Synology RackStation 4-Bay NAS Enclosure, 8GB of DDR4 ECC RAM, 1U Form Factor, 4 x Gigabit Ethernet Ports, 3.5"/2.5" SATA Drive, Expansion Port, USB 3.0 Type-A | RS1619XSPLUS SYNOLOGY Rs1619xs+
Model :
SKU : SYNOLOGY Rs1619xs+
About this item
0
Inclusive of VAT
Delivery to
FREE scheduled delivery as soon as Loading...
Sold and shipped by: Adarc computers
1
About this item
Description
Rack-Mount Powerhouse: RS1619xs+ NAS Delivers Speed, Security, and Scalability
table { border-collapse: collapse; width: 100%; } tr { border-bottom: 1px solid rgb(222, 226, 230); } td { padding: 8px; margin: 0; }
| Synology NAS Specifications | |
| CPU Model | Intel Xeon D-1527 |
| CPU Quantity | 1 |
| CPU Architecture | 64-bit |
| CPU Frequency | 4-core 2.2 (base) / 2.7 (turbo) GHz |
| Hardware Encryption Engine (AES-NI) | Yes |
| System Memory | 8 GB DDR4 ECC UDIMM |
| Memory Module Pre-installed | 8 GB (8 GB x 1) |
| Total Memory Slots | 4 |
| Maximum Memory Capacity | 64 GB (16 GB x 4) |
| Notes | Synology reserves the right to replace memory modules with the same or higher frequency based on supplier's product life cycle status. Rest assured that the compatibility and stability have been strictly verified with the same benchmark to ensure identical performance. Please select Synology memory modules for optimum compatibility and reliability. Synology will not provide complete product warranty or technical support if non-Synology memory modules are used for memory expansion. For more information on the recommended memory configurations, visit here. |
| Drive Bays | 4 |
| Maximum Drive Bays with Expansion Unit | 16 (RX1217/RX1217RP x 1) |
| M.2 Drive Slots | 2 (NVMe & SATA) |
| Compatible Drive Type* | 3.5" SATA HDD 2.5" SATA HDD 2.5" SATA SSD M.2 2280 NVMe & SATA SSD |
| Hot Swappable Drive* | Yes |
| Notes | The hot swappable drive feature is not supported by M.2 SSD slots. "Compatible drive type" indicates drives that have been tested to be compatible with Synology products. This term does not indicate the maximum connection speed of each drive bay. |
| RJ-45 1GbE LAN Port | 4 (with Link Aggregation / Failover support) |
| USB 3.2 Gen 1 Port* | 2 |
| Expansion Port | 1 |
| Notes | The USB 3.0 standard was renamed to USB 3.2 Gen 1 by the USB Implementers Forum (USB-IF) in 2019. |
| PCIe Expansion | 1 x Gen3 x8 slot (x8 link) |
| Internal Drives | Btrfs ext4 |
| External Drives | Btrfs ext4 ext3 FAT NTFS HFS+ exFAT |
| Notes | exFAT Access can be installed for free from Package Center in DSM 7.0. In DSM 6.2 or earlier versions, exFAT Access needs to be purchased in Package Center. |
| Form Factor (RU) | 1U |
| Size (Height x Width x Depth) | 44 mm x 480 mm x 518.6 mm |
| Weight | 8.16 kg |
| Rack Installation Support* | 4-post 19" rack (Synology Rail Kit - RKM114/RKS-02) |
| Notes | The rail kit is sold separately |
| System Fan | 40 mm x 40 mm x 2 pcs |
| Fan Speed Mode | Full-Speed Mode Cool Mode Quiet Mode |
| Power Recovery | Yes |
| Noise Level* | 39.3 dB(A) |
| Scheduled Power On / Off | Yes |
| Wake on LAN / WAN | Yes |
| Power Supply Unit / Adapter | 150 W |
| Redundant Power Supply | Yes |
| AC Input Power Voltage | 100V to 240V AC |
| Power Frequency | 50/60 Hz, Single Phase |
| Power Consumption | 68.68 W (Access) 34.78 W (HDD Hibernation) |
| British Thermal Unit | 234.35 BTU/hr (Access) 118.67 BTU/hr (HDD Hibernation) |
| Notes | Power consumption is measured when it is fully loaded with Western Digital 1TB WD10EFRX hard drive(s). Noise Level Testing Environment: Fully loaded with Seagate 2TB ST2000VN000 hard drive(s) in the idle state. Two G.R.A.S. Type 40AE microphones, each set up 1 meter away from the Synology NAS at the front and rear. Background noise: 16.49-17.51 dB(A); Temperature: 24.25-25.75??C; Humidity: 58.2-61.8% |
| Operating Temperature | 5??C to 35??C (40??F to 95??F) |
| Storage Temperature | -20??C to 60??C (-5??F to 140??F) |
| Relative Humidity | 5% to 95% RH |
| Certification | EAC CCC KC FCC CE BSMI VCCI RCM |
| Warranty | 5 Years |
| Notes | The warranty period starts from the purchase date as stated on your purchase receipt. (Learn more) |
| RoHS Compliant | Yes |
| Packaging Content | Main Unit X 1 Accessory Pack X 1 AC Power Cord X 2 Quick Installation Guide X 1 |
| Optional Accessories | DDR4 ECC UDIMM: D4EC-2666-8G/D4EC-2666-16G Expansion Units: RX1217/RX1217RP 3.5" SATA HDD: HAT5300 2.5" SATA SSD: SAT5210 25GbE Network Interface Card: E25G30-F2 10GbE Network Interface Card: E10G21-F2/E10G18-T2/E10G18-T1 Rail Kit Sliding: RKS-02 Rail Kit Mounted: RKM114* Surveillance Device License Pack |
| Notes | Certain items may not be available in your location. Please contact your local distributors for more information. All memory modules will operate at the maximum frequency specified by the CPU manufacturer. |
