Synology 4bay NAS RackStation (Diskless), 2 GB DDR4 non-ECC, Intel Atom C3538 CPU, RJ-45 Lan Port x4, USB 3.0 x2, eSATA Port, Black/Gray | RS820+
Model :
SKU : SYNOLOGY RS820 PLUS
Description
Power Up Your Rack: Synology RS820+ 4-Bay NAS Server Delivers Speed and Versatility
| CPU | |
| CPU Model | Intel Atom C3538 |
| CPU Quantity | 1 |
| CPU Architecture | 64-bit |
| CPU Frequency | 4-core 2.1 GHz |
| Hardware Encryption Engine (AES-NI) | Yes |
| Memory | |
| System Memory | 2 GB DDR4 non-ECC |
| Total Memory Slots | 1 |
| Maximum Memory Capacity | 18 GB (2GB + 16 GB) |
| Notes | Please select Synology memory modules for optimum compatibility and reliability Synology will not provide complete product warranty or technical support if non-Synology memory modules are used for memory expansion. Synology reserves the right to replace memory modules with the same or higher frequency based on the supplier's product life cycle status. Rest assured that compatibility and stability have been strictly verified with the same benchmark to ensure identical performance. |
| Storage | |
| Drive Bays | 4 |
| Maximum Drive Bays with Expansion Unit | 8 (RX418 x 1) |
| Compatible Drive Type* | 3.5" SATA HDD 2.5" SATA HDD 2.5" SATA SSD |
| Maximum Internal Raw Capacity | 64 TB (16 TB drive x 4) (Capacity may vary by RAID types) |
| Maximum Raw Capacity with Expansion Units | 128 TB (64 TB + 16 TB drive x 4) (Capacity may vary by RAID types) |
| Maximum Single Volume Size* | 108 TB |
| Hot Swappable Drive | Yes |
| Notes | "Compatible drive type" indicates drives that have been tested to be compatible with Synology products. This term does not indicate the maximum connection speed of each drive bay. |
| The maximum raw capacity is not limited by the maximum single volume size. Synology NAS models may utilize capacities over the maximum single volume size as long as each volume created is below the limit. (Learn more) | |
| Each internal volume (may consist of multiple drives) is expandable up to 108TB. | |
| External Ports | |
| RJ-45 1GbE LAN Port | 4 (with Link Aggregation / Failover support) |
| USB 3.0 Port | 2 |
| eSATA Port | 1 |
| PCIe | |
| PCIe Expansion | 1 x Gen3 x8 slot (black, x4 link) |
| File System | |
| Internal Drives | Btrfs, EXT4 |
| External Drives | Btrfs, EXT4, EXT3, FAT, NTFS, HFS+, exFAT* |
| Notes | exFAT Access is purchased separately in Package Center. |
| Appearance | |
| Form Factor (RU) | 1U |
| Size (Height x Width x Depth) | 44 mm x 480 mm x 492.6 mm 44 mm x 480 mm x 518.6 mm (for RP model) |
| Weight | 6.4 kg 7.96 kg (for RP model) |
| Rack Installation Support* | 4-post 19" rack (Synology Rail Kit - RKM114/RKS1317) |
| Notes | The rail kit is sold separately |
| Others | |
| System Fan | 40 mm x 40 mm x 3 pcs 40 mm x 40 mm x 2 pcs (for RP model) |
| Fan Speed Mode | Full-Speed Mode Cool Mode Quiet Mode |
| Power Recovery | Yes |
| Noise Level* | 27 dB(A) 39.9 dB(A) (for RP model) |
| Scheduled Power On / Off | Yes |
| Wake on LAN / WAN | Yes |
| Power Supply Unit / Adapter | 150 W |
| Redundant Power Supply | yes (for RP model) |
| AC Input Power Voltage | 100 V to 240 V AC |
| Power Frequency | 50/60 Hz, Single Phase |
| Power Consumption | |
| 37.94 W (Access) | 20.96 W (HDD Hibernation) |
| 38.88 W (Access) (for RP model) | 22.17 W (HDD Hibernation) (for RP model) |
| British Thermal Unit (BTU/hr) | |
| 129.54 (Access) | 71.57 (HDD Hibernation) |
| 132.75 (Access) (for RP model) | 75.70 (HDD Hibernation) (for RP model) |
