ASUS ROG CROSSHAIR X870E GLACIAL E-ATX AM5 White Motherboard, 5" Full Color LCD, 4x DDR5 DIMM slots, max. 256GB, 7x M.2 slots (PCIe 5.0 support), Dual 10Gb Ethernet, Wi-Fi 7, USB4, 60W Quick Charge 4+ | 90MB1NQ0-M0EAY0
Model :
SKU : MB-ASUS X870E GLACIAL
The ROG CROSSHAIR X870E GLACIAL is an elite E-ATX motherboard engineered for the next generation of AI-powered computing and ultra-high-performance gaming. Built for AMD Ryzen™ 9000, 8000, and 7000 series processors, it features a stunning 5-inch full-color LCD for real-time system stats and a massive seven M.2 slots for extreme storage density. With dual 10Gb Ethernet, Wi-Fi 7, and USB4® connectivity, this motherboard represents the absolute pinnacle of the AM5 platform for enthusiasts and professional creators.
Description
The ASUS ROG CROSSHAIR X870E GLACIAL is more than just a motherboard; it is the ultimate foundation for the 2026 "Advanced AI PC." As part of the prestigious Crosshair line, the Glacial edition is optimized for users who demand the highest bandwidth and thermal efficiency. With its sophisticated white and silver aesthetic, integrated 5" LCD dashboard, and extreme power delivery, it is designed to push AMD Ryzen™ processors to their absolute theoretical limits.
Key Features
- Next-Gen Connectivity (Wi-Fi 7 & Dual 10GbE): Stay at the forefront of networking with Wi-Fi 7 support and Dual Realtek 10Gb Ethernet ports. This combination ensures ultra-low latency for competitive gaming and massive data throughput for NAS environments and professional workstations.
- Storage Without Limits: The X870E Glacial supports an incredible seven M.2 slots, including PCIe 5.0 lanes. With the included ROG Hyper M.2 card and Q-DIMM.2 expansion, you can create a localized storage array with speeds exceeding 10,000 MB/s.
- Intelligent AI Enhancements: Ready for the future of software, this board features AI Overclocking, AI Cooling II, and Two-Way AI Noise Cancelation. These features utilize machine learning to optimize your system’s performance and acoustics in real-time based on your specific hardware and environment.
- Extreme Power & Front Panel 60W Charging: The board features a robust VRM design and an 8-pin PCIe power connector dedicated to the front panel USB 20Gbps port. This enables 60W Quick Charge 4+, allowing you to fast-charge smartphones or tablets directly from your PC case.
- ASUS EZ DIY Features: Building a high-end PC has never been simpler. The Glacial includes a PCIe Q-Release Switch for easy GPU removal, M.2 Q-Slide, and a pre-mounted I/O shield. The Q-Antenna system for Wi-Fi 7 allows for snap-on installation without the need for tedious screwing.
Visual Hub: 5" Full-Color LCD The centerpiece of the Glacial is its high-resolution 5-inch LCD screen. Using the ASUS InfoHub and Armoury Crate, you can display custom GIFs, wallpapers, or critical system data such as CPU temperature, voltages, and fan speeds, making it the focal point of any high-end transparent build.
Why This Product Stands Out The X870E Glacial stands out by offering NitroPath DRAM Technology, which optimizes the memory trace paths for higher stability and cleaner signals, supporting DDR5 speeds of 9600+ MT/s (OC). It is a masterclass in engineering that balances extreme "over-the-top" features with practical DIY innovations, making it the definitive X870E motherboard for the AM5 era.
Specification
ASUS AMD X870E Motherboard – Specifications
| CPU Support | AMD Socket AM5 for AMD Ryzen™ 9000 / 8000 / 7000 Series Desktop Processors * Refer to ASUS support site for CPU compatibility list |
| Chipset | AMD X870E |
| Memory Slots | 4 x DIMM, max. 256GB, DDR5 |
| Memory Speed Support | Ryzen™ 9000: up to 8600+ MT/s (OC) Ryzen™ 8000: up to 9600+ MT/s (OC) Ryzen™ 7000: up to 8000+ MT/s (OC) |
| Memory Features | ECC / Non-ECC Unbuffered Dual Channel Architecture AMD EXPO™ Support DIMM Fit & DIMM Fit Pro ASUS AEMP NitroPath DRAM Technology |
| Graphics Output | 2 x USB4® (40Gbps) Type-C® with DisplayPort output Supports up to 4K@60Hz |
| PCIe Slots | Ryzen™ 9000 / 7000: 2 x PCIe 5.0 x16 (x16 / x8x8 / x8x4x4) Ryzen™ 8000 / 8400 / 8600 / 8700: 2 x PCIe 4.0 x16 |
| M.2 & SATA | Up to 7 x M.2 slots 4 x SATA 6Gb/s ports Supports PCIe 5.0 & PCIe 4.0 depending on CPU |
| RAID | AMD RAIDXpert2 RAID 0 / 1 / 5 / 10 |
| Ethernet | 2 x Realtek 10Gb Ethernet (ASUS LANGuard) |
| Wireless | Wi-Fi 7 (802.11be) Bluetooth® 5.4 (LE Audio) |
| Rear USB | 2 x USB4® (40Gbps) 12 x USB 10Gbps |
| Front USB | 2 x USB 20Gbps Type-C® USB Power Delivery up to 60W |
| Audio Codec | ROG SupremeFX ALC4082 ESS® ES9219 QUAD DAC 7.1 Surround Sound |
| Ports | USB4®, USB 10Gbps 2 x 10Gb Ethernet Wi-Fi Module Optical S/PDIF BIOS FlashBack™, Clear CMOS |
| Fan / Cooling | CPU Fan, CPU OPT, Chassis Fans, Radiator Fans, AIO, Pump Headers |
| Power | 24-pin ATX 2 x 8-pin CPU Power 1 x 8-pin PCIe Power |
| Overclocking & Design | Extreme OC Kit Dual BIOS Aura Sync RGB 5" Full-Color LCD Display |
| Software | Armoury Crate Aura Sync & Creator AI Overclocking AIDA64 (1 Year) |
| BIOS | UEFI AMI BIOS, Dual 512Mb Flash ROM |
| OS Support | Windows® 11 |
| Form Factor | E-ATX (12” x 10.9” / 30.5 cm x 27.7 cm) |
