Home/Networking/Home Networking/Wireless Networking/tp-link ER706W-4G Omada 4G+ Cat6 AX3000 Gigabit VP...
tp-link ER706W-4G Omada 4G+ Cat6 AX3000 Gigabit VPN Router, Supports 2402 Mbps on 5 GHz and 574 Mbps on 2.4 GHz, High-Security VPN
Model :
SKU : WR-TPLINK ER706W-4G+ VPN
About this item
0
Inclusive of VAT
Delivery to
FREE scheduled delivery as soon as Loading...
Sold and shipped by: Adarc computers
1
About this item
Description
table { border-collapse: collapse; width: 100%; } tr { border-bottom: 1px solid rgb(222, 226, 230); } td { padding: 8px; margin: 0; } td:first-child { font-weight: bold; color: #333; } h3 { margin-top: 10px; }
ER706W-4G Router Specifications
4G Network
| Network Type |
|
| Carrier Aggregation | B1+B1/B3/B5/B7/B8/B20/B28/B38/B40/B41, B3+B3/B5/B7/B8/B20/B28/B38/B40/B41, B5+B5/B7/B38/B40/B41, B7+B7/B8/B20/B28/B32, B8+B32/B38/B40/B41, B20+B32/B38/B40, B28+B32/B38/B40/B41, B38+B38, B40+B40, B41+B41 |
| SIM Type | 1?? Nano SIM Card |
| Frequency | Downlink: 300 Mbps; Uplink: 50 Mbps |
Security
| Access Control | Source/Destination IP Based Access Control |
| Filtering | Web Group Filtering???, URL Filtering, Web Security??? |
| ARP Inspection | Sending GARP Packets, ARP Scanning???, IP-MAC Binding |
| Attack Defense | TCP/UDP/ICMP Flood Defense, Block TCP Scan (Stealth FIN/Xmas/Null), Block Ping from WAN |
Hardware Features
| Interfaces |
|
| Network Media | 10BASE-T, 100BASE-TX, 1000BASE-T with UTP Cat 3???6 cables (Max 100m) |
| Button | Reset Button |
| Power Supply | 12VDC / 2A Power Adapter |
| Wi-Fi Frequency & Rate | 2.4 GHz: 574 Mbps; 5 GHz: 2402 Mbps (HE160) |
| Flash / DRAM | 128 MB NAND / 512 MB DDR4 |
| LED Indicators | SYS, WLAN, SFP, LTE Signal, WAN, WAN/LAN |
| Dimensions | 226 ?? 131 ?? 35 mm (8.9 ?? 5.2 ?? 1.4 in) |
| Antenna |
|
| Mounting | Desktop / Wall-Mounting |
| Max Power Consumption | EU: 17.3W |
Performance
| GRE Throughput | Unencrypted: 545.3Mbps; Encrypted: 282.6Mbps |
| WireGuard VPN | 387.7Mbps |
| Concurrent Sessions | 150,000 |
| New Sessions/sec | 5,100 |
| NAT (Static IP) | 947.1Mbps / 940.1Mbps |
| NAT (DHCP) | 949.2Mbps / 941.1Mbps |
| NAT (PPPoE) | 942.6Mbps / 941.1Mbps |
| NAT (L2TP) | 875.4Mbps / 892.0Mbps |
| NAT (PPTP) | 881.2Mbps / 895.8Mbps |
| IPSec VPN |
|
| OpenVPN | 115.5Mbps |
| L2TP VPN | Unencrypted: 990Mbps; Encrypted: 475Mbps |
| PPTP VPN | Unencrypted: 1177.9Mbps; Encrypted: 177.4Mbps |
| SSL VPN | 122.5Mbps |
| Packet Forwarding Rate (66 Byte) | 1,453,489 pps |
| Packet Forwarding Rate (1,518 Byte) | 81,274 pps / 91,275 pps |
Wireless Features
| Advanced Features | Seamless Roaming, Mesh, OFDMA, Beamforming, MU-MIMO, Rate Limit, Airtime Fairness, WPA/WPA2/WPA3 (Personal/Enterprise), 16 SSIDs, Guest Network |
Basic Functions
| WAN Connection Types | Static IP, Dynamic IP, PPPoE, PPTP, L2TP |
| MAC Clone | WAN Address Modification |
| DHCP | Server, DHCPv6 PD, Options Customization, Address Reservation, Multi-IP Interfaces, Multi-Net DHCP |
| SMS | Send/Receive SMS |
| IPv6 | StaticIP, SLAAC, DHCPv6, PPPoE, 6to4Tunnel, PassThrough |
| VLAN | 802.1Q VLAN |
| IPTV | IGMP v2/v3 Proxy, Bridge, Custom Mode |
Advanced Features
| ACL | IP/Port/Protocol/Domain Filtering |
| Routing | Static Routing, Policy Routing, RIP???, OSPF??? |
| Bandwidth Control | IP-Based Control |
| Load Balance | Intelligent Load Balance, Optimized Routing, Failover, Detection |
| NAT | One-to-One, Multi-Net, Virtual Server, Port Triggering???, NAT-DMZ, ALG, UPnP |
| Session Limit | IP-Based |
VPN Support
| GRE | Standalone Mode |
| SSL VPN | 50 Tunnels |
| IPsec VPN | 100 Tunnels, AES256, IKE v1/v2, NAT-T, PFS, DPD, Failover |
| PPTP VPN | Client(10), Server, 50 Tunnels, MPPE Encryption |
| L2TP VPN | Client(10), Server, 50 Tunnels, L2TP over IPSec |
| OpenVPN | Client(5), Server, 55 Tunnels, Full & "Cert+Account" Mode |
Authentication
| Web Authentication | None, Simple Password, Hotspot, RADIUS, LDAP, External Portal |
Management
| Omada App | Supported |
| Controllers | Cloud, OC300, OC200, Software |
| Cloud Access | Yes |
| Service | DDNS (Dyndns, No-IP, Peanuthull, Comexe) |
| Maintenance | Web, Remote, SNMP, CLI, Syslog, Ping/Traceroute, NTP, Import/Export, Port Mirroring |
| Zero-Touch Provisioning | Yes (Omada Cloud-Based Controller required) |
Others
| Certification | CE, FCC, RoHS |
| Package Contents | ER706W-4G, Power Adapter, Quick Installation Guide |
| System Requirements | Windows 98SE???11, Mac OS, NetWare, UNIX, Linux |
| Environment | Operating: 0???40??C, Storage: -40???70??C, Humidity: 5???90% (non-condensing) |
