Ubiquiti Dream Machine Pro Max Switch, 8x GbE RJ45 & 1x 10G SFP+ LAN Ports, Up to 5Gbps IDS/IPS Throughput, 1.3" Touchscreen, Quad-Core ARM Cortex-A57, White | UDM-PRO-MAX-EU
Model :
SKU : NS-UNIFI UDM-Pro-Max
About this item
Enhanced computing power and memory for 2x the UniFi device and client capacity of Dream Machine Pro/SE
Includes full UniFi application suite for device management
5 Gbps routing with IDS/IPS
(1) 10G SFP+*, (8) GbE RJ45 LAN ports
(1) 10G SFP+*, (1) 2.5 GbE RJ45 WAN ports
(2) 3.5" NVR HDD bays with RAID data protection
Built-in 128 GB SSD for NVR detection recordings
1.3" touchscreen
0
Inclusive of VAT
Delivery to
FREE scheduled delivery as soon as Loading...
Sold and shipped by: Adarc computers
1
About this item
Description
Dream Machine Pro Max
| Dimensions | 442.4 x 43.7 x 285.6 mm (17.4 x 1.7 x 11.2") |
| Weight | 4.7 kg (10.4 lb) |
| Enclosure Material | Aluminium CNC, SGCC steel |
| Mount Material | SGCC steel |
| Processor | Quad-core ARM?? Cortex??-A57 at 2.0 GHz |
| System Memory | 8 GB DDR4 |
| On-Board Storage | 32 GB eMMC |
| Integrated Storage | 128 GB SSD |
| Management Interface | Ethernet, Bluetooth |
| Networking Interface | LAN: (8) GbE RJ45 ports, (1) 10G SFP+ port WAN: (1) 2.5 GbE RJ45 port, (1) 10G SFP+ port |
| IDS/IPS Throughput | 5 Gbps* |
| Power Method | (1) Universal AC input, 100???240V AC, 2A Max., 50/60 Hz (1) USP-RPS DC input, 11.5V DC, 8.7A |
| Power Supply | AC/DC, internal, 100W |
| Supported Voltage Range | 100???240V AC |
| Max. Power Consumption | 60W |
| ESD/EMP Protection | Air: ?? 15kV, contact: ?? 8kV |
| LCM Display | (1) 1.3" touchscreen |
| Button | Factory reset |
| Ambient Operating Temperature | -10?? to 40?? C (14?? to 104?? F) |
| Ambient Operating Humidity | 5 to 95% noncondensing |
| Certifications | CE, FCC, IC |
| Gateway Features |
Performance: Redundant WAN with failover and load balancing, WiFi QoS with UniFi APs,
Application, domain, and country-based QoS, Application and device type identification,
Additional internet failover with LTE Backup, Internet quality and outage reporting Next-Generation Security: Application-aware firewall rules, Signature-based IPS/IDS threat detection, Content, country, domain, and ad filtering, VLAN/subnet-based traffic segmentation, Full stateful firewall Advanced Networking: License-free SD-WAN, WireGuard, L2TP and OpenVPN server, OpenVPN client, OpenVPN and IPsec site-to-site VPN, One-click Teleport and Identity VPN, Policy-based WAN and VPN routing, DHCP relay, Customizable DHCP server, IGMP proxy, IPv6 ISP support |
| LEDs |
Ethernet: Green: link/activity SFP+: Green: link/activity HDD: White: disk activity, Amber: disk error RPS: Blue: ready |
Specification
Dream Machine Pro Max
| Dimensions | 442.4 x 43.7 x 285.6 mm (17.4 x 1.7 x 11.2") |
| Weight | 4.7 kg (10.4 lb) |
| Enclosure Material | Aluminium CNC, SGCC steel |
| Mount Material | SGCC steel |
| Processor | Quad-core ARM?? Cortex??-A57 at 2.0 GHz |
| System Memory | 8 GB DDR4 |
| On-Board Storage | 32 GB eMMC |
| Integrated Storage | 128 GB SSD |
| Management Interface | Ethernet, Bluetooth |
| Networking Interface | LAN: (8) GbE RJ45 ports, (1) 10G SFP+ port WAN: (1) 2.5 GbE RJ45 port, (1) 10G SFP+ port |
| IDS/IPS Throughput | 5 Gbps* |
| Power Method | (1) Universal AC input, 100???240V AC, 2A Max., 50/60 Hz (1) USP-RPS DC input, 11.5V DC, 8.7A |
| Power Supply | AC/DC, internal, 100W |
| Supported Voltage Range | 100???240V AC |
| Max. Power Consumption | 60W |
| ESD/EMP Protection | Air: ?? 15kV, contact: ?? 8kV |
| LCM Display | (1) 1.3" touchscreen |
| Button | Factory reset |
| Ambient Operating Temperature | -10?? to 40?? C (14?? to 104?? F) |
| Ambient Operating Humidity | 5 to 95% noncondensing |
| Certifications | CE, FCC, IC |
| Gateway Features |
Performance: Redundant WAN with failover and load balancing, WiFi QoS with UniFi APs,
Application, domain, and country-based QoS, Application and device type identification,
Additional internet failover with LTE Backup, Internet quality and outage reporting Next-Generation Security: Application-aware firewall rules, Signature-based IPS/IDS threat detection, Content, country, domain, and ad filtering, VLAN/subnet-based traffic segmentation, Full stateful firewall Advanced Networking: License-free SD-WAN, WireGuard, L2TP and OpenVPN server, OpenVPN client, OpenVPN and IPsec site-to-site VPN, One-click Teleport and Identity VPN, Policy-based WAN and VPN routing, DHCP relay, Customizable DHCP server, IGMP proxy, IPv6 ISP support |
| LEDs |
Ethernet: Green: link/activity SFP+: Green: link/activity HDD: White: disk activity, Amber: disk error RPS: Blue: ready |
