ASUS ROG STRIX X870-F GAMING WIFI AM5 DDR5 ATX Motherboard, 4x DIMM slots, max. 192GB, 4x M.2 slots 2x SATA, PCIe 5.0, 2.5Gb Ethernet, WiFi 7, 2.5Gb Ethernet, AI Solution | 90MB1IV0-M0EAY0
Model :
SKU : MB-ASUS ROG X870-F GAM WI
About this item
About this item
Description
Supercharge your large language model (LLM) workflows with AI Cache Boost. Exclusive to ASUS AMD 800 and 600 series motherboards that use Ryzen™ 9000 Series CPUs, this BIOS setting optimizes CPU cache and memory pathways to deliver up to 29% faster local LLM performance with high-speed memory tuning.
Specification
| Model | ROG STRIX X870-F GAMING WIFI |
| CPU Socket | AMD Socket AM5 for Ryzen™ 9000, 8000 & 7000 Series Desktop Processors |
| Chipset | AMD X870 |
| Memory Slots | 4 x DIMM, Max 256GB DDR5, Dual Channel, ECC & Non-ECC, Unbuffered |
| Memory Features | AMD EXPO™, ASUS Enhanced Memory Profile (AEMP), Supports up to 8000+ MT/s (OC) |
| Graphics Output | 1 x DisplayPort, 1 x HDMI™, 2 x USB4® Type-C (40Gbps, DisplayPort Alt Mode) |
| Expansion Slots | 1 x PCIe 5.0 x16 (Ryzen 9000/7000, x16 mode), 1 x PCIe 4.0 x16 (Ryzen 8000, x8/x4 mode), 1 x PCIe 4.0 x16 (X870, x4 mode) |
| Storage | 4 x M.2 slots (PCIe 5.0/4.0), 2 x SATA 6Gb/s ports, Supports RAID 0/1/5/10 (RAID 5 only Ryzen 9000) |
| Ethernet | Intel® 2.5Gb Ethernet, ASUS LANGuard |
| Wireless & Bluetooth | Wi-Fi 7 2x2 (802.11be, 320MHz), Bluetooth® v5.4 |
| Rear USB Ports | 2 x USB4® Type-C (DP Alt Mode), 6 x USB 10Gbps (5 Type-A + 1 Type-C PD), 4 x USB 5Gbps Type-A |
| Front USB Ports | 1 x USB 20Gbps Type-C, 2 x USB 5Gbps headers (4 ports), 2 x USB 2.0 headers (4 ports) |
| Audio | ROG SupremeFX ALC4080 7.1 HD Audio, Impedance sense, Jack-detection, Multi-streaming, Front Panel MIC retasking, 120 dB SNR playback, 110 dB SNR recording, Up to 32-Bit/384 kHz front panel playback |
| Audio Features | SupremeFX Shielding, Savitech SV3H712 AMP, Rear optical S/PDIF out, Premium audio capacitors, Audio cover |
| Internal I/O Connectors | 1 x 24-pin Main Power, 2 x 8-pin CPU Power, 4 x M.2 slots, 2 x SATA 6Gb/s 1 x USB 20Gbps Type-C, 2 x USB 5Gbps headers, 2 x USB 2.0 headers 1 x CPU Fan, 1 x CPU OPT Fan, 1 x AIO Pump, 5 x Chassis Fan, 3 x Addressable Gen 2 headers Alteration PCIe mode switch, Chassis Intrusion, CPU Overvoltage jumper, Front Panel Audio, Start button, System Panel header, Thermal Sensor |
| Special Features | Extreme Engine Digi+, 5K Black metallic capacitors ASUS Q-Design (M.2 Q-Latch, Q-Release, Q-Slide, PCIe Slot Q-Release Slim, Q-Antenna, Q-Dashboard, Q-DIMM, Q-LED, Q-Slot) Thermal Solution (M.2 heatsink & backplate), ASUS EZ DIY (BIOS FlashBack™, LED, Clear CMOS, ProCool II, Pre-mounted I/O shield, SafeSlot, SafeDIMM), Aura Sync |
| Software Features | ROG CPU-Z, Dolby Atmos, Armoury Crate (Aura Creator, Aura Sync, Fan Xpert 4, GameFirst, HWiNFO, Power Saving), ASUS Driver Hub, ASUS GlideX, USB Wattage Watcher, TurboV Core, Adobe Creative Cloud trial, Norton 360 trial, WinRAR trial, AI Overclocking Guide, Dynamic OC Switcher, FlexKey |
| BIOS | 256 Mb Flash ROM, UEFI AMI BIOS |
| Accessories | 2 x SATA 6Gb/s cables, Thermal pad for M.2 22110, Wi-Fi Q-Antenna, Cable ties, M.2 Q-Latch package, M.2 Q-Slide package, ROG key chain, ROG Strix stickers, 4 x M.2 rubber packages, Quick start guide |
| Operating System | Windows 11 |
| Form Factor | ATX, 12 in x 9.6 in (30.5 cm x 24.4 cm) |
