| CPU |
- CPU Model: Intel Celeron J4125
- CPU Quantity: 1
- CPU Architecture: 64-bit
- CPU Frequency: 4-core 2.0 (base) / 2.7 (burst) GHz
- Hardware Encryption Engine (AES-NI)
|
| Memory |
- System Memory: 2 GB DDR4 non-ECC
- Total Memory Slots: 1
- Maximum Memory Capacity: 6 GB (2 GB + 4 GB)
- Notes:
- Synology reserves the right to replace memory modules with the same or higher frequency based
on supplier's product life cycle status.
- Compatibility and stability have been strictly verified with the same benchmark to ensure
identical performance.
- Select Synology memory modules for optimum compatibility and reliability.
- Synology will not provide complete product warranty or technical support if non-Synology memory
modules are used for memory expansion.
- For more information about the recommended memory configurations, check the Hardware Installation
Guide of your Synology product.
|
| Storage |
- Drive Bays: 4
- M.2 Drive Slots: 2 (NVMe)
- Compatible Drive Type:
- 3.5" SATA HDD
- 2.5" SATA SSD
- M.2 2280 NVMe SSD
- Hot Swappable Drive
- Notes:
- The hot swappable drive feature is not supported by M.2 SSD slots.
- "Compatible drive type" indicates drives that have been tested to be compatible with Synology
products. This term does not indicate the maximum connection speed of each drive bay.
|
| External Ports |
- RJ-45 1GbE LAN Port: 2 (with Link Aggregation / Failover support)
- USB 3.2 Gen 1 Port: 2
- Notes:
- This device's 1GbE LAN ports have a maximum transmission unit (MTU) size of 1,500 bytes.
- The USB 3.0 standard was renamed to USB 3.2 Gen 1 by the USB Implementers Forum (USB-IF) in 2019.
|
| File System |
- Internal Drives: Btrfs, ext4
- External Drives: Btrfs, ext4, ext3, FAT, NTFS, HFS+, exFAT
- Notes: exFAT Access can be installed for free from Package Center in DSM 7.0. In DSM 6.2 or earlier versions,
exFAT Access needs to be purchased in Package Center.
|
| Appearance |
- Size (Height x Width x Depth): 166 mm x 199 mm x 223 mm
- Weight: 2.18 kg
|
| Others |
- System Fan: 92 mm x 92 mm x 2 pcs
- Fan Speed Mode: Full-Speed Mode, Cool Mode, Quiet Mode
- Brightness Adjustable Front LED Indicators
- Power Recovery
- Noise Level: 19.8 dB(A)
- Scheduled Power On / Off
- Wake on LAN / WAN
|
| Power |
- Power Supply Unit / Adapter: 90 W
- AC Input Power Voltage: 100V to 240V AC
- Power Frequency: 50/60 Hz, Single Phase
- Power Consumption:
- 28.3 W (Access)
- 8.45 W (HDD Hibernation)
- British Thermal Unit:
- 96.5 BTU/hr (Access)
- 28.81 BTU/hr (HDD Hibernation)
- Notes:
- Power consumption is measured when it is fully loaded with Western Digital 1TB WD10JFCX hard
drive(s).
- Noise Level Testing Environment: Fully loaded with Synology SATA HDDs and in an idle state. Two G.R.A.S.
Type 40AE microphones are placed at a 1 m distance from the front and rear of the device. Background
noise: 16.49-17.51 dB(A); Temperature: 24.25-25.75??C; Humidity: 58.2-61.8%.
|
| Temperature |
- Operating Temperature: 0??C to 40??C (32??F to 104??F)
- Storage Temperature: -20??C to 60??C (-5??F to 140??F)
- Relative Humidity: 5% to 95% RH
|
| Certification |
- FCC
- CE
- BSMI
- VCCI
- RCM
- UKCA
- EAC
- CCC
- KC
|
| Warranty |
- 3-year hardware warranty, extendable to 5 years with EW201 or Extended Warranty Plus
- Notes: The warranty period starts from the purchase date as stated on your purchase receipt. (Learn
more)
|
| Environment |
|
| Packaging Content |
- Main Unit X 1
- Accessory Pack X 1
- AC Power Adapter X 1
- AC Power Cord X 1
- RJ-45 LAN Cable X 2
- Quick Installation Guide X 1
|
| Optional Accessories |
- DDR4 non-ECC SODIMM: D4NESO-2666-4G
- 3.5" SATA HDD: HAT5300/HAT3300
- 2.5" SATA SSD: SAT5210
- M.2 2280 NVMe SSD: SNV3410
- Surveillance Device License Pack
|
