Synology NAS Specifications

Processor

Processor model: Intel Celeron J4025
Processor architecture: 64-bit
Processor clock: 2-core 2.0 GHz (base frequency) / 2.9 GHz (burst frequency)
Hardware encryption engine (AES-NI): Not specified

Memory

System memory: 2 GB DDR4 non-ECC
Total number of memory slots: 1
Memory can be expanded to: 6 GB (2 GB + 4 GB)
Remarks:
- Please purchase original Synology memory modules for best compatibility and reliability.
- Synology reserves the right to replace memory components with the same or higher frequency based on availability.

Storage Device

Number of disk slots: 4
M.2 drive bay: 2 (NVMe)
Compatible disk types:
- 3.5" SATA HDD
- 2.5" SATA HDD
- 2.5" SATA SSD
- M.2 2280 NVMe SSD
Maximum internal net total storage capacity: 64 TB (16 TB drive x 4) (Capacity may vary by RAID types)
Maximum single storage space capacity: 108 TB
Remarks:
- Compatible disk type refers to the type of hard drive that is confirmed to be compatible with the product.
- The maximum single storage space does not directly equal the maximum net total storage capacity.
- The internal storage space can be expanded, but the expanded single storage space cannot exceed 108 TB.

External Ports

RJ-45 1GbE network port: 2 (Support Link Aggregation / Failover)
USB 3.0 port: 2

File System

Internal disk: Btrfs, EXT4
External disk: Btrfs, EXT4, EXT3, FAT, NTFS, HFS+, exFAT*
Remarks: exFAT Access must be purchased separately from the package center.

Exterior

Size (Height X Width X Depth): 166 mm x 199 mm x 223 mm
Weight: 2.18 kg

Other Projects

System fan: 92 mm x 92 mm x 2 pcs
Fan mode: Full speed mode, Low temperature mode, Silent mode
Front panel LED indicator can adjust brightness
Automatic power supply recovery
Noise value: 19.8 dB (A)
Timer switch
Wake on LAN

Power

Power supply / transformer: 90 W
AC input voltage: 100 V to 240 V AC
Current frequency: 50/60 Hz, single frequency
Power consumption:
- 28.30 W (Access)
- 8.45 W (HDD Hibernation)
British Thermal Unit:
- 96.63 BTU / hr (Access)
- 72.11 BTU / hr (HDD Hibernation)
Remarks:
- The power consumption test data is obtained by testing the Western Digital 1TB WD10EFRX hard drive.
- Noise test environment: Seagate 2TB ST2000VN000 hard drive is in standby mode, with two GRAS Type 40AE microphones installed at a distance of 1 meter in front and back of the Synology NAS; background noise value: 16.49-17.51 dB (A); temperature: Celsius 24.25-25.75 degrees; humidity: 58.2-61.8%.

Temperature

Operating temperature: 0 ?? C to 40 ?? C (32 ?? F to 104 ?? F)
Storage temperature: -20 ?? C to 60 ?? C (-5 ?? F to 140 ?? F)
Relative humidity: 5% to 95% RH

Certification Body

EAC
VCCI
CCC
RCM
KC
FCC
CE
BSMI

Surroundings

RoHS Compliant

Synology NAS Specifications

Processor

Processor model: Intel Celeron J4025
Processor architecture: 64-bit
Processor clock: 2-core 2.0 GHz (base frequency) / 2.9 GHz (burst frequency)
Hardware encryption engine (AES-NI): Not specified

Memory

System memory: 2 GB DDR4 non-ECC
Total number of memory slots: 1
Memory can be expanded to: 6 GB (2 GB + 4 GB)
Remarks:
- Please purchase original Synology memory modules for best compatibility and reliability.
- Synology reserves the right to replace memory components with the same or higher frequency based on availability.

Storage Device

Number of disk slots: 4
M.2 drive bay: 2 (NVMe)
Compatible disk types:
- 3.5" SATA HDD
- 2.5" SATA HDD
- 2.5" SATA SSD
- M.2 2280 NVMe SSD
Maximum internal net total storage capacity: 64 TB (16 TB drive x 4) (Capacity may vary by RAID types)
Maximum single storage space capacity: 108 TB
Remarks:
- Compatible disk type refers to the type of hard drive that is confirmed to be compatible with the product.
- The maximum single storage space does not directly equal the maximum net total storage capacity.
- The internal storage space can be expanded, but the expanded single storage space cannot exceed 108 TB.

