Thermaltake View 71 Tempered Glass RGB Edition E-ATX Case, 5mm Tempered Glass x 4 (Left & Right & Front & Top), 4x Pre Installed Fans, USB 3.0 x 2, USB 2.0 x 2, HD Audio x 1, 8+2 Expansion Slots, USB 3.0 x 2, USB 2.0 x 2, HD Audio x 1 | CA-117-00F1WN-00
Model :
SKU : ATX-THERMAL VIEW71 BLACK
About this item
0
Inclusive of VAT
Delivery to
FREE scheduled delivery as soon as Loading...
Sold and shipped by: Adarc computers
1
About this item
Description
View Full Tower Case Specifications table { border-collapse: collapse; width: 100%; margin-top: 20px; } tr { border-bottom: 1px solid rgb(222, 226, 230); } td { padding: 8px; margin: 0; } td:first-child { font-weight: bold; color: #333; }
Thermaltake View 71 Tempered Glass RGB Edition E-ATX Case, 5mm Tempered Glass x 4 (Left & Right & Front & Top), USB 3.0 x 2, USB 2.0 x 2, HD Audio x 1, 8+2 Expansion Slots, USB 3.0 x 2, USB 2.0 x 2, HD Audio x 1, 4x Pre Installed Fans | CA-117-00F1WN-00
| P/N | CA-117-00F1WN-00 |
| SERIES | View |
| CASE TYPE | Full Tower |
| DIMENSION (H X W X D) | 577 x 274 x 592 mm (22.7 x 10.8 x 23.3 inch) |
| NET WEIGHT | 19.1 kg / 42.10 lb |
| PANEL | 5mm Tempered Glass x 4 (Left & Right & Front & Top) |
| COLOR | Exterior & Interior: Black |
| MATERIAL | SPCC |
| COOLING SYSTEM | |
| Rear (exhaust) | 140 x 140 x 25 mm Riing RGB fan (1400rpm, 28dBA) |
| Front (intake) | 140 x 140 x 25 mm Riing RGB fan (1400rpm, 28dBA) x2 |
| DRIVE BAYS | 2.5??? x 4 or 3.5???x4 (HDD Rack) 2.5???x 6 or 3.5??? x 3 |
| EXPANSION SLOTS | 8+2 |
| MOTHERBOARDS | 6.7??? x 6.7??? (Mini ITX), 9.6??? x 9.6??? (Micro ATX), 12??? x 9.6??? (ATX), 12??? x 13???(E-ATX) |
| I/O PORT | USB 3.0 x 2, USB 2.0 x 2, HD Audio x 1 |
| PSU | Standard PS2 PSU (optional) |
| FAN SUPPORT | |
| Front | 3 x 120mm , 2 x 140mm |
| Top | 3 x 120mm , 3 x 140mm |
| Rear | 1 x 120mm, 1 x 140mm |
| Bottom | 2 x 120mm |
| RADIATOR SUPPORT | |
| Front | 1 x 360mm , 1 x 420mm |
| Top | 1 x 360mm , 1 x 420mm |
| Rear | 1 x 120mm, 1 x 140mm |
| Right | 1 x 360mm, 1 x 420mm |
| Bottom | 1 x 240mm |
| CLEARANCE | |
| CPU cooler height limitation | 190mm |
| VGA length limitation | 310mm(With HDD Rack) 410mm(Without HDD Rack) |
| PSU length limitation | 220mm (Without Bottom Fan) |
Specification
View Full Tower Case Specifications table { border-collapse: collapse; width: 100%; margin-top: 20px; } tr { border-bottom: 1px solid rgb(222, 226, 230); } td { padding: 8px; margin: 0; } td:first-child { font-weight: bold; color: #333; }
Thermaltake View 71 Tempered Glass RGB Edition E-ATX Case, 5mm Tempered Glass x 4 (Left & Right & Front & Top), USB 3.0 x 2, USB 2.0 x 2, HD Audio x 1, 8+2 Expansion Slots, USB 3.0 x 2, USB 2.0 x 2, HD Audio x 1, 4x Pre Installed Fans | CA-117-00F1WN-00
| P/N | CA-117-00F1WN-00 |
| SERIES | View |
| CASE TYPE | Full Tower |
| DIMENSION (H X W X D) | 577 x 274 x 592 mm (22.7 x 10.8 x 23.3 inch) |
| NET WEIGHT | 19.1 kg / 42.10 lb |
| PANEL | 5mm Tempered Glass x 4 (Left & Right & Front & Top) |
| COLOR | Exterior & Interior: Black |
| MATERIAL | SPCC |
| COOLING SYSTEM | |
| Rear (exhaust) | 140 x 140 x 25 mm Riing RGB fan (1400rpm, 28dBA) |
| Front (intake) | 140 x 140 x 25 mm Riing RGB fan (1400rpm, 28dBA) x2 |
| DRIVE BAYS | 2.5??? x 4 or 3.5???x4 (HDD Rack) 2.5???x 6 or 3.5??? x 3 |
| EXPANSION SLOTS | 8+2 |
| MOTHERBOARDS | 6.7??? x 6.7??? (Mini ITX), 9.6??? x 9.6??? (Micro ATX), 12??? x 9.6??? (ATX), 12??? x 13???(E-ATX) |
| I/O PORT | USB 3.0 x 2, USB 2.0 x 2, HD Audio x 1 |
| PSU | Standard PS2 PSU (optional) |
| FAN SUPPORT | |
| Front | 3 x 120mm , 2 x 140mm |
| Top | 3 x 120mm , 3 x 140mm |
| Rear | 1 x 120mm, 1 x 140mm |
| Bottom | 2 x 120mm |
| RADIATOR SUPPORT | |
| Front | 1 x 360mm , 1 x 420mm |
| Top | 1 x 360mm , 1 x 420mm |
| Rear | 1 x 120mm, 1 x 140mm |
| Right | 1 x 360mm, 1 x 420mm |
| Bottom | 1 x 240mm |
| CLEARANCE | |
| CPU cooler height limitation | 190mm |
| VGA length limitation | 310mm(With HDD Rack) 410mm(Without HDD Rack) |
| PSU length limitation | 220mm (Without Bottom Fan) |
