Unifi Enterprise 24 PoE A 24-port, Layer 3 switch with 2.5 GbE PoE+ output, 400W total PoE availability | USW-Enterprise-24-PoE (400W)
Model :
SKU : NS-UNIFI USW-ENTER-24-POE
About this item
About this item
Description
Specification
| Dimensions | 442 x 325 x 44 mm (17.4 x 12.8 x 1.7") |
| Weight | Without mounting brackets: 5.1 kg (11.3 lb) With mounting brackets: 5.2 kg (11.5 lb) |
| Enclosure Material | SGCC steel |
| Management Interface | Ethernet In-Band |
| Networking Interface | (12) GbE RJ45 ports (12) 2.5 GbE RJ45 ports (2) 10G SFP+ ports |
| PoE Interface | (24) PoE/PoE+ (Pins 1, 2+; 3, 6-) |
| Total Non-Blocking Throughput | 62 Gbps |
| Switching Capacity | 124 Gbps |
| Forwarding Rate | 92.25 Mpps |
| Power Method | (1) Universal input, 100???240V AC, 8.5A Max., 50/60 Hz (1) USP-RPS DC input: 52V DC, 7.7A; 11.5V DC, 8.7A |
| Power Supply | AC/DC, internal, 550W |
| Supported Voltage Range | 100???240V AC |
| Max. Power Consumption | 60W (Excluding PoE output) |
| Total Available PoE | 400W |
| Max. PoE+ Wattage Per Port by PSE | 34.2W |
| Voltage Range PoE Mode | PoE: 44???57V PoE+: 50???57V |
| Services | SMB Layer 3 PoE GbE switch |
| ESD/EMP Protection | Air: ?? 16kV, Contact: ?? 12kV |
| LCM Display | (1) 1.3" color touchscreen |
| Button | Factory reset |
| Ambient Operating Temperature | -5 to 40?? C (23 to 104?? F) |
| Ambient Operating Humidity | 10 to 95% noncondensing |
| Certifications | CE, FCC, IC |
| Switching Features | |
| Layer 2 Features | IGMP snooping, STP/RSTP with priorities and port-level disable, Port isolation, Storm control, Voice VLAN, Port mirroring, LACP port aggregation, Multicast/broadcast rate limiting, MAC address blocking, Flow control, 802.1X control, Jumbo frames, Proprietary loop protection, DHCP snooping/guarding, Egress rate limit, LLDP-MED, Port restricted by MAC, Device isolation with ACLs |
| Layer 3 Features | DHCP for locally-managed networks, DHCP relay, Inter-VLAN routing between networks on the same switch, Static routing between local networks, Network isolation with ACLs |
| LEDs | |
| System | Status |
| Ethernet | Link/activity |
| SFP+ | Link/activity |
| Application Requirements | |
| UniFi Network | Version 5.14.12 and later |
