Unifi U6 Mesh Pro Indoor/outdoor WiFi 6 AP with 4 spatial streams, Integrated super antenna, Gigabit passthrough port | U6-Mesh-Pro
Model :
SKU : WAP-UNIFI U6 MESH PRO
0
Inclusive of VAT
Delivery to
FREE scheduled delivery as soon as Loading...
Sold and shipped by: Adarc computers
1
About this item
Description
Unifi U6 Mesh Pro Indoor/outdoor WiFi 6 AP with 4 spatial streams, Integrated super antenna, Gigabit passthrough port | U6-Mesh-Pro Specifications
| Mechanical | |
|---|---|
| Dimensions | 343.2 x 181.2 x 60.2 mm (13.5 x 7.1 x 2.4") |
| Weight | 819 g (1.8 lb) |
| Enclosure Material | UV-stabilized polycarbonate |
| Mount Material | Aluminum alloy, steel |
| Pole Mount Diameter | 1~2.5" on pipe outer diameter |
| Weatherproofing | IPX6 |
| Hardware | |
|---|---|
| Networking Interface | (2) GbE RJ45 ports |
| Management Interface | Ethernet |
| WiFi | Supported |
| Power Method | PoE |
| Power Supply | UniFi PoE switch, 48V, 0.5A PoE adapter (Included) |
| Supported Voltage Range | 42.5???57V DC |
| Max. Power Consumption | 9W |
| Max. TX Power |
2.4 GHz: 22 dBm 5 GHz: 27 dBm 6 GHz: ??? |
| MIMO |
2.4 GHz: 2 x 2 (DL/UL MU-MIMO) 5 GHz: 2 x 2 (DL/UL MU-MIMO) 6 GHz: ??? |
| Max. Data Rate |
2.4 GHz: 573.5 Mbps (BW40) 5 GHz: 2.4 Gbps (BW160) 6 GHz: ??? |
| Antenna Gain |
2.4 GHz: 8 dBi 5 GHz: 8 dBi 6 GHz: ??? |
| LEDs | White/blue |
| Button | Factory reset |
| Mounting | Wall, pole (Included) |
| Ambient Operating Temperature | -30 to 60?? C (-22 to 140?? F) |
| Ambient Operating Humidity | 5 to 95% noncondensing |
| Certifications | CE, FCC, IC |
| Software | |
|---|---|
| WiFi Standards | 802.11a/b/g/n/ac/ax (WiFi 6) |
| Wireless Security | WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3) |
| BSSID | 8 per radio |
| VLAN | 802.1Q |
| Advanced QoS | Per-user rate limiting |
| Guest Traffic Isolation | Supported |
| Concurrent Clients | 350+ |
| Supported Data Rates |
802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps 802.11b: 1, 2, 5.5, 11 Mbps 802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps 802.11n: 6.5 Mbps to 300 Mbps (MCS0 - MCS15, HT 20/40) 802.11ac: 6.5 Mbps to 1.7 Gbps (MCS0 - MCS9 NSS1/2, VHT 20/40/80/160) 802.11ax (WiFi 6): 7.3 Mbps to 2.4 Gbps (MCS0 - MCS11 NSS1/2, HE 20/40/80/160) |
| Application Requirements | UniFi Network Version 8.1.127 and later |
Specification
Unifi U6 Mesh Pro Indoor/outdoor WiFi 6 AP with 4 spatial streams, Integrated super antenna, Gigabit passthrough port | U6-Mesh-Pro Specifications
| Mechanical | |
|---|---|
| Dimensions | 343.2 x 181.2 x 60.2 mm (13.5 x 7.1 x 2.4") |
| Weight | 819 g (1.8 lb) |
| Enclosure Material | UV-stabilized polycarbonate |
| Mount Material | Aluminum alloy, steel |
| Pole Mount Diameter | 1~2.5" on pipe outer diameter |
| Weatherproofing | IPX6 |
| Hardware | |
|---|---|
| Networking Interface | (2) GbE RJ45 ports |
| Management Interface | Ethernet |
| WiFi | Supported |
| Power Method | PoE |
| Power Supply | UniFi PoE switch, 48V, 0.5A PoE adapter (Included) |
| Supported Voltage Range | 42.5???57V DC |
| Max. Power Consumption | 9W |
| Max. TX Power |
2.4 GHz: 22 dBm 5 GHz: 27 dBm 6 GHz: ??? |
| MIMO |
2.4 GHz: 2 x 2 (DL/UL MU-MIMO) 5 GHz: 2 x 2 (DL/UL MU-MIMO) 6 GHz: ??? |
| Max. Data Rate |
2.4 GHz: 573.5 Mbps (BW40) 5 GHz: 2.4 Gbps (BW160) 6 GHz: ??? |
| Antenna Gain |
2.4 GHz: 8 dBi 5 GHz: 8 dBi 6 GHz: ??? |
| LEDs | White/blue |
| Button | Factory reset |
| Mounting | Wall, pole (Included) |
| Ambient Operating Temperature | -30 to 60?? C (-22 to 140?? F) |
| Ambient Operating Humidity | 5 to 95% noncondensing |
| Certifications | CE, FCC, IC |
| Software | |
|---|---|
| WiFi Standards | 802.11a/b/g/n/ac/ax (WiFi 6) |
| Wireless Security | WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3) |
| BSSID | 8 per radio |
| VLAN | 802.1Q |
| Advanced QoS | Per-user rate limiting |
| Guest Traffic Isolation | Supported |
| Concurrent Clients | 350+ |
| Supported Data Rates |
802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps 802.11b: 1, 2, 5.5, 11 Mbps 802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps 802.11n: 6.5 Mbps to 300 Mbps (MCS0 - MCS15, HT 20/40) 802.11ac: 6.5 Mbps to 1.7 Gbps (MCS0 - MCS9 NSS1/2, VHT 20/40/80/160) 802.11ax (WiFi 6): 7.3 Mbps to 2.4 Gbps (MCS0 - MCS11 NSS1/2, HE 20/40/80/160) |
| Application Requirements | UniFi Network Version 8.1.127 and later |
