Without mounting brackets: 3 kg (6.6 lb) With mounting brackets: 3.1 kg (6.8 lb)
Enclosure material
SGCC steel
Management interface
Ethernet In-Band
Networking interface
(24) GbE RJ45 ports (2) 1G SFP ports
PoE interface
(16) PoE/PoE+ (Pins 1, 2+; 3, 6-)
Total non-blocking throughput
26 Gbps
Switching capacity
52 Gbps
Forwarding rate
38.69 Mpps
Power method
Universal input, 100???240V AC, 50/60 Hz
Power supply
AC/DC, internal, 120W
Supported voltage range
100???240V AC
Max. power consumption
25W (Excluding PoE output)
Total available PoE
95W
Max. PoE wattage per port by PSE
PoE+: 32W
Voltage range PoE mode
PoE: 44???57V PoE+: 50???57V
ESD/EMP protection
Air: ?? 16kV, contact: ?? 12kV
LCM display
(1) 1.3" touchscreen
Button
Factory reset
Shock and vibration
ETSI300-019-1.4 Standard
Ambient operating temperature
-5 to 40?? C (23 to 104?? F)
Ambient operating humidity
10 to 90% noncondensing
Certifications
CE, FCC, IC
Layer 2 features
IGMP snooping
STP / RSTP with priorities and port-level disable
Port isolation
Storm control
Voice VLAN
Port mirroring
LACP port aggregation
Multicast / broadcast rate limiting
MAC address blocking
Flow control
802.1X control
Jumbo frames
Proprietary loop protection
DHCP snooping / guarding
Egress rate limit
LLDP-MED
Port restricted by MAC
Device isolation with ACLs
Without mounting brackets: 3 kg (6.6 lb) With mounting brackets: 3.1 kg (6.8 lb)
Enclosure material
SGCC steel
Management interface
Ethernet In-Band
Networking interface
(24) GbE RJ45 ports (2) 1G SFP ports
PoE interface
(16) PoE/PoE+ (Pins 1, 2+; 3, 6-)
Total non-blocking throughput
26 Gbps
Switching capacity
52 Gbps
Forwarding rate
38.69 Mpps
Power method
Universal input, 100???240V AC, 50/60 Hz
Power supply
AC/DC, internal, 120W
Supported voltage range
100???240V AC
Max. power consumption
25W (Excluding PoE output)
Total available PoE
95W
Max. PoE wattage per port by PSE
PoE+: 32W
Voltage range PoE mode
PoE: 44???57V PoE+: 50???57V
ESD/EMP protection
Air: ?? 16kV, contact: ?? 12kV
LCM display
(1) 1.3" touchscreen
Button
Factory reset
Shock and vibration
ETSI300-019-1.4 Standard
Ambient operating temperature
-5 to 40?? C (23 to 104?? F)
Ambient operating humidity
10 to 90% noncondensing
Certifications
CE, FCC, IC
Layer 2 features
IGMP snooping
STP / RSTP with priorities and port-level disable
Port isolation
Storm control
Voice VLAN
Port mirroring
LACP port aggregation
Multicast / broadcast rate limiting
MAC address blocking
Flow control
802.1X control
Jumbo frames
Proprietary loop protection
DHCP snooping / guarding
Egress rate limit
LLDP-MED
Port restricted by MAC
Device isolation with ACLs
Without mounting brackets: 3 kg (6.6 lb) With mounting brackets: 3.1 kg (6.8 lb)
Enclosure material
SGCC steel
Management interface
Ethernet In-Band
Networking interface
(24) GbE RJ45 ports (2) 1G SFP ports
PoE interface
(16) PoE/PoE+ (Pins 1, 2+; 3, 6-)
Total non-blocking throughput
26 Gbps
Switching capacity
52 Gbps
Forwarding rate
38.69 Mpps
Power method
Universal input, 100???240V AC, 50/60 Hz
Power supply
AC/DC, internal, 120W
Supported voltage range
100???240V AC
Max. power consumption
25W (Excluding PoE output)
Total available PoE
95W
Max. PoE wattage per port by PSE
PoE+: 32W
Voltage range PoE mode
PoE: 44???57V PoE+: 50???57V
ESD/EMP protection
Air: ?? 16kV, contact: ?? 12kV
LCM display
(1) 1.3" touchscreen
Button
Factory reset
Shock and vibration
ETSI300-019-1.4 Standard
Ambient operating temperature
-5 to 40?? C (23 to 104?? F)
Ambient operating humidity
10 to 90% noncondensing
Certifications
CE, FCC, IC
Layer 2 features
IGMP snooping
STP / RSTP with priorities and port-level disable
Port isolation
Storm control
Voice VLAN
Port mirroring
LACP port aggregation
Multicast / broadcast rate limiting
MAC address blocking
Flow control
802.1X control
Jumbo frames
Proprietary loop protection
DHCP snooping / guarding
Egress rate limit
LLDP-MED
Port restricted by MAC
Device isolation with ACLs
Without mounting brackets: 3 kg (6.6 lb) With mounting brackets: 3.1 kg (6.8 lb)
Enclosure material
SGCC steel
Management interface
Ethernet In-Band
Networking interface
(24) GbE RJ45 ports (2) 1G SFP ports
PoE interface
(16) PoE/PoE+ (Pins 1, 2+; 3, 6-)
Total non-blocking throughput
26 Gbps
Switching capacity
52 Gbps
Forwarding rate
38.69 Mpps
Power method
Universal input, 100???240V AC, 50/60 Hz
Power supply
AC/DC, internal, 120W
Supported voltage range
100???240V AC
Max. power consumption
25W (Excluding PoE output)
Total available PoE
95W
Max. PoE wattage per port by PSE
PoE+: 32W
Voltage range PoE mode
PoE: 44???57V PoE+: 50???57V
ESD/EMP protection
Air: ?? 16kV, contact: ?? 12kV
LCM display
(1) 1.3" touchscreen
Button
Factory reset
Shock and vibration
ETSI300-019-1.4 Standard
Ambient operating temperature
-5 to 40?? C (23 to 104?? F)
Ambient operating humidity
10 to 90% noncondensing
Certifications
CE, FCC, IC
Layer 2 features
IGMP snooping
STP / RSTP with priorities and port-level disable
Port isolation
Storm control
Voice VLAN
Port mirroring
LACP port aggregation
Multicast / broadcast rate limiting
MAC address blocking
Flow control
802.1X control
Jumbo frames
Proprietary loop protection
DHCP snooping / guarding
Egress rate limit
LLDP-MED
Port restricted by MAC
Device isolation with ACLs
Layer 3 features
???
LEDs
System
Status
Ethernet
PoE Speed/link/activity
SFP
Link/activity
Application Requirements
UniFi Network Version 7.2.94 and later
