ASUS ROG Maximus Z890 Extreme LGA 1851 ATX Motherboard, Intel Z890 Chipset, 4x DDR5 DIMM, Up to 192GB Max Memory, Wi-Fi 7 & BT 5.4, 2x PCIe 5.0 x16 Slots, 6x M.2, 5 inch LCD Display | 90MB1IA0-M0EAY0
Model :
SKU : MB-ASUS RO MAXIM Z890 EXT
About this item
About this item
Description
The ROG Maximus Z890 Extreme is more than a motherboard; it is a declaration of performance. Designed specifically for the Intel LGA 1851 socket, it serves as the premier foundation for the Intel Core Ultra series. Every square inch of the board is optimized for thermal efficiency and data throughput, ensuring that your high-end workstation or gaming rig operates at the bleeding edge of modern technology.
Innovative Monitoring: 5-Inch Color LCD Display
Setting a new standard for system aesthetics, the Z890 Extreme features a massive 5-inch full-color LCD display integrated into the I/O cover. This isn't just for show—it provides real-time monitoring of CPU temperatures, voltages, and fan speeds. It can also be customized via Armoury Crate to display personalized animations, logos, or hardware statistics, making it the most interactive motherboard interface ever created.
Power for the Elite: 24+1+2+2 Architecture
To drive the most powerful processors in the world, the Z890 Extreme utilizes an unmatched 24+1+2+2 power stage design. Rated for massive current handling, this teamed power architecture provides the stability and overhead required for extreme liquid nitrogen (LN2) overclocking or sustained heavy-duty rendering. The VRMs are encased in high-performance heatsinks connected by a massive heatpipe to ensure rapid thermal dissipation.
Storage and Networking: Total Connectivity
Storage enthusiasts will find a home here with six M.2 slots, three of which support the incredible speeds of PCIe 5.0. Connectivity is equally groundbreaking, featuring onboard WiFi 7 for multi-gigabit wireless speeds and a combination of 10Gb and 2.5Gb Ethernet ports. For external peripherals, Dual Thunderbolt™ 4 ports provide 40Gbps of bandwidth and support for multiple 4K displays or high-speed RAID arrays.
Why the ROG Maximus Z890 Extreme Stands Out
5-Inch LCD Dashboard: Real-time hardware monitoring and deep personalization.
Massive Power Delivery: 24+1+2+2 stages built for the highest performance tier.
Six M.2 Slots: Unmatched NVMe expandability with PCIe 5.0 support.
Next-Gen WiFi 7: Revolutionary wireless technology with ultra-low latency.
Specification
| CPU Support | Intel® Core™ Ultra Processors (Series 2), LGA1851 |
| Chipset | Intel® Z890 Chipset |
| Memory | 4 x DIMM slots, max. 256GB, DDR5, up to 9200+ MT/s (OC), Non-ECC, Un-buffered, Dual Channel, XMP & AEMP III, DIMM Flex, DIMM Fit, NitroPath DRAM Technology |
| Graphics | 1 x HDMI port, 2 x Intel® Thunderbolt™ 5 (USB Type-C®) ports |
| Expansion Slots | 2 x PCIe 5.0 x16 slots, 1 x PCIe 4.0 x4 slot |
| Storage | 6 x M.2 slots, 4 x SATA 6Gb/s ports, RAID support via Intel® RST |
| Ethernet | 1 x Intel® 2.5Gb, 1 x Marvell® AQtion 10Gb, ASUS LANGuard |
| Wireless & Bluetooth | Intel® Wi-Fi 7, 2x2 Wi-Fi 7 (802.11be), Bluetooth® v5.4 |
| Rear USB Ports | 2 x Thunderbolt™ 5 Type-C, 1 x USB 20Gbps Type-C, 7 x USB 10Gbps (5 x Type-A + 2 x Type-C) |
| Front USB Ports | 1 x USB 20Gbps Type-C, 1 x USB 10Gbps Type-C, 2 x USB 5Gbps headers (support 4 ports), 2 x USB 2.0 headers (support 4 ports) |
| Audio | ROG SupremeFX 7.1 Surround, ALC4082, 120 dB SNR stereo output, 110 dB SNR recording input, ESS® ES9219 QUAD DAC |
| Internal I/O Connectors | CPU Fan headers, Chassis Fan headers, Radiator Fan headers, W_PUMP+ headers, WB_SENSOR header, Main Power connector, CPU Power connectors, PCIe Power connector, M.2 slots, DIMM.2 slots, SATA ports, USB connectors |
| Special Features | Extreme OC Kit, Extreme Engine Digi+, ASUS Q-Design, ASUS Thermal Solution, ASUS EZ DIY, Aura Sync, Dual BIOS, Full Color 5" LCD, ROG M.2 PowerBoost, Front Panel USB 20Gbps with Quick Charge |
| Software Features | ROG Exclusive Software, ASUS Exclusive Software (Armoury Crate, Aura Creator, Fan Xpert 4, GameFirst, HWiNFO, Power Saving, LCD Display), ASUS AI Advisor, ASUS Driver Hub, Turbo Vcore, GlideX, Thunderbolt™ Share, WinRAR (trial), Adobe CC (trial) |
| BIOS | 2 x 256 Mb Flash ROM, UEFI AMI BIOS, AI Overclocking Guide, EZ Flash, CrashFree BIOS 3 |
| Manageability | WOL by PME |
| Accessories | ARGB splitter cables, fan splitters, ROG Q-DIMM.2 with heatsink, thermal pads, M.2 backplates, WiFi antenna, Q-connector, stickers, screwdriver, VIP card, installation USB, documentation |
| Operating System | Windows 11 (22H2 & later) |
| Form Factor | E-ATX, 12 inch x 10.9 inch (30.5 cm x 27.7 cm) |
