ASUS ROG CROSSHAIR X870E EXTREME AM5 E-ATX Gaming Motherboard, Gen 5, 20+2+2 Power Stages, DDR5, PCIe 5.0, 5x M.2, 5G & 10G LAN, Wi-Fi 7, USB4 Type-C, Full Color 5inch LCD Display, AI Overclocking & Networking | 90MB1LB0-M0EAY0

Model :

SKU : MB-ASUS CROSS X870E EXTRE

About this item

The ROG Crosshair X870E Extreme is the flagship AMD Ryzen™ 9000 series motherboard, designed for the most discerning users. It provides the ultimate foundation for AM5 CPUs, DDR5 memory, and PCIe® 5.0 components to ensure maximum performance and future-readiness. Its comprehensive connectivity includes USB4®, and the integrated 5-inch LCD offers a unique way to monitor system performance or add a touch of personalized style.

dirham-symbol0

Inclusive of VAT

Delivery to

FREE scheduled delivery as soon as Loading...

Sold and shipped by: Adarc computers

1

AED 0.00

stock : 1

About this item

Description

ASUS DriverHub streamlines the installation and management of ASUS drivers and utilities to keep your hardware up-to-date and performing optimally. This standalone application automatically detects current driver versions and presents available updates in a list view. By default, it supports ASUS motherboards, and users are invited to install ASUS DriverHub after OS installation. Additionally, ASUS DriverHub offers one-click installation and update checks, making it easier for users to keep their systems running smoothly and efficiently.



BUILD FOR THE MOST ADVANCED PC FOR GAMING AND CREATING
When only the fastest will do, ROG X870E/X870 motherboards deliver. With USB 4.0 onboard along with robust overclocking¹ capabilities, featuring faster dual-channel DDR5 memory support, AMD EXPO™ technology and PCIe® 5.0 support for both graphics and NVMe, you can play the most demanding games and deliver your biggest projects with the revolutionary performance of an ROG X870E/X870 motherboard and AMD Ryzen™ 9000, 8000, and 7000 Series processors.



1. Overclocking and/or undervolting AMD processors and memory, including without limitation, altering clock frequencies / multipliers or memory timing / voltage, to operate outside of AMD's published specifications will void any applicable AMD product warranty, even when enabled via AMD hardware and/or software. This may also void warranties offered by the system manufacturer or retailer. Users assume all risks and liabilities that may arise out of overclocking and/or undervolting AMD processors, including, without limitation, failure of or damage to hardware, reduced system performance and/or data loss, corruption or vulnerability. GD-106.

Specification

ModelROG CROSSHAIR X870E EXTREME
CPU SupportAMD Socket AM5 for AMD Ryzen™ 9000 / 8000 / 7000 Series Desktop Processors
ChipsetAMD X870E
Memory4 x DIMM slots, max. 256GB, DDR5
Supports up to 8200+ MT/s (OC) with Ryzen™ 9000 Series
Supports up to 9000+ MT/s (OC) with Ryzen™ 8000 Series
Supports up to 8000+ MT/s (OC) with Ryzen™ 7000 Series
ECC & Non-ECC, Un-buffered DIMM, Dual Channel
EXPO™ & ASUS Enhanced Memory Profile (AEMP) Support
NitroPath DRAM Technology
Graphics1 x HDMI™ 2.1 port (4K@60Hz)
2 x USB4® (40Gbps) Type-C display outputs (4K@60Hz, DP 1.4a)
Expansion Slots2 x PCIe 5.0 x16 with Q-Release Slim
Supports x16 or x8/x8 or x8/x4/x4 modes depending on CPU
(See ASUS support for bifurcation details)
StorageUp to 5 x M.2 slots + 1 x SlimSAS + 4 x SATA 6Gb/s
Supports PCIe 5.0 / 4.0 modes depending on CPU
DIMM.2 slots via ROG Q-DIMM.2
SlimSAS supports PCIe 4.0 x4 via SFF-8654 cable
RAID SupportAMD RAIDXpert2 Technology
Ryzen™ 9000: RAID 0/1/5/10
Ryzen™ 8000: RAID 0/1
Ryzen™ 7000: RAID 0/1/10
Ethernet1 x Realtek 5Gb Ethernet
1 x Marvell® AQtion 10Gb Ethernet
ASUS LANGuard
Wireless & BluetoothWi-Fi 7 (802.11be), 2x2, 2.4/5/6GHz
Up to 6.5Gbps, 320MHz bandwidth
Bluetooth® v5.4
USB PortsRear: 2 x USB4® (40Gbps) Type-C, 10 x USB 10Gbps (8 x Type-A + 2 x Type-C)
Front: 1 x USB 20Gbps Type-C (60W PD/QC4+), 1 x USB 10Gbps Type-C, 4 x USB 5Gbps, 4 x USB 2.0
AudioROG SupremeFX 7.1 ALC4082 Codec
ESS® ES9219 QUAD DAC
Supports 32-bit / 384 kHz playback (front)
SupremeFX Shielding, LED jacks, Optical S/PDIF
Back Panel I/O2 x USB4® (40Gbps) Type-C
10 x USB 10Gbps
1 x HDMI™
1 x Wi-Fi Module
1 x 5GbE + 1 x 10GbE LAN
2 x LED Audio Jacks + 1 x Optical S/PDIF
BIOS FlashBack™, Clear CMOS
Internal I/OMultiple 4-pin fan headers, 24-pin ATX, dual 8-pin CPU power, PCIe power
3 x M.2, 1 x DIMM.2 (2 M.2), 1 x SlimSAS, 4 x SATA 6Gb/s
Multiple USB 20Gbps, 10Gbps, 5Gbps, 2.0 headers
ARGB Gen 2 headers, LN2 mode, ProbeIt, ReTry, Safe Boot, Q-Design
Special FeaturesExtreme OC Kit (LN2, ProbeIt, Safe Boot, Start Button)
Extreme Engine Digi+, ASUS Q-Design, Aura Sync
Dual BIOS, Full Color 5" LCD Display
Front USB 20Gbps with Quick Charge 4+ (up to 60W)
ASUS Thermal Solution with VRM & M.2 heatsinks
SoftwareArmoury Crate, AIDA64 Extreme (1 year), Fan Xpert 4, Aura Sync, Dolby Atmos, ROG CPU-Z, LCD Display, Turbo Vcore, GameFirst, GlideX
BIOSDual 256Mb Flash ROM, UEFI AMI BIOS
AI Overclocking, EZ Flash 3, CrashFree BIOS 3, MyHotkey
AccessoriesARGB splitters, fan splitters, SATA cables, thermistor cables
ROG Q-DIMM.2 with heatsink, WiFi antenna, stickers, screwdriver, USB drivers
Operating SystemWindows® 11
Form FactorE-ATX, 12" x 10.9" (30.5 cm x 27.7 cm)