External Ports

RJ-45 1GbE network port: 2 (Support Link Aggregation / Failover)
USB 3.0 port: 2

File System

Internal disk: Btrfs, EXT4
External disk: Btrfs, EXT4, EXT3, FAT, NTFS, HFS+, exFAT*
Remarks: exFAT Access must be purchased separately from the package center.

Exterior

Size (Height X Width X Depth): 166 mm x 199 mm x 223 mm
Weight: 2.18 kg

Other Projects

System fan: 92 mm x 92 mm x 2 pcs
Fan mode: Full speed mode, Low temperature mode, Silent mode
Front panel LED indicator can adjust brightness
Automatic power supply recovery
Noise value: 19.8 dB (A)
Timer switch
Wake on LAN

Power

Power supply / transformer: 90 W
AC input voltage: 100 V to 240 V AC
Current frequency: 50/60 Hz, single frequency
Power consumption:
- 28.30 W (Access)
- 8.45 W (HDD Hibernation)
British Thermal Unit:
- 96.63 BTU / hr (Access)
- 72.11 BTU / hr (HDD Hibernation)
Remarks:
- The power consumption test data is obtained by testing the Western Digital 1TB WD10EFRX hard drive.
- Noise test environment: Seagate 2TB ST2000VN000 hard drive is in standby mode, with two GRAS Type 40AE microphones installed at a distance of 1 meter in front and back of the Synology NAS; background noise value: 16.49-17.51 dB (A); temperature: Celsius 24.25-25.75 degrees; humidity: 58.2-61.8%.

Temperature

Operating temperature: 0 ?? C to 40 ?? C (32 ?? F to 104 ?? F)
Storage temperature: -20 ?? C to 60 ?? C (-5 ?? F to 140 ?? F)
Relative humidity: 5% to 95% RH

Certification Body

EAC
VCCI
CCC
RCM
KC
FCC
CE
BSMI

Surroundings

RoHS Compliant

Description

Synology NAS Specifications

Processor	Processor model: Intel Celeron J4025 Processor architecture: 64-bit Processor clock: 2-core 2.0 GHz (base frequency) / 2.9 GHz (burst frequency) Hardware encryption engine (AES-NI): Not specified
Memory	System memory: 2 GB DDR4 non-ECC Total number of memory slots: 1 Memory can be expanded to: 6 GB (2 GB + 4 GB) Remarks: Please purchase original Synology memory modules for best compatibility and reliability. Synology reserves the right to replace memory components with the same or higher frequency based on availability.
Storage Device	Number of disk slots: 4 M.2 drive bay: 2 (NVMe) Compatible disk types: 3.5" SATA HDD 2.5" SATA HDD 2.5" SATA SSD M.2 2280 NVMe SSD Maximum internal net total storage capacity: 64 TB (16 TB drive x 4) (Capacity may vary by RAID types) Maximum single storage space capacity: 108 TB Remarks: Compatible disk type refers to the type of hard drive that is confirmed to be compatible with the product. The maximum single storage space does not directly equal the maximum net total storage capacity. The internal storage space can be expanded, but the expanded single storage space cannot exceed 108 TB.
External Ports	RJ-45 1GbE network port: 2 (Support Link Aggregation / Failover) USB 3.0 port: 2
File System	Internal disk: Btrfs, EXT4 External disk: Btrfs, EXT4, EXT3, FAT, NTFS, HFS+, exFAT* Remarks: exFAT Access must be purchased separately from the package center.
Exterior	Size (Height X Width X Depth): 166 mm x 199 mm x 223 mm Weight: 2.18 kg
Other Projects	System fan: 92 mm x 92 mm x 2 pcs Fan mode: Full speed mode, Low temperature mode, Silent mode Front panel LED indicator can adjust brightness Automatic power supply recovery Noise value: 19.8 dB (A) Timer switch Wake on LAN
Power	Power supply / transformer: 90 W AC input voltage: 100 V to 240 V AC Current frequency: 50/60 Hz, single frequency Power consumption: 28.30 W (Access) 8.45 W (HDD Hibernation) British Thermal Unit: 96.63 BTU / hr (Access) 72.11 BTU / hr (HDD Hibernation) Remarks: The power consumption test data is obtained by testing the Western Digital 1TB WD10EFRX hard drive. Noise test environment: Seagate 2TB ST2000VN000 hard drive is in standby mode, with two GRAS Type 40AE microphones installed at a distance of 1 meter in front and back of the Synology NAS; background noise value: 16.49-17.51 dB (A); temperature: Celsius 24.25-25.75 degrees; humidity: 58.2-61.8%.
Temperature	Operating temperature: 0 ?? C to 40 ?? C (32 ?? F to 104 ?? F) Storage temperature: -20 ?? C to 60 ?? C (-5 ?? F to 140 ?? F) Relative humidity: 5% to 95% RH
Certification Body	EAC VCCI CCC RCM KC FCC CE BSMI
Surroundings	RoHS Compliant

