Unifi AM-5G19-120 airMAX 5 GHz, 19/20 dBi Sector 5 GHz, 120??, 19 dBi or 90??, 20 dBi antenna for sector coverage in Point-to-MultiPoint (PtMP) networks
Model :
SKU : UNIFI AIRM SECTOR AM-5G19
About this item
Description
table { border-collapse: collapse; width: 100%; } tr { border-bottom: 1px solid rgb(222, 226, 230); } td { padding: 8px; margin: 0; } td:first-child { font-weight: bold; color: #333; } h3 { margin-top: 10px; }
Unifi AM-5G19-120 airMAX 5 GHz, 19/20 dBi Sector 5 GHz, 120??, 19 dBi or 90??, 20 dBi antenna for sector coverage in Point-to-MultiPoint (PtMP) networks Specifications
| Dimensions (mm) | 700 x 135 x 73 mm (27.6 x 5.3 x 2.9") |
| Weight | 5.9 kg (13 lb) |
| Frequency Range | 5.15 - 5.85 GHz |
| Gain | 18.6 - 19.1 dBi |
| HPOL Beamwidth | 123?? (6 dB) |
| VPOL Beamwidth | 123?? (6 dB) |
| Electrical Beamwidth | 4?? |
| Electrical Downtilt | 2?? |
| Max. VSWR | 1.5:1 |
| Wind Survivability | 200 km/h (125 mph) |
| Wind Loading | 89 N @ 160 km/h (20 lbf @ 100 mph) |
| Polarization | Dual-Linear |
| Cross-pol Isolation | 28 dB Min. |
| ETSI Specification | EN 302 326 DN2 |
| Mounting | Universal Pole Mount, RocketM Bracket, and Weatherproof RF Jumpers Included |
AM-5G20-90 Specifications
| Dimensions | 700 x 135 x 70 mm (27.6 x 5.3 x 2.8") |
| Weight | 5.9 kg (13 lb) |
| Frequency Range | 5.15 - 5.85 GHz |
| Gain | 19.4 - 20.3 dBi |
| HPOL Beamwidth | 91?? (6 dB) |
| VPOL Beamwidth | 85?? (6 dB) |
| Electrical Beamwidth | 4?? |
| Electrical Downtilt | 2?? |
| Max. VSWR | 1.5:1 |
| Wind Survivability | 200 km/h (125 mph) |
| Wind Loading | 115 N @ 160 km/h (26 lbf @ 100 mph) |
| Polarization | Dual-Linear |
| Cross-pol Isolation | 28 dB Min. |
| ETSI Specification | EN 302 326 DN2 |
| Mounting | Universal Pole Mount, RocketM Bracket, and Weatherproof RF Jumpers Included |
| NDAA Compliant | Yes |
