Unifi U7 In-Wall Wall-mounted WiFi??? 7 Access Point, 4x spatial streams & integrated 2.5 GbE PoE switch designed for hospitality environments.
Model :
SKU : UNINFI U7 IM-WALL U7-IW
About this item
0
Inclusive of VAT
Delivery to
FREE scheduled delivery as soon as Loading...
Sold and shipped by: Adarc computers
1
About this item
Description
Specification
table { border-collapse: collapse; width: 100%; } tr { border-bottom: 1px solid rgb(222, 226, 230); } td { padding: 8px; margin: 0; } td:first-child { font-weight: bold; color: #333; } h3 { margin-top: 10px; }
Unifi U7 In-Wall Wall-mounted WiFi??? 7 Access Point, 4x spatial streams & integrated 2.5 GbE PoE switch designed for hospitality environments. Overview
| Dimensions | 137 x 98.7 x 30.2 mm (5.4 x 3.9 x 1.2") |
|---|---|
| WiFi Standard | WiFi 7 |
| Spatial Streams | 4 |
| Coverage Area | 115 m?? (1,250 ft??) |
| Max. Client Count | 200+ |
| Uplink | 2.5 GbE |
| Mounting | Wall (Metal Wall Mount Included) |
| Power Method | PoE / PoE+ (Required for PoE output) |
Performance
| MIMO | 5 GHz: 2 x 2 (DL/UL MU-MIMO) 2.4 GHz: 2 x 2 (DL/UL MU-MIMO) |
|---|---|
| Max. Data Rate | 5 GHz: 4.3 Gbps (BW240) 2.4 GHz: 688 Mbps (BW40) |
| Antenna Gain | 5 GHz: 8 dBi 2.4 GHz: 4 dBi |
| Max. TX Power | 5 GHz: 24 dBm 2.4 GHz: 23 dBm |
| Max. BSSIDs | 8 per Radio |
| Supported Data Rates | 802.11be (WiFi 7): 7.3 Mbps to 4.3 Gbps 802.11ax (WiFi 6): 7.3 Mbps to 2.4 Gbps 802.11ac (WiFi 5): 6.5 Mbps to 1.7 Gbps 802.11n: 6.5 Mbps to 300 Mbps |
Features
| Wireless Meshing | ??? |
|---|---|
| Band Steering | ??? |
| 802.11v BSS Transition Management | ??? |
| 802.11r Fast Roaming | ??? |
| 802.11k Radio Resource Management (RRM) | ??? |
| Advanced Radio Management | ??? |
| Passpoint (Hotspot 2.0) | ??? |
| Captive Hotspot Portal | ??? |
| Custom Branding Landing Page | ??? |
| Voucher Authentication | ??? |
| Payment-Based Authentication | ??? |
| External Portal Server Support | ??? |
| Password Authentication | ??? |
| Guest Network Isolation | ??? |
| Private Pre-Shared Key (PPSK) | ??? |
| WiFi Speed Limiting | ??? |
| Client Device Isolation | ??? |
| WiFi Schedules | ??? |
| RADIUS over TLS (RadSec) | ??? |
| Dynamic RADIUS-assigned VLAN | ??? |
Hardware
| Max. Power Consumption | 13W (Excluding PoE output) |
|---|---|
| Supported Voltage Range | 42.5???57V DC |
| Networking Interface | (3) 2.5 GbE RJ45 ports |
| Weight | 400 g (14.1 oz) |
| Management | Ethernet |
| Built-In Switch | (1) PoE+ input and (1) PoE output |
| Enclosure Material | Polycarbonate, aluminum alloy |
| Mount Material | Aluminum alloy |
| LEDs | System (White/Blue) |
| Channel Bandwidth | HT 20/40, VHT 20/40/80/160, HE 20/40/80/160, EHT 20/40/80/160/240 (MHz) |
| NDAA Compliant | ??? |
| Certifications | CE, FCC, IC |
| Ambient Operating Temperature | -30 to 40?? C (-22 to 104?? F) |
| Ambient Operating Humidity | 5 to 95% noncondensing |
Software
| Application Requirements | UniFi Network Version 9.0.114 and later |
|---|---|
| Mobile App | iOS??? version 10.20.2 and later Android??? version 10.21.7 and later |