Specification

Synology NAS Specifications

Processor	Processor model: Intel Celeron J4025 Processor architecture: 64-bit Processor clock: 2-core 2.0 GHz (base frequency) / 2.9 GHz (burst frequency) Hardware encryption engine (AES-NI): Not specified
Memory	System memory: 2 GB DDR4 non-ECC Total number of memory slots: 1 Memory can be expanded to: 6 GB (2 GB + 4 GB) Remarks: Please purchase original Synology memory modules for best compatibility and reliability. Synology reserves the right to replace memory components with the same or higher frequency based on availability.
Storage Device	Number of disk slots: 4 M.2 drive bay: 2 (NVMe) Compatible disk types: 3.5" SATA HDD 2.5" SATA HDD 2.5" SATA SSD M.2 2280 NVMe SSD Maximum internal net total storage capacity: 64 TB (16 TB drive x 4) (Capacity may vary by RAID types) Maximum single storage space capacity: 108 TB Remarks: Compatible disk type refers to the type of hard drive that is confirmed to be compatible with the product. The maximum single storage space does not directly equal the maximum net total storage capacity. The internal storage space can be expanded, but the expanded single storage space cannot exceed 108 TB.
External Ports	RJ-45 1GbE network port: 2 (Support Link Aggregation / Failover) USB 3.0 port: 2
File System	Internal disk: Btrfs, EXT4 External disk: Btrfs, EXT4, EXT3, FAT, NTFS, HFS+, exFAT* Remarks: exFAT Access must be purchased separately from the package center.
Exterior	Size (Height X Width X Depth): 166 mm x 199 mm x 223 mm Weight: 2.18 kg
Other Projects	System fan: 92 mm x 92 mm x 2 pcs Fan mode: Full speed mode, Low temperature mode, Silent mode Front panel LED indicator can adjust brightness Automatic power supply recovery Noise value: 19.8 dB (A) Timer switch Wake on LAN
Power	Power supply / transformer: 90 W AC input voltage: 100 V to 240 V AC Current frequency: 50/60 Hz, single frequency Power consumption: 28.30 W (Access) 8.45 W (HDD Hibernation) British Thermal Unit: 96.63 BTU / hr (Access) 72.11 BTU / hr (HDD Hibernation) Remarks: The power consumption test data is obtained by testing the Western Digital 1TB WD10EFRX hard drive. Noise test environment: Seagate 2TB ST2000VN000 hard drive is in standby mode, with two GRAS Type 40AE microphones installed at a distance of 1 meter in front and back of the Synology NAS; background noise value: 16.49-17.51 dB (A); temperature: Celsius 24.25-25.75 degrees; humidity: 58.2-61.8%.
Temperature	Operating temperature: 0 ?? C to 40 ?? C (32 ?? F to 104 ?? F) Storage temperature: -20 ?? C to 60 ?? C (-5 ?? F to 140 ?? F) Relative humidity: 5% to 95% RH
Certification Body	EAC VCCI CCC RCM KC FCC CE BSMI
Surroundings	RoHS Compliant
