 1R Max speed up to 6400+ MT/s • 2DPC 2R Max speed up to 6000+ MT/s Supports AMD POR Speed and JEDEC Speed Supports Memory Overclocking and AMD EXPO™ Supports Dual-Channel mode Supports Non-ECC, Un-buffered memory Supports CUDIMM, Clock Driver bypass mode only* *CUDIMM support and POR boot frequency may vary by CPU series, with manual overclocking available after boot. Certain CPUs may fail to boot, but future BIOS updates will improve compatibility. |
| Onboard Graphics | 1x HDMI™ (HDMI 2.1, max 4K 60Hz*) 1x Type-C DisplayPort (USB4®, DP 1.4 with HBR3, max 4K 120Hz*) *Available only on processors featuring integrated graphics. |
| Expansion Slots | 3x PCI-E x16 1x PCI-E x1 PCI_E1 Gen PCIe 5.0 supports up to x16 (From CPU) PCI_E2 Gen PCIe 3.0 supports up to x1 (From Chipset) PCI_E3 Gen PCIe 4.0 supports up to x4 (From Chipset) PCI_E4 Gen PCIe 3.0 supports up to x1 (From Chipset) PCI_E1 Slot: • PCIe 5.0 x16 (Ryzen™ 9000/ 7000) • PCIe 4.0 x8 (Ryzen™ 8700/ 8600/ 8400) • PCIe 4.0 x4 (Ryzen™ 8500/ 8300) |
| Audio | Realtek® ALC897, 7.1-Channel High Definition Audio |
| Storage | 3x M.2 Slots: • M.2_1 (From CPU) PCIe 5.0 x4, 2280/2260 • M.2_2 (From Chipset) PCIe 4.0 x4, 2280/2260 • M.2_3 (From Chipset) PCIe 4.0 x4, 22110/2280 4x SATA 6G |
| RAID Support | SATA: RAID 0, RAID 1, RAID 10 M.2 NVMe: RAID 0, RAID 1, RAID 5* *RAID 5 only with Ryzen™ 9000 Series. |
| USB | Rear: 4x USB 2.0, 2x USB 5Gbps Type-A, 2x USB 10Gbps Type-A, 1x USB 20Gbps Type-C, 1x USB 40Gbps Type-C Front: 6x USB 2.0, 4x USB 5Gbps Type-A, 1x USB 10Gbps Type-C |
| LAN | Realtek® 8126VB 5G LAN |
| Internal I/O | 1x ATX_PWR, 2x CPU_PWR, 1x PCIE_PWR (8-pin) 1x CPU Fan, 1x Combo Fan (Pump/Sys Fan), 6x System Fan 1x EZ Conn-header (JAF_1), 2x Front Panel (JFP) 1x Chassis Intrusion (JCI), 1x Front Audio (JAUD) 1x Tuning Controller connector (JDASH) 3x Addressable V2 RGB LED (JARGB_V2), 1x RGB LED (JRGB) 1x TPM pin header (TPM 2.0) |
| Wireless LAN & Bluetooth | Wi-Fi 7, MU-MIMO, 2.4/5/6GHz (320MHz) up to 5.8Gbps Bluetooth® 5.4**, MLO, 4KQAM *6GHz support depends on region; **Bluetooth version may update. |
| LED Features | 4x EZ Debug LED, 1x EZ Memory Detection LED |
| Back Panel Ports | Clear CMOS Button USB 5Gbps Type-A USB 10Gbps Type-A USB 2.0 5G LAN Wi-Fi / Bluetooth Audio connectors Flash BIOS Button HDMI™ USB 40Gbps Type-C USB 20Gbps Type-C |
| Operating System | Windows® 11 64-bit |
